Kverneland EO Operation Manual
  1. Manuals
  2. Brands
  3. Kverneland Manuals
  4. Farm Equipment
  5. EO
  6. Operation manual

Kverneland EO Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operation manual
Issue
Date printed
Language
From machine number (PSN)
Reference number
Original operation manual
EO/LO
2009
7.2014
EN
EO:, LO:
A133077740-EN-001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EO and is the answer not in the manual?

Questions and answers

Related Manuals for Kverneland EO

Summary of Contents for Kverneland EO

  • Page 1 EO/LO Operation manual Issue 2009 Date printed 7.2014 Language From machine number (PSN) EO:, LO: Reference number A133077740-EN-001 Original operation manual...
  • Page 2 +47 51 42 90 00 www.kvernelandgroup.com Kverneland Group Operations Norway AS retains all copyrights and rights of usage. The contents of this user manual may be changed without warning. All rights reserved. The publisher reserves the right to make technical revisions.

  • Page 3: Table Of Contents

    Undertaking modifications of the plough Tractor Turning direction EO-LO Remove paint Restrictor position Coupling ............ Spring for release system [EO] Safety Hydraulic release system [+] Coupling Switch pressure on the turnover valve Linkage geometry The position of the drag axle Clearance between the depth Parking and storage ........

  • Page 4: Preface

    • Turn with the bodies over: when turning, turn the bodies over the frame, while the depth wheel turns under the frame. • Turn with the bodies under: Not possible on the EO-LO.

  • Page 5: Safety

    Safety Safety This chapter contains general safety instructions for this product. Each chapter of the operating manual contains additional specific safety in- formation. Safety decals For your safety, safety decals are placed on important parts of the plough. Please do not remove them. If they become illegible or begin to peel off, replace them with the appropriate spare stickers.
  • Page 6 Safety Meaning The meaning of the safety decals is pointed out below. Read the operation manual and follow the instructions. The plough must only be used for the first time once the operating manual has been read and understood. Do not stand between the tractor and the plough Standing between the tractor and plough increases the risk of being crushed.

  • Page 7: General Safety Information

    Safety General safety Please read and ensure you understand the following general safety information. Specific safety information is pointed out in the relevant information chapters. General Read and ensure you understand the instructions Before starting to operate the plough, read the operating manual and follow the instructions.
  • Page 8 Safety Coupling Risk of injury when coupling There is an increased risk of injury when the plough is coupled to the tractor. Therefore: • Secure the tractor to prevent it from rolling • Do not stand between the tractor and plough when coupling •...
  • Page 9 Use only genuine Kverneland spare parts. Other products may ad- versely affect the correct operation of the plough and safety. The war- ranty will no longer be valid if parts not produced by Kverneland are used. Check the tyre pressure Regularly check to ensure the tyre pressure meets the requirements.

  • Page 10: Getting To Know The Plough

    The plough can only turn with the bodies over the frame. When the plough turns with the bodies over, it ensures the plough turns smoothly. EO-LO is an on-land model, and cannot turn with the bodies under the frame. Otherwise, the bodies will collide with the ground.

  • Page 11: Components

    Getting to know the plough Components General – EO Turning head Skimmer Front piece Disc coulter Auto-reset beam Parking stand Main frame Beam holder Depth wheel General – LO Turning head Shear bolt beam Front piece Main frame Parking stand...
  • Page 12 Getting to know the plough Turning head 300 Tower Turning cylinder Turning valve Drag axle Body Support Mouldboard Landside Shank Breast plate Point Share (This illustration shows body no. 9. Other types of bodies have similar components)

  • Page 13: Technical Specifications

    Getting to know the plough Technical specifications General 70/75 Auto 200x120 30-50 2200/ 6200/7700/ x6.3 2400/ 10300 2680 70/75 Auto 200x120 35-55 2200/ 6200/7700/ x6.3 2400/ 10300 2680 70/80 Shear 200x120 30-50 2000/ 5200/6200/ bolt X6.3 2200/ 8600 2400 70/80 Shear 200x120 35-55...

  • Page 14: Information Plate

    Getting to know the plough Information plate The information plate is located on the headstock. When ordering spare parts or consulting services, please state the full model code and plough ID, to avoid any mistakes or misunderstandings. Model Model Body distance Turning head QR head Plough ID...

