FLIR K 5 Series User Manual

Hide thumbs Also See for K 5 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
User's manual
FLIR Kx5 series

Advertisement

Table of Contents
loading

Related Manuals for FLIR K 5 Series

Summary of Contents for FLIR K 5 Series

  • Page 1 User’s manual FLIR Kx5 series...
  • Page 4 Important note Before operating the device, you must read, understand, and follow all instructions, warnings, cautions, and legal disclaimers. Důležitá poznámka Před použitím zařízení si přečtěte veškeré pokyny, upozornění, varování a vyvázání se ze záruky, ujistěte se, že jim rozumíte, a řiďte se jimi.
  • Page 5 User’s manual FLIR Kx5 series #T559946; r. BA/41926/41970; en-US...

  • Page 7: Table Of Contents

    Submitting a question ..............7 Downloads ................8 Important information about FLIR Kx5 series service......9 Starting the camera for the first time (FLIR K65)........10 Quick start guide ................15 List of accessories and services ............16 System configuration overview ............17 Figure ..................
  • Page 8 Saving an image ..............32 12.6.1 General..............32 12.6.2 Figure ................ 32 12.6.3 Procedure ..............32 12.7 Recording a video clip (FLIR K55 and FLIR K65) ......33 12.7.1 General..............33 12.7.2 Figure ................ 33 12.7.3 Procedure ..............33 12.8 Continuous video recording (FLIR K55 and FLIR K65) ....
  • Page 9 18.1 Maintenance................72 18.2 Inspection ................72 18.3 Service ................. 72 Storage conditions ................73 About FLIR Systems ................ 74 20.1 More than just an infrared camera ..........75 20.2 Sharing our knowledge ............75 20.3 Supporting our customers............76 History of infrared technology............

  • Page 11: Legal Disclaimer

    1.8 EULA Terms free of charge if, upon inspection, it proves to be defective in material or work- manship and provided that it is returned to FLIR Systems within the said one- • You have acquired a device (“INFRARED CAMERA”) that includes soft- year period.

  • Page 12: Safety Information

    Applicability: Cameras with one or more batteries. Do not attach the batteries directly to a car’s cigarette lighter socket, unless FLIR Systems supplies a specific adapter to connect the batteries to a cigarette lighter socket. Damage to the batteries can occur.
  • Page 13 Safety information CAUTION Applicability: Cameras with one or more batteries. Do not hit the battery with a hammer. Damage to the battery can occur. CAUTION Applicability: Cameras with one or more batteries. Do not put your foot on the battery, hit it or cause shocks to it. Damage to the battery can occur. CAUTION Applicability: Cameras with one or more batteries.
  • Page 14 CAUTION Do not use the FLIR K series camera without the correct training. If the persons that operate the camera do not have the correct training, an incorrect analysis of the infrared images can occur. Thus, incorrect decisions during the firefighting can be made.

  • Page 15: Label Affixed To The Camera

    Damage to the equipment can occur. CAUTION Only use with batteries that have the part number T198310 on them (that FLIR Systems AB supplies). Damage to the equipment can occur if you do not obey this. WARNING Make sure that you only change the batteries in a known safe area.

  • Page 16: Notice To User

    3.5 Important note about this manual FLIR Systems issues generic manuals that cover several cameras within a model line. This means that this manual may contain descriptions and explanations that do not apply to your particular camera model.

  • Page 17: Customer Help

    • The communication protocol, or method, between the camera and your device (for ex- ample, SD card reader, HDMI, Ethernet, USB, or FireWire) • Device type (PC/Mac/iPhone/iPad/Android device, etc.) • Version of any programs from FLIR Systems #T559946; r. BA/41926/41970; en-US...

  • Page 18: Downloads

    Customer help • Full name, publication number, and revision number of the manual 4.3 Downloads On the customer help site you can also download the following, when applicable for the product: • Firmware updates for your infrared camera. • Program updates for your PC/Mac software. •...

  • Page 19: Important Information About Flir Kx5 Series Service

    Such residues include—but are not limited to—chemical fire-extinguishing com- pounds, radioactivity, biohazardous materials, and residues from chemical fires. • FLIR Systems reserves the right to charge the full cost for the decontamination and disinfection of contaminated cameras that are shipped to our service department.

