  • Page 1 FOTRIC TD3-LD Quick Start Manual...
  • Page 2 Symbols Caution • Protect the acoustic sensor array from stains, dust, and liquids For the symbols that appear in the documentation, the that could affect the performance of the acoustic imaging descriptions are listed below. camera or even cause permanent damage. •...

  • Page 3: Table Of Contents

    FOTRIC TD3-LD Quick Start Manual 丨 1 Contents 1. Acoustic Imaging Camera 1.1 Front view 1. Acoustic Imaging Camera ........1 1.1 Front view ................... 1 1.2 Rear view ..................... 2 1.3 Side view ..................... 3 1.4 Top view ....................4 2.

  • Page 4: Rear View

    2 丨 FOTRIC TD3-LD Quick Start Manual FOTRIC TD3-LD Quick Start Manual 丨 3 1.2 Rear view 1.3 Side view Figure 3. Figure 2.

  • Page 5: Top View

    4 丨 FOTRIC TD3-LD Quick Start Manual FOTRIC TD3-LD Quick Start Manual 丨 5 2. Interface Introduction 1.4 Top view 2.1 Main interface Figure 4. Figure 5. ① Menu bar: Capture mode(Snapshot, Recording), Signal filter mode (single, multi, filter), Gallery ,...

  • Page 6: Save Interface

    6 丨 FOTRIC TD3-LD Quick Start Manual FOTRIC TD3-LD Quick Start Manual 丨 7 graph and allows specific frequency range selection and signal ① File name: displays the file name, which is editable by tapping analysis. to summon a virtual keyboard.

  • Page 7: Gallery

    8 丨 FOTRIC TD3-LD Quick Start Manual FOTRIC TD3-LD Quick Start Manual 丨 9 2.3 Gallery ⑤ Favorite: apply or undo the 'favorite' tag. ⑥ Text annotation: add, edit or delete text annotation; ⑦ Frequency spectrum: display or withdraw the frequency spectrum.

  • Page 8: Settings

    2. 'Save set': toggle the information that appears on exported to link to a PC and conduct software version upgrade. Detailed photos and videos. For detailed data export instruction, please software upgrade instruction is available at "www.fotric.com/ refer to section (2.3 ③ ); support-td3-acoustic-camera".

  • Page 9: Quick Start

    12 丨 FOTRIC TD3-LD Quick Start Manual FOTRIC TD3-LD Quick Start Manual 丨 13 3. Quick Start ⑦ Time: Set up the time for the software system. ⑧ System: the system interface records miscellaneous information about the camera, including the model name, current system...

  • Page 10: Operational Tips

    14 丨 FOTRIC TD3-LD Quick Start Manual FOTRIC TD3-LD Quick Start Manual 丨 15 4. Operational Tips 11. Start the SonicLab professional analysis software. 12. Copy the exported data to the PC with the accessory USB disk drive. 4.1 Frequency filtering The frequency spectrum on the right side of the screen displays 13.

  • Page 11: Gas Leakage Evaluation

    16 丨 FOTRIC TD3-LD Quick Start Manual FOTRIC TD3-LD Quick Start Manual 丨 17 4.2 Gas leakage evaluation The 'Evaluation' option within the display mode is accessible only after selecting ‘Leakage Mode.’ To initiate leakage detection mode, navigate to Settings ->...

  • Page 12: Partial Discharge Detection

    4.3 Partial discharge detection 4.4 Signal filter mode selection To engage the partial discharge detection mode, navigate to The TD3-LD features three signal filter options: Single, Multiple, Settings -> Detection , select 'Partial Discharge Mode'. and Filter. In this mode, the Phase Resolved Partial Discharge (PRPD) graph is 'Single' mode isolates and displays the strongest signal.

  • Page 13: About This Manual

    This manual may be updated by FOTRIC without notice due to product version upgrade or other needs. The trademarks and images used in this manual are for illustrative purposes only and are the copyright of the trademark owner.

  • Page 14: How To Contact Fotric

    If you need to contact FOTRIC, please address the following The product can sense motion detection and fire events under correct installation and configuration, but cannot avoid accidents or resulting personal injury or property damage.
  • Page 15 This is to certify that the device or instrument listed on this card meets the requirements of FOTRIC quality control procedures.
  • Page 16 E N 6 1 3 2 6 - 1 : 2 0 1 3 E l e c t r i c a l e q u i p m e n t f o r product will be repaired or replaced by FOTRIC INC. with m e a s u r e m e n t , c o n t r o l a n d l a b o r a t o r y u s e no cost to the owner.
  • Page 17 Innovation Excellence Integrity Company Disclaimer Equipment described herein may require EU, US and UNSC authorization for export purposes. Imagery for illustration purposes only. Specifications are subject to change without notice. FOTRIC INC. © 2024 All Rights reserved. FOTRIC INC.
