MIRRORED DRESSER & STOOL
ASSEMBLY INSTRUCTIONS
Thank you for purchasing the MIRRORED DRESSER & STOOL. Please read the
instructions carefully to ensure safe operation of the product.
W805 x D405 x H1300mm/Black,Ivory
PLEASE READ this sheet prior to assembly to familiarise yourself with the various stages of construction.
Carefully open the pack supplied and check the contents against the parts and fittings check list. Do not destroy
any of the packaging until you are certain that you have all the necessary parts for the assembly.
CAUTION: There are small components used in the construction of this unit. These loose items should be kept
away from young children whilst assembling your unit to avoid the danger of choking hazards.
Tools Required
Batch no.: WMI 14713
Page 1 of 7
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GFW MIRRORED
Summary of Contents for GFW MIRRORED
- Page 1 MIRRORED DRESSER & STOOL ASSEMBLY INSTRUCTIONS Thank you for purchasing the MIRRORED DRESSER & STOOL. Please read the instructions carefully to ensure safe operation of the product. W805 x D405 x H1300mm/Black,Ivory PLEASE READ this sheet prior to assembly to familiarise yourself with the various stages of construction.
- Page 2 MIRRORED DRESSER & STOOL ASSEMBLY INSTRUCTIONS IMPORTANT - READ CAREFULLY - RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE. INFORMATION Due to the size of this product we recommend that it is assembled in the room intended for use. When you are ready to start, make sure that you have the right tools, plenty of space and a clean, dry area for assembly.
- Page 3 MIRRORED DRESSER & STOOL ASSEMBLY INSTRUCTIONS Parts and Fittings Checklist Please check the pack contents before assembling this product. If any components are missing, please contact your retailer. The fittings pack contains small items that should be kept away from small children.
- Page 4 MIRRORED DRESSER & STOOL ASSEMBLY INSTRUCTIONS STEP 1 PARTS REQUIRED 1. Dresser Top x 2. Dresser Leg x B. Large Bolt x 8 F. Large Washer x G. 4mm Allen Key x 1 STEP 2 PARTS REQUIRED 4. Mirror Base Support x 1 5.
- Page 5 MIRRORED DRESSER & STOOL ASSEMBLY INSTRUCTIONS STEP 3 PARTS REQUIRED B. Large Bolt x 2 D. Barrel Nut x 2 E. Small Washer x 2 G. 4mm Allen Key x 1 Ensure the barrel nut is lined up with the bolt when fitting...
- Page 6 MIRRORED DRESSER & STOOL ASSEMBLY INSTRUCTIONS Parts (Stool) 1. SEAT – 1 Piece 2. LEG – 4 Pieces Fittings (Stool) Code Item Quantity Bolt (1/4”x50mm) Washer (5/16”x19x2.0mm) 4mm Allen Key STEP 1 PARTS REQUIRED 1. Seat x 1 2. Leg x 4 A.
- Page 7 MIRRORED DRESSER & STOOL ASSEMBLY INSTRUCTIONS COMPLETE Batch no.: WMI 14713 Page 7 of 7...