  • Page 20: Starting The Camera For The First Time (Flir K65)

    The code is based on the serial number of the camera. To get the camera unique code, you must log in using a FLIR Customer Support account and register the camera. If you already have an existing FLIR Customer Support account, you can use the same login credentials.
  • Page 21 Starting the camera for the first time (FLIR K65) 5. To create a new FLIR Customer Support account, do the following: 5.1. Click Create a New Account. 5.2. Enter the required information and click Create Account. 6. On the camera, push the Mode button. This displays a dialog box. The serial number (S/N) of the camera is displayed at the top of the screen.
  • Page 22 Starting the camera for the first time (FLIR K65) 7. On the computer, enter the serial number of the camera and click Validate. 8. When the serial number is validated, click Continue. #T559946; r. BA/41926/41970; en-US...
  • Page 23 10. When the registration is completed, the four-digit code is displayed. Note • The code is also sent by e-mail to the address registered with your FLIR Customer Support account. • The code is also displayed in your FLIR Customer Support portal under My Stuff >...
  • Page 24 Starting the camera for the first time (FLIR K65) 11. On the camera, do the following to enter the code: • Push the Mode button repeatedly to change a digit. • Push the Zoom button to navigate to the next digit.

  • Page 25: Quick Start Guide

    Note Moving an image using a drag-and-drop operation does not delete the im- age in the camera. • Move the image to the computer using FLIR Tools. In FLIR Tools you can analyze the images and create PDF reports. Note The function of the trigger is configured by a setting in FLIR Tools, see section 12.14.2 The User interface tab, page 43.

  • Page 26: List Of Accessories And Services

    Tripod Adapter, Kxx T198457ACC USB cable Std A <-> Mini-B 1910423 Note FLIR Systems reserves the right to discontinue models, parts or accessories, and other items, or to change specifications at any time without prior notice. #T559946; r. BA/41926/41970; en-US...

  • Page 27: System Configuration Overview

    4. FLIR P/N: T198457ACC, Tripod Adapter, Kxx 5. FLIR P/N: T198125, Battery charger, incl. power supply with multi plugs 6. FLIR P/N: T198509, Cigarette lighter adapter kit, 12 VDC, 1.2 m/3.9 ft 7. FLIR P/N: T198310ACC, Li-Ion Battery pack 3.6 V 16 Wh 8.
  • Page 28 System configuration overview 9. FLIR P/N: T198322ACC, In-truck charger 10. FLIR P/N: T198441ACC, Transport case Kxx #T559946; r. BA/41926/41970; en-US...

  • Page 29: System Parts

    10.1 Camera (FLIR K45, FLIR K55) 10.1.1 Figure 10.1.2 Explanation 1. USB Mini-B connector: Connect to a computer to download images using FLIR Tools. 2. Attachment point for the lanyard strap/neck strap (left and right sides). 3. Eccentric latch to secure the battery.

  • Page 30: Camera (Flir K65)

    10.2 Camera (FLIR K65) 10.2.1 Figure 10.2.2 Explanation 1. USB Mini-B connector: Connect to a computer to download images using FLIR Tools. The USB Mini-B connector is protected by a plastic cover that is fastened with a Torx screw (T20).

  • Page 31: Lanyard Strap And Retractable Lanyard

    System parts 9. Trigger. 10. Mount for the tripod adapter. 11. Attachment point for the retractable lanyard. 12. Battery. 10.3 Lanyard strap and retractable lanyard 10.4 Handle strap and retractable lanyard #T559946; r. BA/41926/41970; en-US...

  • Page 32: Neck Strap

    System parts 10.5 Neck strap #T559946; r. BA/41926/41970; en-US...

  • Page 33: Screen Elements

    Screen elements 11.1 Figure 11.2 Explanation 1. Basic mode. A multipurpose mode for the initial fire attack with life-saving operations and control of the fire. 2. Black and white firefighting mode. A multipurpose mode for the initial fire attack with life-saving operations and control of the fire.

