Accessing the GPUs

To access the area of the GPUs, first remove the top front cover. Then remove the storage
drive housing.
Release Handles
Figure 3-2. Removing the Storage Drive Housing
1. Remove the top, front cover.
2. Lift the handles at both edges of the storage drive housing and lift out the housing.
