  • Page 1 User Manual of Product 1: Zojirushi 586361-CV-DCC40XT America Corporation Ve Hybrid Water Boiler And Warmer, 4-Liter, Stainless Dark Brown User Manual of Product 2: Zojirushi NS-TSC18 Micom Rice Cooker and Warmer, 10-Cups...
  • Page 2 MODEL N° 71524 OWNER’S MANUAL OWNER’S MANUAL Keep this Product ID Number and use when contacting Customer Service:...
  • Page 3 REGISTER YOUR PRODUCT ONLINE AT WWW.LIFETIME.COM At Lifetime, we are committed to providing innovative and quality products. While registering, you will have the opportunity to give us your feedback. Your input is valuable to us. Lifetime’s Promise to You: Maintaining your privacy is our long-standing policy at Lifetime. And you can rest assured that REGISTER today! Save this owner’s manual for future reference and in the event that...

  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS DAMAGE AND WILL VOID WARRANTY. materials for parts and/or additional instruction material. Before beginning assembly, Proper and complete assembly, use and supervision sections to separate during play or transport. Most injuries are caused by misuse and/or not following instructions. Use caution when using this product. BEFORE BEGINNING ASSEMBLY are missing, call our Customer Service Department.
  • Page 5 TOOLS AND PARTS REQUIRED FOR THIS ASSEMBLY 1/2” Wrench 7/16” Wrench 9/16” Wrench 3/4” Wrench Phillips Screwdriver 1/2” Socket Wrench Rubber Mallet Electric Drill Pliers 3/16” Allen Wrench (2, included) Water Hose Sand Scrap Wood (375 lb) *Two adults required to complete assembly* Only adults should set up the product.
  • Page 6 ASSEMBLY GUIDES Refer to the following areas throughout the instructions to assist in the assembly process: This area is located at the top, TOOLS AND HARDWARE REQUIRED FOR THIS PAGE left-hand corner of the page and indicates which tools and hardware are needed to complete the assembly steps on a page.

  • Page 7: Parts List

    PARTS LIST Item Description Top Pole Middle Pole Bottom Pole Pole Cap Rim Cover Plate Plastic Guard Gas Spring ” 1/2” Base Wheel Base Cap Pole Brace Left Frame Pad Right Frame Pad Center Frame Pad Handle Trigger Zip Tie Rear Lifter Arm Pole Pad HARDWARE LIST...
  • Page 8 HARDWARE LIST Item Description Pole to Base Assembly Hardware 1/4” Barrel Nut 5/16” Washer 3/16” Allen Wrench Backboard & Rim Assembly Hardware 3/8” Push Nut 4.86” U-Bolt Compression Spring Spring Retainer Plate 5/16” Jam Nut Backboard to Pole Assembly Hardware Handle Assembly Hardware Cotter Pin Clevis Pin...

  • Page 9: Parts Identifier

    PARTS IDENTIFIER Parts shown at 10% of Actual Size ” Top Pole ” Middle Pole ” Handle Bottom Pole ” ” 34 1/8” Pole Brace 31” Left Frame Pad Rear Lifter Arm Center Frame Pad Trigger Right Frame Pad ” Gas Spring...
  • Page 10 PARTS IDENTIFIER Parts shown at 10% of Actual Size Parts shown at 5% of Actual Size Pole Pad Base...
  • Page 11 PARTS IDENTIFIER Parts shown at 25% of Actual Size Pole Cap Base Cap Wheel Zip Tie Plastic Guard Rim Cover Plate...