  • Page 34: Battery Condition Indicator

    Screen elements 9. Reference bar. 10. Temperature bar. 11. Spotmeter temperature. 12. Battery condition indicator. 13. Spotmeter. 14. Plus sign, indicating that the camera is not in Basic mode. Note • The green icon color indicates that the camera automatically switches between the high-sensitivity range and the low-sensitivity range, depending on the object.

  • Page 35: Operation

    Operation CAUTION Do not use the FLIR K series camera without the correct training. If the persons that operate the camera do not have the correct training, an incorrect analysis of the infrared images can occur. Thus, incorrect decisions during the firefighting can be made.

  • Page 36: Removing The Battery (Flir K65)

    Operation 12.2 Removing the battery (FLIR K65) 12.2.1 Procedure Follow this procedure: 1. Unscrew the Torx T20 screw and pull up the latch. CAUTION Make sure that you do not use a torque value that is more than 80 Ncm on the Torx T20 screw.

  • Page 37: Turning On And Turning Off The Camera

    Operation 12.4 Turning on and turning off the camera • Push the on/off button to turn on the camera. • Push and hold the on/off button for more than 3 seconds but less than 10 seconds to put the camera into standby mode. The camera then automatically turns off after 6 hours.

  • Page 38: Selecting Camera Modes

    Operation 12.5 Selecting camera modes 12.5.1 General The camera features five different camera modes. You select the camera mode by push- ing the Mode button. The five different camera modes are: 1. Basic mode. 2. Black and white firefighting mode. 3.

  • Page 39: Explanation Of The Different Camera Modes

    Operation 12.5.1.1.3 Explanation 1. LCD area. 2. Area activating the automatic range change. 12.5.2 Explanation of the different camera modes 12.5.2.1 Basic mode Figure 12.1 Basic mode. Basic mode is the default mode of the camera. It is a multipurpose mode for the initial fire attack with life-saving operations and control of the fire.
  • Page 40 Operation The camera automatically switches between the high-sensitivity range and the low-sen- sitivity range, to maintain an optimal infrared image. • Automatic range. • High-sensitivity range: –20 to +150°C (–4 to +302°F). • Low-sensitivity range: 0 to +650°C (+32 to +1202°F). 12.5.2.3 Fire mode Figure 12.3 Fire mode.
  • Page 41 Operation 12.5.2.5 Heat detection mode Figure 12.5 Heat detection mode. Heat detection mode is optimized for searching hotspots during overhaul after the fire is out—typically to ensure that there is no remaining hidden fire. This mode can also be used to find thermal patterns (e.g., signs of people in car seats after accidents), to en- sure that everyone has been found.

  • Page 42: Saving An Image

    12.6.2 Figure 12.6.3 Procedure Note The function of the trigger is configured by a setting in FLIR Tools, see section 12.14.2 The User interface tab, page 43. Follow this procedure: 1. Aim the camera toward an object of interest.

  • Page 43: Recording A Video Clip (Flir K55 And Flir K65)

    Follow this procedure: 1. Aim the camera toward an object of interest. 2. Depending on the Trigger button setting in FLIR Tools, do one of the following to start the recording: • With the Rec. on/off setting, pull the trigger.

  • Page 44: Continuous Video Recording (Flir K55 And Flir K65)

    You can configure the camera to start a continuous video recording when you turn on the camera. The recording cannot be stopped. Note The continuous video recording functionality is configured by a setting in FLIR Tools, see section 12.14.2 The User interface tab, page 43.

  • Page 45: Freezing The Image

    You can freeze the image. 12.9.2 Figure 12.9.3 Procedure Note The function of the trigger is configured by a setting in FLIR Tools, see section 12.14.2 The User interface tab, page 43. Follow this procedure: 1. Aim the camera toward an object of interest.

  • Page 46: Connecting The Camera To A Computer

    You can connect the camera to a computer, using the USB cable. Once connected, you can move the images from the camera’s archive to the computer. You can also import the images into the FLIR Tools software. A download card for FLIR Tools is included in the transport case.

  • Page 47: Procedure (Flir K65)

    Windows Explorer. Note Moving an image using a drag-and-drop operation does not delete the im- age in the camera. • Move the images to the computer using FLIR Tools. 12.10.3 Procedure (FLIR K65) Follow this procedure: 1. Fold up the rubber cover at the top of the camera.
  • Page 48 • Move the images to the computer using a drag-and-drop operation in Microsoft Windows Explorer. Note Moving an image using a drag-and-drop operation does not delete the im- age in the camera. • Move the images to the computer using FLIR Tools. #T559946; r. BA/41926/41970; en-US...

