  • Page 1 TMG-ABC50 PRODUCT MANUAL v2023.09.11 50 GALLON TABLETOP CABINET SANDBLASTER Please read and understand the product manual completely before assembly Check against the parts list to make sure all parts are received Wear proper safety goggles or other protective gears while in assembly Do not return the product to dealer.
  • Page 2 WARNING! This manual provides critical safety instructions on the proper setup, operation, maintenance, and service of this machine/tool. Save this document, refer to it often, and use it to instruct other operators. Failure to read, understand and follow the instructions in this manual may result in fire or serious personal injury—including amputation, electrocution, or death.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION....................................3 Manual Accuracy................................3 Contact Info ..................................3 SECTION 1: SAFETY....................................4 Safety Instructions for Machinery ............................4 Additional Safety for Sandblasters ...........................6 SECTION 2: SETUP....................................7 Unpacking ..................................7 Assembly ..................................7 SECTION 3: OPERATIONS.................................10 Operation afety................................10 Basic Operation................................10 Abrasive ptions................................11 Nozzle/Jet Options.................................11 SECTION 4: MAINTENANCE................................12 Maintenance...................................12 SECTION 5: EXPLODED VIEW &...

  • Page 4: Introduction

    INTRODUCTION Manual Accuracy We are proud to offer this document with your new machine! We've made every effort to be exact with the instructions, specifications, drawings, and photographs of the machine we used when writing this manual. However, sometimes we still make an occasional mistake.

  • Page 5: Section 1: Safety

    SECTION 1: SAFETY For Your Own Safety, Read Instruction Manual Before Operating This Machine The purpose of safety symbols is to attract your attention to possible hazardous conditions. This manual uses a series of symbols and signal words intended to convey the level of importance of the safety messages. The progression of symbols is described below.
  • Page 6 HEARING PROTECTION. Always wear hearing protection when operating or observing loud machinery. Extended exposure to this noise without hearing protection can cause permanent hearing loss. REMOVE ADJUSTING TOOLS. Tools left on machinery can become dangerous projectiles upon startup. Never leave chuck keys, wrenches, or any other tools on machine.

  • Page 7: Additional Safety For Sandblasters

    Additional Safety for Sandblasters USE CORRECT ABRASIVES. Never use wet abrasives in this sandblaster, it is designed for dry abrasives only. PROTECT LUNGS. Make sure that you always use a respirator when using or cleaning the sand- blaster. LEAVING THE AREA. Always disconnect air supply when leaving the sandblaster. PROTECT EYES.

  • Page 8: Section 2: Setup

    WARNING satisfied with the machine and have resolved any issues between SUFFOCATION HAZARD! TMG INDUSTRIAL or the shipping agent. Keep children and pets away You MUST have the original pack- aging to file a freight claim. It is from plastic bags or packing also extremely helpful if you need to return your machine later .
  • Page 9 Install filter(16) and side vent seat(18) with filter ring (17), Figure 1 screws(39), washer (41) and nuts(44) (Figure 1). Noted: When using the sandblaster, you need take off the Side vent cover(44). 39 41 44 3. Install the air inlet connect (35)with plain washer(34). Attach the air supply hose and suction hose to the bulkhead fittings and suction pipe with hose clamps (Figure 2).

  • Page 10: Section 3: Operations

    If you have never used this type of machine or equipment before, WE STRONGLY REC- OMMEND that you read books, trade magazines, or get formal training before beginning any projects. Regardless of the content in this section, TMG Industrial will not be held liable for accidents caused by lack of training.

  • Page 11: Abrasive Ptions

    Abrasive Options Below is a basic introduction to some of the most common blasting abrasives. Refer to magazines, trade articles, professionals, and the abrasive manufacturer for the specific surfaces that can be addressed with a type of abrasive. All abrasives have benefits and drawbacks like quality of surface finish, abrasive life, toxicity, and what precautions you must take to prevent environmental damage or personal injury to your respiratory system.

  • Page 12: Section 4: Maintenance

    SECTION 4: MAINTENANCE Maintenance WARNING Always disconnect power and air supply to machine before performing maintenance. Failure to do this may result in serious personal injury. Depressurize the sandblaster, and check the following items each time you use the sandblaster and replace any parts immediately if found to be worn: •...

  • Page 13: Section 5: Exploded View & Parts List

    SECTION 5: EXPLODED VIEW & PARTS LIST Exploded View 41 44 48 47 44 43 41 44 Air Inlet...

  • Page 14: Parts List

    Parts List PART NO. DESCRIPTION PART NO. DESCRIPTION Front window frame Legs Outer front window Plastic leg cover Inner front window Nozzle cap Front window replacement film Blast nozzle Front window seal Blast gun Front door assembly Hose clamp ø10-ø13 Top door support Air hose ø6.2 (ID) Rear air intake cover...