  • Page 15: Optional Equipment

    Optional equipment Optional equipment This section gives an overview of the optional equipment for the EO/ LO plough. Limitations apply. Please contact your Kverneland dealer for more information. Skimmer Recommended for effective burial of residues on the field. Two types of skimmers are available - manure skimmers and maize skimmers.
  • Page 16 Optional equipment Landside knife An alternative to disc coulters, when reduction in weight may be nec- essary or when blockage from trash or stones is likely. Good in com- bination with skimmers, and fits in combination with all types of shares Eco share A share for working 10cm deeper than the plough's normal share and breaking up the topsoil.
  • Page 17 Optional equipment Quick-fit share Reduces the downtime when replacing the points. Can be fitted to all plough bodies. Very good ground penetration. Furrow splitter Designed for mounting to any part of the mouldboard, to cut through firm soil, making subsequent operations easier. The splitter is secured with a screw in the existing hole in the mouldboard.
  • Page 18 Optional equipment Wear plate Can be fitted on the landsides, to reduce wearing of the landsides. Fitted to the rear end of the landside as a usable wearing part. Depth and transport It is highly recommended that a depth wheel is used on all ploughs. A wide range of depth wheels is available for the plough.
  • Page 19 Hydraulic release As an alternative to the leaf spring construction, a hydraulic release, consisting of a single-acting cylinder, can be supplied (EO). The leaf spring is then equipped with a hydraulic cylinder which is connected to an accumulator used to regulate the pressure to ensure a release force suited to uneven ground conditions..

  • Page 20: Preparing For Operation

    Preparing for operation Preparing for operation This chapter will guide you through the preparations that must be made on the plough and tractor before you start operating the plough. Tractor Hydraulic connections The following chart shows the connections required on the tractor. Hydraulic functions Single-acting Double-acting...

  • Page 21: Remove Paint

    Preparing for operation Tyre pressure To avoid uneven furrows, the air pressure must be equal on both rear tyres of the tractor. Front weights Add sufficient front end weights to ensure safe driving. Drawbars Set both drawbars at the same height. This ensures equal levelling of the plough in both directions.

  • Page 22: Coupling

    Coupling Coupling This chapter explains how to secure the plough to the tractor. Safety Risk of injury when coupling There is an increased risk of injury when the plough is coupled to the tractor. Therefore: • Secure the tractor to prevent it from rolling. Apply the handbrake. •...

  • Page 23: Linkage Geometry

    Coupling Linkage geome- To ensure a stable first furrow width, the imaginary intersection of the lower links should be 1/3 of the axle distance behind the front axle. If this is not the case, replace the drag axle with another length. →...

  • Page 24: Driving On The Road

    Driving on the road Driving on the road This chapter explains how to drive safely on roads. Safety Stabilise lift rods During transport, stabilise the lift rods of the tractor. This will prevent the plough from accidentally moving sideways. Use the transport wheel If the plough is equipped with a depth/transport wheel, use it when driving on the road.

  • Page 25: Prior To Transport

    Driving on the road Prior to transport Prior to transport Remove soil and dirt from the plough Lift the plough carefully Stabilise the lower drawbars Adjust the plough to its narrowest working width Place the plough in transport position (see below) Stabilise the rotating drag axle [+] (see below) Mount the lights [+] →...

  • Page 26: Place In Transport Position

    Driving on the road Place in transport position Transport wheel for half- turned position Lift the plough 10 cm above the ground Raise the upper depth stop - to release it (A) Lift up Repeat this for the lower depth stop. Rotate the lock pin, so that the wheel can rotate 360°...
  • Page 27 Driving on the road Transport position Release the locking pin. Turn the plough carefully into butterfly position. Make sure the transport lock latches. Lower the plough until it rests on the transport wheel Disconnect the top link from the tower Transport position...
  • Page 28 Driving on the road Hydraulic depth wheel To change to transport position > Lift the plough slightly > Stabilise the lower links > Adjust the plough to it's narrowest working width Bolt and ring pin Release plate > Lift the wheel slightly. This eases removing of the bolt. Hole A >...

