Electrolux EKC7051BOW User Manual page 29

Install the shelf supports in the opposite
sequence.
CAUTION!
Make sure that the longer fixing wire is in
the front. The ends of the two wires must
point to the rear. Incorrect installation can
cause damage to the enamel.
11.4 Removing the oven door
To make the cleaning easier, remove the
door.
1
2
1. Open the door fully.
2. Move the slider until you hear a click.
3. Close the door until the slider locks.
4. Remove the door.
To remove the door, pull the door
outwards first from one side, and then the
other.
When the cleaning procedure is completed,
insert the oven door in the opposite
sequence. Make sure that you hear a click
when you insert the door. Use force if
necessary.
11.5 Removing and cleaning the
door glasses
The door glass in your product can be
different in type and shape from the
examples you see in the images. The
number of glasses can also be different.
1. Hold the door trim B on the top edge of
the door at the two sides and push
inwards to release the clip seal.
2
B
2. Pull the door trim to the front to remove it.
3. Hold the door glass panels on their top
edge one by one and pull them upwards
from the guide.
4. Clean the door glass panels.
To install panels, do the same steps in
reverse.
11.6 How to remove: grill
WARNING!
Deactivate the appliance before you
remove the heating element. Make sure
that the appliance is cold. There is a risk
of burns.
Remove the shelf supports.
You can remove the heating element to clean
the oven ceiling more easily.
1. Remove the screw which holds the
heating element. For the first time, use a
screwdriver.
2. Carefully pull the heating element down.
1
ENGLISH 29
