Summary of Contents for Fotric P Series
- Page 1 FOTRIC P-series Quick Start Manual...
- Page 2 I 丨 FOTRIC P-series Quick Start Manual Symbols For the symbols that appear in the documentation, the descriptions are listed below. Warning Caution Potential death or serious Potential danger of injury or injury inducing hazards property damage Safety information The purpose of this section is to ensure that the user uses the product properly to avoid danger or property damage.
- Page 3 FOTRIC P-series Quick Start Manual 丨 II • Thermal imaging cameras that use a laser pointer. Do not view the laser beam directly with the human eye. The laser beam can cause eye irritation. • If the unit is not working properly, contact your dealer or our...
- Page 4 III 丨 FOTRIC P-series Quick Start Manual • Avoid damage to the sensor caused by over-range use of the device. • It is strongly recommended to use the original power adapter, the specific requirements of the power adapter are shown in the product data sheet.
-
Page 5: Table Of Contents
Cautions ................14 Please read the manual before use ........16 Software activation and download ........17 Maintenance ................ 18 Appendix A ................19 Appendix B ................21 Warnings ................23 About this brochure ............24 How to contact FOTRIC ............26... -
Page 6: Thermal Imaging Camera
1 丨 FOTRIC P-series Quick Start Manual Thermal imaging camera Front view ① Speaker ⑤ Arrow keys ⑨ 5'' LCD screen ② AI key ⑥ Confirmation key ⑩ Battery ③ Indicator LED ⑦ Gallery button ⑪ Microphone ④ Power button ⑧... - Page 7 FOTRIC P-series Quick Start Manual 丨 2 Rear view ① AI key ⑥ Wrist band lower connection ② Manual focus ring ⑦ Freeze image and snapshot button ③ Laser key ⑧ Wrist band upper connection ④ Tripod fixing interface ⑨ Autofocus button ⑤...
- Page 8 3 丨 FOTRIC P-series Quick Start Manual Top view ① Thermal camera ② Digital camera ③ Flash light ④ Laser emitter ⑤ Laser ranger ⑥ View finder (Only available on specific models)
- Page 9 FOTRIC P-series Quick Start Manual 丨 4 Interface ① Charging port ② USB interface ③ HDMI interface ④ Battery ⑤ Thread hanger ⑥ SD memory card socket...
-
Page 10: Interface Introduction
5 丨 FOTRIC P-series Quick Start Manual Interface introduction Main interface ① Display battery, Wi-Fi, cellular network, Bluetooth, GPS, SD card capacity low, laser warning , Compass, time, Logo and other reminder icons. ② Displays global and area temperature, emissivity, area, length, and other values. - Page 11 FOTRIC P-series Quick Start Manual 丨 6 ④ Displays real-time thermal image, temperature measurement markers(ROIs) and target distance. ⑤ Enable users to adjust the temperature span/scale, temperature measurement parameters, image mode, ROIs, color palette and to summon settings menu. ⑥ Displays emissivity, reflected temperature, ambient...
- Page 12 7 丨 FOTRIC P-series Quick Start Manual System menu ① Select among automatic temperature span, manual temperature span, touch temperature span setting. ② Adjust emissivity, reflection temperature, ambient temperature, relative humidity, target distance, infrared window compensation factors. ③ Switch between infrared, visible light, picture-in-picture, and image fusion mode.
- Page 13 FOTRIC P-series Quick Start Manual 丨 8 ⑤ Apply various color palettes and inverse palettes, including color alarms (isotherms). ⑥ Change settings about capture mode, network connection, temperature measurement range, storage and save options, device settings, etc.
- Page 14 9 丨 FOTRIC P-series Quick Start Manual Gallery ① Displays the captured thermal image, visible light photo, full radiometric thermal video, non-radiometric videos. Short click to select, long press to multi-select; ② Display only images with the favorite toggle activated;...
- Page 15 FOTRIC P-series Quick Start Manual 丨 10 Settings ① Capture mode: switch between single-frame shooting, recording (radiometric or MPS), and time-lapse mode; ② Connection: WLAN, hotspot, Bluetooth, FTP transfer, and Network; ③ Temperature range: Switch among 3 different temperature ranges, can also enable intelligent range;...
- Page 16 11 丨 FOTRIC P-series Quick Start Manual display settings, geolocation, energy saving mode, manual span/ scale mode, volume, reset and camera information. ⑥ Optional function upgrades and plug-ins.
-
Page 17: Quick Start
(From here, users may either choose IRExplorer or AnalyzIR to conduct analysis on the thermal images. Detailed instructions for accessing IRExplorer are included in the 'Software activation and download' section) 10. Download the AnalyzIR software from 'https://www.fotric. - Page 18 13 丨 FOTRIC P-series Quick Start Manual com/fotric-analyzir'. 11. Install AnalyzIR and related drivers on the PC. 12. Start AnalyzIR professional analysis software. 13. Connect the camera to the computer using a Type-C USB cable or connect to the SD card with a reader.
