Keypad And Start Up; Menu; Program Pc-Timer; Clear Times (Clr) - ALGE-Timing Timy2 Manual

1

Keypad and Start Up

See TIMY2 Manual GENERAL
1.1

Menu

All standard menu settings are described in the general manual for the Timy 2.
2

Program PC-Timer

The Timy2 can form a very strong combination with the PC, i. e. the exact time comes form
the Timy2, the rest of the timing is carried out at the PC. In this program the Timy2 issues the
running time in 1/10 seconds interval. When an impulse is triggered, the daytime with its cor-
responding number (subsequent number or entered start number) and channel identification
is sent to the PC.
In case the program PC-Timer is selected, the following appears on the display:
TIME 12:34:56.7893
SYNC DATE 28-09-04
12:32:07.8
The Timy 2 now waits for the sync-impulse. When it is sent or manually triggered, the follow-
ing appears on the display:
SYNC DATE 28-09-04
TIME 12:34:56.7893
12:32:07.8
→→→ 0 1 2 3 4 5 6 7 8
With key F0 you can see the list of stopped times.
2.1

Clear Times (CLR)

In case a double impulse or false impulse was triggered, it can be cleared with
time that is to be cleared has to be in the last line. When the time is cleared, it is indicated by
a "c" on display and printout.
2.2

Edit Start Numbers (STN)

Select correct line and press
ber and confirm with either of the "OK" keys. The change line is indicated by an "n".
Manual
TIMY2 – PC-Timer
SYNC-time daytime – enter time or press OK
SYNC-time date – enter date or press OK
currently running daytime
synchronized date
synchronized time
currently running daytime
. The start number begins to blink. Correct the start num-
. The
Page 5
