KORE BEDFRAME 120CM ASSEMBLY INSTRUCTIONS
Thank you for purchasing the KORE BEDFRAME 120CM.
Please read the instructions carefully to ensure safe operation of the product.
1900mm×1200mm×253mm 4ft
SMALL DOUBLE
PLEASE READ this sheet prior to assembly to familiarise yourself with the various stages of construction.
Carefully open the pack supplied and check the contents against the parts and fittings check list.
Do not destroy any of the packaging until you are certain that you have all the necessary parts
for the assembly.
CAUTION:There are small components used in the construction of this unit.These loose items should
be kept away from young children whilst assembling your unit to avoid the danger of choking hazards.
Tools Required
15Minutes
x2
Set Up
4mm Allen key x 2
V2 1/23
Page 1 of 10
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for GFW KORE BEDFRAME 120CM
Summary of Contents for GFW KORE BEDFRAME 120CM
- Page 1 KORE BEDFRAME 120CM ASSEMBLY INSTRUCTIONS Thank you for purchasing the KORE BEDFRAME 120CM. Please read the instructions carefully to ensure safe operation of the product. 1900mm×1200mm×253mm 4ft SMALL DOUBLE PLEASE READ this sheet prior to assembly to familiarise yourself with the various stages of construction.
-
Page 2: Care Information
KORE BEDFRAME 120CM ASSEMBLY INSTRUCTIONS IMPORTANT - READ CAREFULLY - RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE. INFORMATION This product is intended for a maximum person’s weight of 110kg per side. Do not exceed • this weight. Due to the size of this product we recommend that it is assembled in the room intended for use. - Page 3 KORE BEDFRAME 120CM ASSEMBLY INSTRUCTIONS Please check the pack contents before assembling the product.If any components are missing,please contact your retailer.The fittings pack contains small items that should be kept away from small children. (NOT TO SCALE) V2 1/23 Page 3 of 10...
- Page 4 KORE BEDFRAME 120CM ASSEMBLY INSTRUCTIONS Parts (NOT TO SCALE) END RAILS ADJUSTABLE CENTRE FEET SIDE RAIL CENTRE SUPPORT FEET 2PCS 2PCS 3PCS Dimension: 1200*253*25mm Dimension: 30*20*20mm Dimension: 922*120*50mm Dimension: 645*120*80mm CENTRE SUPPORT RAIL SLATS ADHESIVE RUBBER ANTI SLIP PADS 2PCS...
- Page 5 KORE BEDFRAME 120CM ASSEMBLY INSTRUCTIONS Fixings (to scale) Dimensions Bolt-M6x15 Bolt-M6x40 Bolt-M6x25 ''T''Nut- Ø 6x16 Flat Washer- Ø 6x16 (Not to scale) 4mm Allen Key CAUTION: There are many small components used in the construction of this product. Please keep these components away from young children whilst assembling this product .
- Page 6 KORE BEDFRAME 120CM ASSEMBLY INSTRUCTIONS Layout Parts on Soft Surface Lay out all 4 sides on a soft surface i.e. Rug, Carpet or Packaging Carton. V2 1/23 Page 6 of 10...
- Page 7 KORE BEDFRAME 120CM ASSEMBLY INSTRUCTIONS Step1 Parts Required End rails x 2 15mm M6 Bolt x 4 Flat washer x 4 4mm Allen key Step2 Parts Required side rail x 2 25mm M6 Bolt x4 ''T''Nut x 4 Flat washer x 4...
- Page 8 KORE BEDFRAME 120CM ASSEMBLY INSTRUCTIONS Step3 Parts Required Adjustable centre feet x 3 Centre support feet x 1 5 Centre support rail x 2 Step4 Parts Required End rails x 2 Side rail x 2 4 Centre support feet x 1...
- Page 9 KORE BEDFRAME 120CM ASSEMBLY INSTRUCTIONS Step5 Step6 V2 1/23 Page 9 of 10...
- Page 10 KORE BEDFRAME 120CM ASSEMBLY INSTRUCTIONS Step7 Parts Required Suitable for all types and depth of mattress. Keep instructions for future reference V2 1/23 Page 10 of 10...
