Page 2: Installation
1. Installation The product has the American Standard 1 / 4-20unc tripod interface (the upper part and the lower part have interfaces), which is convenient for customers to install; There are four cushions at the four corners of the bottom, which can be used for horizontal placement of products. -
Page 3: Quick Setup
2. Quick Setup 1. Connect the blackbody to the AC220V power supply and turn on the power switch. 2. The power indicator is on, and the display shows the default temperature of 35.0 ℃ , Set the blackbody temperature to 40 ℃ by adjusting the up and down buttons. After 5 minutes of preheating, the machine is stable and can be used normally. -
Page 4: Display Panel
3. Display panel 4. Matters needing attention 1. Please ensure the correct power input 2. Please do not touch the black target area to prevent scalding 3. It is better to use the product at room temperature of about 25 ℃ to ensure the accuracy of the equipment 4. -
Page 5: Product Parameters
5. Product parameters Blackbody AC100V~240V Working Voltage 260W Max Power Dissipation 0 ℃ ~+40 ℃ Working environment Temperature RT+5 ℃ ~100 ℃ Settable Temperature Calibration Temperature 35 ℃ ~40 ℃ Emissivity 0.97±0.02 Temperature Resolution 0.1 ℃ ≤5min Settling Time ±0.2 ℃ @36 ℃ Temperature Accuracy ±... - Page 6 FOTRIC INC. www.fotric.com info@fotric.com...