  • Page 29: Place In Ploughing Position

    Driving on the road Place in ploughing position Transport wheel for half-turned position Connect the top linkage to the tower Transport position Lift the plough fully. Deactivate the transport lock on the headstock Lock Turn the plough carefully into the ploughing position. Handle Turn the wheel Hole Y...
  • Page 30 Driving on the road Lift up the upper and lower lock pin to unlock the depth stops Rotate...
  • Page 31 Driving on the road Connect the top linkage to the tower Lift the plough fully. Transport position Deactivate the transport lock on the headstock Lock Turn the plough carefully into the ploughing position. Unlock Handle Bolt Hole Y > Remove the bolt from hole Z >...
  • Page 32 Driving on the road If the wheels must be moved from the ploughing position to the trans- port position, the following procedure must be followed to prevent any dangerous situations or damage caused by crushing, and heavy lift- ing. First raise the plough slightly, so that the wheel is free from the ground.
  • Page 33 Driving on the road NB! The plough is lowered gently until the transport wheels rest on the ground and the top linkage can be released from the plough. NB! Must always be uncoupled during transport. During transport, the plough must always be stabilised at the sides. Before driving, activate the on-land cylinder and furrow width cylinder at this point to ensure that the lowest possible centre of gravity is reached, and the correct angle is obtained on the wheel's vertical turning...

  • Page 34: Adjusting The Plough

    Adjusting the plough Adjusting the plough This chapter describes the plough adjustments required to obtain the desired ploughing result. You can make these adjustment before and during ploughing. Recommended working order We recommend you to use the following working order when adjusting the plough in the field Working width First furrow width...
  • Page 35 Adjust the working width on all beam holders. Use the spanner supplied. Adjust the lean of the turnbuckle in accordance with the table: »EO-LO incremental setting 85-100«, page 37. This figure shows hydraulic working width adjustment Hydraulic (ploughs with turning valve) Adjust the working width cylinders using the tractor's hydraulic out- let.

  • Page 36: First Furrow Width

    Adjusting the plough First furrow width Do not adjust when lifted Do not adjust the first furrow width when the plough is raised above the ground. This may result in damage or injury. In general, the first furrow should match the width of the other furrows. Please be aware of the following: •...
  • Page 37 Adjusting the plough This figure shows hydraulic first furrow adjust- Hydraulic ment Adjust the first furrow width cylinder using the tractor's hydraulic outlet. The furrow width is set using the front part of the cylinder, chamber (A). This cylinder is a master cylinder which is coupled to and controls a slave cylinder (C).
  • Page 38 Adjusting the plough Extra "On-land" If the tractor has twin wheels, belts or extra wide tyres, it may be a good idea to adjust the plough to extra long "on-land". This is done by first adjusting the furrow width to the minimum to ensure that the piston rod (B) is completely extended.
  • Page 39 Adjusting the plough EO-LO incremental setting 85-100 Settings for turnbuckle (A): “ “ 12” 14” 16” 16” 18” 18” 20”...

  • Page 40: Working Depth

    Adjusting the plough • Working depth The plough frame should always be parallel to the ground. • The top linkage should be in the centre of the slot. • After changing the working depth, make sure to check the side- ways levelling (see next paragraph) Incorrect adjustment Correct adjustment...
  • Page 41 Adjusting the plough Hydraulic adjustment of You adjust the working depth by operating the single acting cylinder the depth wheel > Operate the tractor’s spool valve. • Retract the cylinder to plough deeper • Extend the cylinder to plough shallower ! The scale indicates the ploughing depth.

  • Page 42: Levelling The Plough, In Furrows

    Adjusting the plough Levelling the Seen from the rear, the plough beams should be at 90º to the ground. plough, in furrows Correct adjustment Incorrect adjustment Levelling the plough, on-land Incorrect adjustment Correct adjustment Turning head 300 To level the plough turn the plough slightly turn the adjustment screws on the headstock.
  • Page 43 Adjusting the plough Extreme deep and shallow ploughing The turning stops on Headstock 300 must never touch the headstock frame. This may occur when • This ploughs at a shallow depth and the bodies turn over the frame Normal position (Headstock cross section) Turning stop Collision danger...