-
Page 19: Cautions
FOTRIC P-series Quick Start Manual 丨 14 Cautions • It is very important to properly adjust the focus when taking the image. Poorly focused images will not only affect the thermal image clarity but also compromise the temperature measurement accuracy. - Page 20 15 丨 FOTRIC P-series Quick Start Manual • Please always select an area with high emissivity (e.g., an area with an unsmooth surface) for measurement if possible. • Shiny objects (and objects with low emissivity) may appear warm or cold in the thermal imaging camera because they are reflecting radiation from its vicinity.
-
Page 21: Please Read The Manual Before Use
FOTRIC P-series Quick Start Manual 丨 16 Please read the manual before Please visit the following website to read or download the brochure: https://www.fotric.com/support... -
Page 22: Software Activation And Download
17 丨 FOTRIC P-series Quick Start Manual Software activation and download IRExplorer: Go to Settings->Device Set->Plug-in manager->Service plugin- >IRExplorer->Turn on Network connection If the user is connecting with a device capable of scanning the QR code, open and scan the QR code either from 'IRExplorer' interface or from the swipe-down menu on the main interface. -
Page 23: Maintenance
FOTRIC P-series Quick Start Manual 丨 18 User Manual' on the same page. Maintenance • Temperature measuring equipment is recommended for temperature calibration measurement once every one to two years. • Pay attention to keep the lens clean, use a soft non-woven... - Page 24 19 丨 FOTRIC P-series Quick Start Manual Appendix A Emissivity Table （For reference only） Material Surface Temperature (℃） Emissivity (ε） Name Condition Non- oxidized Aluminum Oxidized 0.55 Polished brown Unpolished 0.22 Brass Oxidized 0.61 Severely Copper 0.78 oxidized Oxidized 0.74...
- Page 25 FOTRIC P-series Quick Start Manual 丨 20 Common Surface 0.93 brick Concrete Surface 0.92 Polished Glass 0.94 plate White 0.92 Lacquer Natural 0.97 color black Smoke 0.95 black Candle soot 0.95 Carbon Graphite rough 0.98 surface Average of Paint 0.94...
- Page 26 21 丨 FOTRIC P-series Quick Start Manual Appendix B Statement Federal Communications Commission (FCC) Declaration of Conformity Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
- Page 27 FOTRIC P-series Quick Start Manual 丨 22 compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The mobile device is designed to meet the requirements for exposure to radio waves established by the Federal Communications Commission (USA).
-
Page 28: Warnings
23 丨 FOTRIC P-series Quick Start Manual Warnings According to Article 10 (10) of Directive 2014/53/EU, the packaging shows that this radio equipment will be subject to some restrictions when placed on the market in Belgium (BE), Bulgaria (BG), the Czech Republic (CZ), Denmark (DK), Germany... -
Page 29: About This Brochure
The photographs, graphics, icons, and illustrations provided in this manual are for illustrative purposes only and may differ from the actual product. This manual may be updated by FOTRIC without prior notice due to product version upgrade or other needs. - Page 30 25 丨 FOTRIC P-series Quick Start Manual to risks including but not limited to network attacks, hacker attacks, virus infections, etc. The company will not be responsible for any abnormal work of the product, information leakage and other problems caused by this, but will provide technical support for you in a timely manner.
-
Page 31: How To Contact Fotric
FOTRIC P-series Quick Start Manual 丨 26 prevail. How to contact FOTRIC If you need to contact FOTRIC, please address the following... - Page 32 Warranty Card Thank you for choosing FOTRIC thermal imaging camera. We design products to deliver long-lasting performance under our warranty policy (starting from date of original purchase). If any manufacturing defects appear under normal use, the product will be repaired or replaced by...
- Page 33 This is to certify that the thermal imaging camera listed on this card meets the requirements of FOTRIC quality control procedures.
- Page 34 FOTRIC thermal cameras’ technical standards are formulated following the international standards for the industrial testing infrared thermal imager and the relevant standards cited therein, as listed below: FCC 47 CFR Part 15 Radio Frequency Devices EN 61326-1:2013 Electrical equipment for measurement, control and laboratory use - EMC requirements - Part 1: General requirements EN 301 489-1 V2.2.3:2019 Electro Magnetic Compatibility (EMC) standard...
- Page 35 Innovation Excellence Integrity Company Disclaimer Equipment described herein may require EU, US and UNSC authorization for export purposes. Imagery for illustration purposes only. Specifications are subject to change without notice. FOTRIC INC. © 2023 All Rights reserved. FOTRIC INC.