  • Page 12: Hardware Identifier

    HARDWARE IDENTIFIER POLE ASSEMBLY HARDWARE Hardware shown at Actual Size 3/8” Washer Washer POLE TO BASE ASSEMBLY HARDWARE Hardware shown at Actual Size 5/16” Washer 3/16” Allen Wrench...
  • Page 13 HARDWARE IDENTIFIER BACKBOARD TO RIM ASSEMBLY HARDWARE Hardware shown at Actual Size 3/8” Push Nut 5/16”Jam Nut Hardware shown at 25% of Actual Size 4.86” U-Bolt Compression Spring Spring Retainer Plate...
  • Page 14 HARDWARE IDENTIFIER BACKBOARD TO POLE ASSEMBLY HARDWARE Hardware shown at Actual Size 7 1/16” (Not actual length) HANDLE ASSEMBLY HARDWARE Hardware shown at Actual Size Release Pin 7 1/16” Clevis Pin (Not actual length) Cotter Pin 6 1/2” (Not actual length)
  • Page 15 HARDWARE IDENTIFIER HANDLE ASSEMBLY HARDWARE (CONTINUED) Hardware shown at Actual Size 6 1/2” (Not actual length) Note: The 5/16” x 2 1/2” Hex Bolt (ACX) and the 5/16” Nylock Nut (AAO) will not be used in this assembly. Hardware shown at Actual Size...

  • Page 16: Pole Assembly

    POLE ASSEMBLY HARDWARE REQUIRED Hardware shown at Actual Size 3/8” Washer...