  • Page 44: Disc Coulter [+]

    • When the distance between the disc coulter and the landside is be- tween 1 and 4 cm. 1-4 cm EO; without parallel side adjustment To adjust the depth Support the disc coulter, to prevent it from dropping down Loosen bolt (T)
  • Page 45 Adjusting the plough EO; with parallel side adjustment To adjust the depth Support the disc coulter, to prevent it from dropping down Loosen bolt (R) Turn the arm Retighten bolt (R) Bolt R To adjust the sideways position Loosen bolt (S)

  • Page 46: Skimmer [+]

    Adjusting the plough Skimmer [+] The skimmers are correctly adjusted when • The skimmers have a working depth of approximately 3 to 5 cm. • All skimmers are adjusted equally. Adjusting the depth Support the skimmers, ensuring that they do not fall Loosen the nut on bolt C Loosen bolt C, one side at a time Adjust the skimmers to the desired position, and count the markings...

  • Page 47: Skimming Board

    Adjusting the plough Skimming board The skimming board should be placed with the front edge down against the mouldboard, the rear edge should be adjusted according to the ploughing depth. There are two adjusting holes in the bracket for the skimming board, one for deep ploughing and one for shallower ploughing (A).

  • Page 48: Ploughing

    Ploughing Ploughing Safety Be careful when turning, whilst driving backwards. Be careful when turning the plough while driving backwards. There is a risk that the mouldboards or depth wheel will hit the ground. This may result in damage or injury. Release the lift rods Release the tractor’s lift rods prior to ploughing.

  • Page 49: Turn The Plough

    Ploughing Checklist Turn the plough Completing the turning sequence Always complete the entire turning sequence. Only then will the turn- ing cylinder be locked, and will not creep during ploughing. The plough reverses when you apply pressure on the P-side of the turnover valve.

  • Page 50: Driving At The Headland

    Ploughing Driving at the headland Method 1 Method 1 Aim to drive in a large semi-circle at the headland. Using this method avoids having to reverse and stop NB! This way of driving requires large headlands Method 2 Method 2 Aim to drive straight towards the field boundary, reversing and driving into the furrows.

  • Page 51: Maintenance And Care

    Use original spare parts Use only genuine Kverneland spare parts. Other products may ad- versely affect the correct operation of the plough and safety. The war- ranty will no longer be valid if parts not produced by Kverneland are used. Use protective clothing Use protective clothing, e.g.

  • Page 52: Cleaning

    Maintenance and care Cleaning Thorough cleaning will give the plough a longer service life. • The plough can be cleaned with a power cleaner, but do never aim directly at bearings. • Lubricate all nipples after power cleaning. Lubrication Use appropriate grease Only use EP (Extreme Pressure) grease.
  • Page 53 Maintenance and care The illustrations below show the lubrication points (S) Lubrication points (S) Turning head 300 Turning head 300 Front Front Dual depth wheel Depth-/ transport wheel for butterfly position...
  • Page 54 Maintenance and care Lubrication points (S) Depth wheel Hydraulic depth wheel [+] Disc coulter Auto-reset beam EO...

  • Page 55: Replace Hoses

    Replace parts in contact with the soil and other parts when they are worn or damaged. parts • Use only genuine Kverneland spare parts. Remove the old part. Fit the new part Remove paint from any surfaces in contact with the soil...

  • Page 56: Tighten Bolts And Nuts

    Maintenance and care Replacing Quick-Fit Wear eye protection Wear eye protection when replacing Quick-fit points. Otherwise, there points is a risk that splinters from the Quick-Fit points can cause eye dam- age. Removing a worn point Position the tool Knock the point out Fitting a new point Place the new point the right way around Use the tool as a buffer between the point and the hammer...

  • Page 57: Replacing Shear Bolts [Lo]

    Maintenance and care Specific tightening torque Turning head 300 Shear bolt beam [LO] M30 left hand 672 Nm 883-932 Nm 68 kpm 90-95 kpm Shear bolt M20 545-600 Nm 55-61 M30 right hand 883-932 Nm 90-95 kpm Replacing shear Only fit original shear bolts Only fit original shear bolts.

  • Page 58: Check The Spring Is Of The

    Over time, the spring adjustment is of the correct can change gradually and needs to be corrected. length [EO] Check the spring length every year. Adjust the length if it is shorter or longer than 70 cm.
  • Page 59 Maintenance and care Check the pre- Couple to the tractor and support the beams When checking, couple the plough to the tractor and place the plough charge pressure on firm and level floor. Support the beams with a wedge under the landsides.
  • Page 60 Maintenance and care After checking Pressurise the system to 100 - 160 bar depending on the soil con- ditions Disconnect the charging hose from the quick coupling on the accu- mulator Disconnect the charging hose to the tractor Refit the dust caps Refill Refilling should be carried out at a special service station.