  • Page 49: Viewing Saved Images

    Operation 12.11 Viewing saved images 12.11.1 General When you save an image, the image is stored in the camera’s archive. To display the im- age again, you can recall it from the archive. 12.11.2 Procedure Follow this procedure: 1. Push the Mode and Zoom buttons at the same time. This displays the main menu. 2.

  • Page 50: Viewing Saved Video Clips

    Operation 12.12 Viewing saved video clips 12.12.1 General When you save a video clip, it is stored in the camera’s archive. To view the video clip, you can recall it from the archive. 12.12.2 Procedure Follow this procedure: 1. Push the Mode and Zoom buttons at the same time. This displays the main menu. 2.

  • Page 51: Changing Settings (In The Camera)

    Operation 12.13 Changing settings (in the camera) 12.13.1 General You can change a variety of settings. These settings include the following: • Temperature unit. • Temperature indication. • Date. • Time. • Factory default settings. 12.13.2 Procedure Follow this procedure: 1.
  • Page 52 12.13.2.1 Restore factory default settings You can restore all camera settings to the factory defaults. Note This will also restore settings that have been changed using FLIR Tools. Follow this procedure: 1. Push the Mode and Zoom buttons at the same time. This displays the main menu.

  • Page 53: Changing Settings (In Flir Tools)

    Operation 12.14 Changing settings (in FLIR Tools) 12.14.1 The General settings tab 12.14.1.1 Figure 12.14.1.2 Explanation Regional settings area: To synchronize the camera’s date and time settings with the com- puter, select the checkbox. Firmware info area: To check whether a newer version of the camera firmware exists, click Check for updates and follow the on-screen instructions.
  • Page 54 Nothing will happen when you press the trigger momentarily. • No action, Record video (not applicable to the FLIR K45): Select to make the camera start a recording when you press and hold the trigger. The recording will stop when you release the trigger.
  • Page 55 Operation the image will remain, with a static heat color reference bar displayed next to the tem- perature bar. Add custom boot image area: To select an image of your choice to appear during start- up, click Browse, and navigate to the image file. This is useful for, for example, identifying your fire department’s cameras.

  • Page 56: In-Truck Charger (Optional Accessory)

    The in-truck charger can also be powered using a standard FLIR Systems power supply, and has a battery charger located at the lower front of the unit.

  • Page 57: Choosing A Suitable Position

    3. Hole for attaching the charger housing to the metal bracket. 4. Connectors in the cradle. 5. Connector to power the charger using a standard FLIR Systems power supply. 6. Hole for attaching the charger housing to the metal bracket.

  • Page 58: Charging The Camera

    The charging of the camera has now started, and is finished when the blue light glows continuously. Charging a fully depleted camera takes approximately 4 hours. 13.7 Charging a battery separately FLIR Kx5 series batteries can be charged separately using the battery charger at the lower front of the unit. Follow this procedure: 1.

  • Page 59: Technical Data

    14.2 Note about technical data FLIR Systems reserves the right to change specifications at any time without prior notice. Please check http://support.flir.com for latest changes.

  • Page 60: Flir K45

    Easy-to-use—also in a gloved firefighter’s hand: An intuitive and simple user interface allows you to focus on the job. The FLIR K series can be controlled by just three large buttons on top of the unit. Ideal for a gloved firefighter’s hand.
  • Page 61 Image storage capacity 200 images Image storage mode IR only File formats Standard JPEG Image annotations Report generation Separate software (FLIR Tools) Video streaming Non-radiometric IR video streaming Uncompressed colorized video using USB USB Mini-B Compatibility Compatible with FLIR software FLIR Tools...
  • Page 62 Technical data Power system Start-up time from sleep mode < 4 s. Start-up time < 17 s. (IR image, no GUI) Environmental data Operating temperature range • –20°C to +85°C (–4°F to +185°F) • +150°C (+302°F): 15 min. • +260°C (+500°F): 5 min. Storage temperature range –40°C to +85°C (–40°F to +185°F) Humidity (operating and storage)
  • Page 63 Technical data Shipping information Packaging, size 500 × 190 × 370 mm (19.7 × 7.5 × 14.6 in.) EAN-13 4743254002005 845188010898 UPC-12 Country of origin Estonia Supplies and accessories: • 1910423; USB cable Std A <-> Mini-B • T198509; Cigarette lighter adapter kit, 12 VDC, 1.2 m/3.9 ft. •...

