Pin Signal name
1 AIN0 +
2 AGND
3 AIN0 -
4 AGND
5 AIN1 +
6 AGND
7 AIN1 -
8 AGND
9 AIN2 +
10 AGND
11 AIN2 -
12 AGND
13 AIN3 +
14 AGND
15 AIN3 -
16 AGND
17 empty
18 +5V
19 GND
20 DIO0
21 DIO1
22 DIO2
23 DIO3
24 DIO4
25 DIO5
26 DIO6
27 DIO7
28 GND
Table 18. Differential mode pinout
Pin Signal name
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
23
AOUT0
AOUT1
AGND
NC
NC
AGND
AICKI
AICKO
AOCKI
AOCKO
TRIG
GND
CTR0
CTR1
TMR
GND
empty
+5V
GND
DIO8
DIO9
DIO10
DIO11
DIO12
DIO13
DIO14
DIO15
GND