  • Page 61: Undertaking Modifications Of The Plough

    Turning direction The plough can only be used with the bodies over and the wheel under the frame. EO-LO Please contact your dealer if you have any questions relating to the turning direction. Restrictor position A restrictor is fitted on the turning cylinder to ensure turning takes place more smoothly.

  • Page 62: Spring For Release System [Eo]

    Undertaking modifications of the plough Spring for release This section explains how to: • Remove and fit an auto-reset beam system [EO] • Change the auto-reset beam's spring • Adjust the spring tension on the auto-reset beam Safety Support the beam Support the beam securely when removing it, by using appropriate equipment.
  • Page 63 Undertaking modifications of the plough Spring tension The diagram shows how the mechanism for transferring power from the spring must be set. Bolt E: Clearance to the hole wall Bolt X: Length of the spring 1-2 mm clearance 70 cm For instructions, see the next page.
  • Page 64 Undertaking modifications of the plough To relieve the spring tension Park the plough on a firm, level floor. Loosen slightly Push forward Support the beam correctly. Place a wedge under the rear of the landside Loosen bolt X To be able to removed the beam, bolt E must be undone. Loosen To apply spring tension Bolt J...
  • Page 65 Undertaking modifications of the plough Change the release force The release setting's release force is correct if the beams are only re- leased during ploughing when they meet an obstacle. setting The release force can be changed on the auto-reset beam by: •...

  • Page 66: Hydraulic Release System [+]

    Undertaking modifications of the plough Hydraulic release Pressure range 100 - 160 bar Do never exceed the pressure range. Exceeding the pressure range system [+] can result in damage to the system. (Dis)connecting the charging hose Because of the pressure in the hydraulic system, the charging hose can not be directly (dis)connected on the tractor.

  • Page 67: Switch Pressure On The Turnover Valve

    Undertaking modifications of the plough Switch pressure Do not open the valve. Never open the valve yourself. Once opened, valves are difficult to re- on the turnover fit, and dirt may penetrate the valve. This may result in damage or in- jury.

  • Page 68: The Position Of The Drag Axle

    Undertaking modifications of the plough The position of the The drag axle can be placed in several configurations to change: • The clearance between the tractor and the turning head drag axle • the clearance from the ground during turning •...

  • Page 69: Parking And Storage

    Parking and storage Parking and storage Safety Parking stand Use the parking stand when parking the plough. If the plough is not correctly supported, it may tip over. This may damage the plough or lead to injury. Park on a firm, level floor Park the plough on a firm, level floor.

  • Page 70: Troubleshooting

    Troubleshooting Troubleshooting Problem Possible cause Solution Turnover system The plough will not start turning The connections to the tractor are Check that the quick–couplings are mounted incorrectly. properly engaged and correctly con- nected (see colour coding on the hoses) The plough will not start reversing - The switch pressure is wrong Increase the transfer pressure setting the plough reacts with a suddenly in-...

  • Page 71: Checklist

    Checklist Checklist Tractor Check • Is the inner wheel distance 110-160 cm? • Is the pressure in the left and right tyres equal? • Are both lower link arms at the same height? Mounting Check • Are the hoses trapped or stretched? •...
  • Page 72 Checklist Daily maintenance The following must be carried out: Check the condition of the plough Lubricate the plough Regular maintenance The following must be carried out: Replace worn parts Retighten bolts and nuts Check • Is the automatic release system spring length L = 70 cm? •...

  • Page 73: Disposal Of The Plough

    Disposal of the plough Disposal of the plough Dispose of the plough correctly at the end of its service life. Please ob- serve the waste disposal regulations in force in your area. Metal All metal components can be sent for ferrous metal recycling. Tyres Tyres can be sent to tyre recycling facilities.

  • Page 74: Ec Declaration Of Conformity

    EC Declaration of conformity EC Declaration of conformity In accordance with EU Directive 2006/42/EC Kverneland Group Operations Norway AS Kverneland Klepp N-4355 Kverneland Norway declare under our sole responsibility that the product Information plate EO/LO and accessories to which this declaration relates, conforms to the relevant basic health and safety requirements of EU Directive 2006/42/EC.
