Project Source 5217236 Assembly Instruction Manual page 12

Hinge Adjustment:
Side adjustment:
Using a Phillips screwdriver, rotate
screw (1) clockwise to move the door
left and counter-clockwise to move the
door right. Moves the door up to 2 mm.
Drawer Adjustment:
Removing the drawer:
Open the drawer as far as possible.
Lift the drawer upward and pullout to
remove.
Depth adjustment:
Using a Phillips screwdriver, rotate screw
(2) clockwise to move the door forward
and counter- clockwise to move the door
backwards. Moves the door up to 2 mm.
Drawer adjustment:
For drawer alignment move the drawer up and down adjustable to
the desired position while moving left and right. When the screw is
realeased, the front can be moved +/- 1.5 mm in any direction.
Then the screws need to be retightened.
Height adjustment:
Using a Phillips screwdriver, rotate
screw (3) clockwise to move the door
upward and counter-clockwise to
move the door downward. Moves
the door up to 2 mm.
12
Door Assembly
Re-install the drawer.
