ZOLL Thermogard HQ Surface Setup Manual

ZOLL Circulation, Inc.

2000 Ringwood Ave

San Jose, CA 95131 USA

+1-877-225-7487

www.zoll.com

Thermogard HQ

Surface

Setup Guide

Equipment Checklist

Thermogard HQ



console

Thermogard HQ



Surface Start-Up Kit

STx™ Vest (S/M or L/XL)



Core temperature



probe

Temperature cable



106942-001 Rev 1

Sheet 1 of 2

Table of Contents

Need help?

Do you have a question about the Thermogard HQ Surface and is the answer not in the manual?

Page 1 Thermogard HQ  Surface Start-Up Kit STx™ Vest (S/M or L/XL)  Core temperature  probe Temperature cable  ZOLL Circulation, Inc. 2000 Ringwood Ave San Jose, CA 95131 USA Sheet 1 of 2 +1-877-225-7487 106942-001 Rev 1 www.zoll.com...
Page 2 Initiate Console POWER ON THE CONSOLE Plug in the console and turn on the power switch located on the lower rear of the unit. (figure 1.0) The console will take several minutes to complete self-tests. SELECT “COOLING” (figure 1.1) CHOOSE WHETHER NEW PATIENT Choose No if continuing a prior treatment.
Page 3 Set Up Tubing FILL RESERVOIR BAG Fill reservoir bag with water and fasten cap. Hang reservoir bag on console hook. (figure 2.0) INSERT COIL Open coolant well cap. Place coil in well. (figure 2.1) Close cap, passing tubes through slit in cap. PLACE AIR TRAP Place in stand with orange...
Page 4 Place Vest PLACE VEST UNDER PATIENT Place the vest under the patient. Do not secure the Velcro straps at this time. (figure 3.0) Note: The vest may be disconnected from the tubing while positioning it under the patient. CHECK VEST CONNECTIONS Ensure the vest is fully connected to the tubing.