  • Page 17: Parts Required

    POLE ASSEMBLY PARTS REQUIRED Parts shown at 10% of Actual Size ” Top Pole ” Middle Pole ” Bottom Pole Part shown at 25% of Actual Size TOOLS REQUIRED 9/16” Wrench Phillips Screwdriver Electric Drill Scrap Wood...
  • Page 18 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Insert the 3/8” x 4” Hex Bolts (ABE) into the Top Pole (ALH) 1/2” x 3.41” Spacers (ABR) onto the Large holes Small holes...
  • Page 19 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 9/16" Place the Pole Bracket (ALL) onto the 3/8” x 4” Hex Bolts (ABE), and attach it to the Top Pole (ALH)
  • Page 20 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Align the hole in the Top Pole (ALH) slide the Top Pole over the Middle Pole. Insert a 1/4” x 3/4” Screw (ADS) through the small hole in the Top Pole and into the slot in the Middle Pole Warning Sticker Note: The 1/4”...
  • Page 21 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Align the hole in the Bottom Pole (ALE) and slide the Middle Pole over the Bottom Pole. Insert a 1/4” x 3/4” Screw (ADS) through the small hole in the Middle Pole and into the slot in the Bottom Note: The 1/4”...
  • Page 22 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE ATTENTION: THIS STEP CANNOT BE REVERSED! the Poles cover the slots before seating has occurred. If the do not completely cover the slots on the after seating, DO NOT COMPLETE ASSEMBLY. Call our Customer Service Department. WARNING The Poles must be seated together! Even if the Poles cover the slots before seating, they must be struck on a hard...
  • Page 23 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE #14 x 1”Self-Tapping Screws (ABZ) Note: Chuck the #14 x 1” Self-Tapping Screw directly into an Electric Drill for easy installation, or use a 3/8” Hex Driver.
  • Page 24 POLE TO BASE ASSEMBLY HARDWARE REQUIRED Hardware shown at Actual Size 1/4” Barrel Nut 5/16” Washer PARTS REQUIRED Part shown at 5% of Actual Size Parts shown at 25% of Actual Size Wheel Base Base Cap Parts shown at 10% of Actual Size ”...
  • Page 25 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE onto the Rubber Gasket Note: Make sure the Rubber Gasket is inside the Base Cap. Slide the through one of the Wheels (AMU) and into Bottom Pole (ALE) the other side of the Base and through the other Wheel. Note: It may be necessary to use a Rubber Mallet to tap the Axle into place.
  • Page 26 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2" 3/16" Attach the fl attened end of the Pole Brace (ALI) to the Note: Repeat this step to install the other Pole Brace to the other side of the Base. Attach the Pole Braces (ALI) to the Bottom Pole (ALE) Note: Tip the system backward so the Pole rests on the ground.
  • Page 27 BACKBOARD TO RIM ASSEMBLY HARDWARE REQUIRED Hardware shown at Actual Size 5/16”Jam Nut 3/8” Push Nut Flange Nut Hardware shown at 25% of Actual Size 4.86” U-Bolt Compression Spring Spring Retainer Plate...
  • Page 28 BACKBOARD TO RIM ASSEMBLY PARTS REQUIRED Part shown at 5% of Actual Size Parts shown at 10% of Actual Size Parts shown at 25% of Actual Size Plastic Guard Rim Cover Plate TOOLS REQUIRED 1/2” Socket Wrench 1/2” Wrench 7/16” Wrench Phillips Screwdriver...
  • Page 29 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 7/16” (Not to scale) Slide the 4.86” U-Bolt (BNP) through the Notch 1/4” x 2 3/4” Hex Bolts (AAS) 1/2” x 2 5/16” Galvanized Spacers (ABS) 1/4” Centerlock Nuts (AAB). Note: Tighten the hardware securely now.
  • Page 30 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” (Not to scale) (Not to scale) 5/16” x 2” Carriage Bolts (AAR) through the Rim Pivot Bracket (APY) 3/8” Push Nut (AAQ) onto one end of the 3/8” x 5 1/2” Axle (ABQ). Note: The Push Nut should rest about 1/4”...
  • Page 31 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” Slide the end of the 3/8” x 5 1/2” Axle (ABQ) through the Rim (ALX) and the Rim Pivot Bracket (APY). Press the Push Nut (AAQ) onto the end of the Insert the 4.86” U-Bolt (BNP) through the upper part of the opening on the...
  • Page 32 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” Connect the Rim (ALX) and Plastic Guard (ALD) to the .38” x 1” Steel Spacers (ACS) onto the 5/16” x 2” Carriage Bolts (AAR), and secure the onto the bolts. Underside View Thread the 4.86”...
  • Page 33 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” (Not to scale) (Not to scale) Slide the onto the 4.86” U-Bolt (BNP), and place the Spring Retainer Plate (AOW) over the Compression Springs. Tighten the until the Rim (ALX) does not Note: DO NOT COMPLETELY TIGHTEN THE 5/16”...
  • Page 34 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” Slide a 5/16” x 1 1/4” Carriage Bolt (ABC) into 3.11 the crimped slot in each the 5/16” x 1 1/4” Carriage Bolts (ABC) 3.12 Note: Tighten the 5/16” Nylock Flange Nuts (ABK) until they are fl ush with the ends of the Bolts.
  • Page 35 BACKBOARD TO POLE ASSEMBLY HARDWARE REQUIRED Hardware shown at Actual Size 7 1/16” (Not actual length) PARTS REQUIRED Parts shown at 10% of Actual Size ” ” Part shown at 25% of Actual Size Pole Cap TOOLS REQUIRED 3/4” Wrench Rubber Mallet...
  • Page 36 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 7 1/16” 3/4” (Not actual length) Secure the Short Extension Arms (AKC) Note: Tighten the 1/2” Centerlock Nut (AAX) until it is fl ush with the end of the Bolt.
  • Page 37 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 7 1/16” 3/4” (Not actual length) Secure the ends of the Long Extension Arms (AKB) that only have one Note: Tighten the 1/2” Centerlock Nut (AAX) until it is fl ush with the end of the Bolt.
  • Page 38 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 7 1/16” 3/4” (Not actual length) CAUTION: HAVE ONE ADULT HOLD THE BACKBOARD IN PLACE UNTIL ASSEMBLY HAS BEEN COMPLETED! Rim on cardboard to prevent scratching. Then secure the Long Extension Arms (AKB) to the Top Pole (ALH)
  • Page 39 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 7 1/16” 3/4” (Not actual length) Secure the Short Extension Arms (AKC) to the Top Pole (ALH) in the assembly.
  • Page 40 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Insert the Pole Cap (ALM) into the end of the Top Pole (ALH).