  • Page 64: Flir K55

    Easy-to-use—also in a gloved firefighter’s hand: An intuitive and simple user interface allows you to focus on the job. The FLIR K series can be controlled by just three large buttons on top of the unit. Ideal for a gloved firefighter’s hand.
  • Page 65 IR only File formats Standard JPEG Image annotations Report generation Separate software (FLIR Tools) Video recording in camera Non-radiometric IR video recording MPEG-4 to internal flash memory Storage capacity 200 files in total, with a maximum duration of 5 mi- nutes each.
  • Page 66 Technical data Power system Battery type Li Ion Battery voltage 3.6 V Battery capacity 4.4 Ah, at +20°C to +25°C (+68°F to +77°F) Battery operating time Approx. 4 hours at +25°C (+77°F) ambient tem- perature and typical use Charging system •...
  • Page 67 Technical data Physical data Tripod mounting UNC ¼"-20 (adapter needed) Material • PPSU • Silicon rubber • Aluminium, cast • Flame-resistant magnesium alloy Shipping information List of contents • Infrared camera • Battery (2 ea.) • Battery charger • Hard transport case •...

  • Page 68: Flir K65

    Easy-to-use—also in a gloved firefighter’s hand: An intuitive and simple user interface allows you to focus on the job. The FLIR K series can be controlled by just three large buttons on top of the unit. Ideal for a gloved firefighter’s hand.
  • Page 69 IR only File formats Standard JPEG Image annotations Report generation Separate software (FLIR Tools) Video recording in camera Non-radiometric IR video recording MPEG-4 to internal flash memory Storage capacity 200 files in total, with a maximum duration of 5 mi- nutes each.
  • Page 70 Technical data Compatibility Compatible with FLIR software FLIR Tools Data communication interfaces Interfaces • Update from PC devices • Data transfer to and from PC Power system Battery type Li Ion Battery voltage 3.6 V Battery capacity 4.4 Ah, at +20°C to +25°C (+68°F to +77°F) Battery operating time Approx.
  • Page 71 • T198457ACC; Tripod Adapter, Kxx • T198441ACC; Transport case Kxx • T911309ACC; Screwdriver TX20 • T198322ACC; In-truck charger • T199398; FLIR K65 accessory kit • T199368ACC; Battery Li-ion 3.6 V, 4.4 Ah, 16 Wh • T129915ACC; Carabiner strap #T559946; r. BA/41926/41970; en-US...

  • Page 72: In-Truck Charger

    3.2 kg (7.0 lb.) Packaging, size 435 × 245 × 167 mm (17.1 × 9.6 × 6.6 in.) EAN-13 7332558005446 4743254001282 (Estonia plant) UPC-12 845188005368 Country of origin Estonia Compatible with the following products • 72201-0106; FLIR K45 #T559946; r. BA/41926/41970; en-US...
  • Page 73 Technical data • 72201-0206; FLIR K55 • 72202-0303; FLIR K65 #T559946; r. BA/41926/41970; en-US...

  • Page 74: Mechanical Drawings

    Mechanical drawings [See next page] #T559946; r. BA/41926/41970; en-US...
  • Page 77 6,02 7,08 ±0,04 ±0,04 ±1 ±1 Mounting hole 10x ø5,0 Mounting hole 6x ø6,3 Konstr/Drawn Datum/Date Kontr/Check Material P. MARCUS 2013-04-08 MABR Ytjämnhet/Roughness Ytbehandling/Surface treatment Ändrad av/Modified by Ändrad/Modified P. MARCUS 2013-04-08 µm Skala/Scale Blad/Sheet Där ej annat anges/Unless otherwise stated Benämning/Denomination 1(1) ISO 2768-mK...

