Vitek VTC-C770/WDR Specifications

VTC-C770WDR
(Lens not included)
Lighting conditions play a critical role in producing useable video images in a surveillance
system. The VITEK VTC-C770WDR Surveillance Camera was created to meet and solve the
challenges brought on by varying lighting conditions within a single capture area. By use of the
PIXIM Seawolf Wide Dynamic Range DSP we are able to control and display clear crisp images
in varied lighting conditions more accurately than ever before. Its improved resolution of 700TV
Lines is unequaled by any other WDR Surveillance camera on the market. Advanced on screen
display and True ICR Day/Night function are among the many other features which place this
camera at the best in its class.
FEATURES
• Pixim D8800C Seawolf Digital Imaging System CMOS
• 700TVL High Resolution
• On Screen Display (OSD) Menu
• 3DNR - Three Dimensional Motion Adaptive Noise Reduction
• UTC CONTROL - Serial Control over Coax
• 0.00008 Lux (F1.2@40IRE using sense-up)
• Supports C/CS mount DC drive lenses
• Supports NTSC & PAL Standards
• 4:3 / 16:9 Ratio Scaled Video Output
• CRT / LCD Selectable Video Output Optimization
• 10 - bit ITU DSP
• 4 Metering Zones for WDR Optimization
• 24VAC (245mA / 5.88VA) & 12VDC (300mA / 3.6W)
WDR True Day and Night (ICR) Camera
Example of WDR:
Conventional Camera
Day
OSD Menu
Night
(888) VITEK-70 l www.vitekcctv.com
28492 Constellation Road Valencia CA 91355
VTC-C770WDR
3DNR
Supports
NTSC
PAL
Standards
