Project Source 5217236 Assembly Instruction Manual page 10

ASSEMBLY INSTRUCTIONS
13. Position the mounting bracket for the legs on the
underside of the cabinet box and using a phillips
head screwdriver, secure into place with csk screws
5/8" as per the illustration.
Hardware Used
DD PVC adjustable leg
Leg Mounting bracket
CSK screw 5/8"
HH
14. Insert the assembled drawer box into the
assembled cabinet box as per the illustration.
If adjustments to the drawer are needed, instructions
are available on page 12 of this manual.
15. Insert the shelf onto the cabinet at some angle as
per the drawing and press the shelf from the top
until it gets held with the shelf support hardware.
13
x 4
x 16
14
15
10
DD
HH