  • Page 41: Handle Assembly

    HANDLE ASSEMBLY HARDWARE REQUIRED Hardware shown at Actual Size Release Pin ACX* 7 1/16” Clevis Pin (Not actual length) Cotter Pin 6 1/2” AAO* (Not actual length) 6 1/2” (Not actual length) Note: The 5/16” x 2 1/2” Hex Bolt (ACX) and the 5/16” Nylock Nut (AAO) will not be used in this assembly.
  • Page 42 HANDLE ASSEMBLY PARTS REQUIRED Parts shown at 10% of Actual Size 31” Rear Lifter Arm Handle Gas Spring Trigger Parts shown at 25% of Actual Size Zip Tie TOOLS REQUIRED 9/16" Wrench 3/4" Wrench Pliers...
  • Page 43 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Remove the protective fabric from the ), and assemble 1/2 inch from the top of the Spring. Note: Use Pliers to tighten the Zip Ties (AMX) securely, then cut off the ends of the Zip Ties. Attach the Gas Spring assembly to the Pole Bracket (ALL) Cotter Pin (AAH) once it has been inserted into the Clevis Pin (AAI).
  • Page 44 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 6 1/2” 9/16” (Not actual length) Position the Trigger (AMN) inside of the Handle (AKI) Note: Tighten the 3/8” Centerlock Nut (ABB) until it is fl ush with the end of the Bolt. Place the Height Sticker (AKP) on the Top Pole (ALH) indicated.
  • Page 45 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 6 1/2” 3/4” (Not actual length) Insert the Release Pin (AQE) through the Slide the Handle (AKI) under the so that the Release Pin (AQE) rests in the channels of the Trigger (AMN). Position the Rear Lifter Arms (ALS) Note: Tighten the 1/2”...
  • Page 46 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 6 1/2” 9/16” (Not actual length) Secure the Handle (AKI) to the 3/8” x 1/2” Spacers (ABM)
  • Page 47 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 3/4” 7 1/16” (Not actual length) Connect the Rear Lifter Arms (ALS) to the inside of the Long Extension Arms (AKB) .62” x 3.20” Spacer (ABT) WARNING The Handle mechanism is designed to lift only the weight of the Backboard and Rim.
  • Page 48 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Apply grease from the Grease Packet (AKH) on to the Release Pin (AQE).
  • Page 49 HARDWARE REQUIRED Hardware shown at Actual Size PARTS REQUIRED Parts shown at 10% of Actual Size Left Frame Pad Right Frame Pad Bottom Frame Pad Part shown at 5% of Actual Size Pole Pad TOOLS REQUIRED Sand (375 lb) Electric Drill Water Hose...
  • Page 50 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE , and attach the Left ADP ADP...
  • Page 51 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Attach the to the in the locations...
  • Page 52 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE (375 lb) Two adults are required to complete assembly. To prevent serious injuries, the Pole should be held down by one adult at all times while the Base is being fi lled. (375 lb of sand required) a.
  • Page 53 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Two adults are required to complete assembly. To prevent serious injuries, the Pole should be held down by one adult at all times while the Base is being fi lled. algae formation. up on a smooth surface.
  • Page 54 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Attach Net (AKZ) to the Rim (ALX). Note: If a replacement Net is needed, please call our Customer Service Department. Our Nets are shorter than average to reduce the risk of entanglement. Attach the Pole Pad (ALN)

  • Page 55: Moving The System

    OPERATION OF HEIGHT ADJUSTMENT SYSTEM To Adjust the Height of the Hoop: MOVING THE SYSTEM WARNING: The system must only be moved by people capable of b. Stand in front of the system and pull on the Pole until the unit is balanced on its Wheels.
  • Page 56 NOTES...
  • Page 57 NOTES...
  • Page 58 NOTES...
  • Page 59 ® ENHANCE YOUR LIFETIME PURCHASE BY ADDING ACCESSORIES OR OTHER GREAT PRODUCTS: To purchase accessories or other Lifetime Products, visit us at: www.lifetime.com Or call: 1-800-424-3865...
  • Page 60 No cuelgue nada de la mécanisme a été conçu uniquement pour soutenir le poids du panneau et de sous peine d’endommager l’équipement et d’annuler la garantie. www.lifetime.com 10/12/2004...

  • Page 61: Warranty Information

    In addition, defects resulting from intentional damage, negligence, unreasonable use or this policy. 5. This product is not intended for institutional or commercial use; Lifetime Products, Inc. does not assume state to state. ALL WARRANTY CLAIMS MUST BE ACCOMPANIED BY A SALES RECEIPT.