  • Page 78: Ce Declaration Of Conformity

    CE Declaration of conformity [See next page] #T559946; r. BA/41926/41970; en-US...

  • Page 80: Cleaning, Decontamination And Disinfection

    Cleaning, decontamination and disinfection 17.1 Cleaning 17.1.1 Camera housing, cables, and other items 17.1.1.1 Liquids Use one of these liquids: • Warm water • A weak detergent solution 17.1.1.2 Equipment A soft cloth 17.1.1.3 Procedure Follow this procedure: 1. Soak the cloth in the liquid. 2.

  • Page 81: Decontamination And Disinfection

    Such residues include—but are not limited to—chemical fire-extinguishing com- pounds, radioactivity, biohazardous materials, and residues from chemical fires. • FLIR Systems reserves the right to charge the full cost for the decontamination and disinfection of contaminated cameras that are shipped to our service department.

  • Page 82: Maintenance, Inspection, And Service

    5. Verify the function of all buttons and triggers. 6. Inspect the attachment point for the lanyard strap/neck strap, and the attachment point for the retractable lanyard. 18.3 Service For contact details to our service departments, use the following link: http://support.flir.com/service #T559946; r. BA/41926/41970; en-US...

  • Page 83: Storage Conditions

    Storage conditions The following storage conditions apply. Storage temperature range –40°C to +85°C (–40°F to +185°F) Storage humidity IEC 60068-2-30/24 h 95% relative humidity +25°C to +40°C (+77°F to +104°F) / 2 cycles #T559946; r. BA/41926/41970; en-US...

  • Page 84: About Flir Systems

    • Prox Dynamics (2016) Figure 20.1 Patent documents from the early 1960s FLIR Systems has three manufacturing plants in the United States (Portland, OR, Bos- ton, MA, Santa Barbara, CA) and one in Sweden (Stockholm). Since 2007 there is also a manufacturing plant in Tallinn, Estonia.

  • Page 85: More Than Just An Infrared Camera

    20.1 More than just an infrared camera At FLIR Systems we recognize that our job is to go beyond just producing the best infra- red camera systems. We are committed to enabling all users of our infrared camera sys- tems to work more productively by providing them with the most powerful camera–...

  • Page 86: Supporting Our Customers

    About FLIR Systems 20.3 Supporting our customers FLIR Systems operates a worldwide service network to keep your camera running at all times. If you discover a problem with your camera, local service centers have all the equipment and expertise to solve it within the shortest possible time. Therefore, there is no need to send your camera to the other side of the world or to talk to someone who does not speak your language.

  • Page 87: History Of Infrared Technology

    History of infrared technology Before the year 1800, the existence of the infrared portion of the electromagnetic spec- trum wasn't even suspected. The original significance of the infrared spectrum, or simply ‘the infrared’ as it is often called, as a form of heat radiation is perhaps less obvious to- day than it was at the time of its discovery by Herschel in 1800.
  • Page 88 History of infrared technology When Herschel revealed his discovery, he referred to this new portion of the electromag- netic spectrum as the ‘thermometrical spectrum’. The radiation itself he sometimes re- ferred to as ‘dark heat’, or simply ‘the invisible rays’. Ironically, and contrary to popular opinion, it wasn't Herschel who originated the term ‘infrared’.
  • Page 89 History of infrared technology Figure 21.4 Samuel P. Langley (1834–1906) The improvement of infrared-detector sensitivity progressed slowly. Another major break- through, made by Langley in 1880, was the invention of the bolometer. This consisted of a thin blackened strip of platinum connected in one arm of a Wheatstone bridge circuit upon which the infrared radiation was focused and to which a sensitive galvanometer re- sponded.
  • Page 90 A note on the technical production of this publication This publication was produced using XML — the eXtensible Markup Language. For more information about XML, please visit http://www.w3.org/XML/ A note on the typeface used in this publication This publication was typeset using Linotype Helvetica™ World. Helvetica™ was designed by Max Miedinger (1910–1980) LOEF (List Of Effective Files) T501016.xml;...
  • Page 92 Disclaimer Specifications subject to change without further notice. Models and accessories subject to regional market considerations. License procedures may apply. Products described herein may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Publ. No.: T559946...
