TMG -ABT20 Product Manual

20 gallon portable sandblaster
Hide thumbs

Advertisement

Quick Links

Download this manual
TMG-ABT20
PRODUCT MANUAL
v2023.08.26
20 GALLON
PORTABLE SANDBLASTER
Please read and understand the product manual completely before assembly
Check against the parts list to make sure all parts are received
Wear proper safety goggles or other protective gears while in assembly
Do not return the product to dealer. They are not equipped to handle your requests.
Missing parts or questions on assembly?
Please call: 1-877-761-2819 or email: cs@tmgindustrial.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the TMG-ABT20 and is the answer not in the manual?

Questions and answers

Related Manuals for TMG TMG-ABT20

Summary of Contents for TMG TMG-ABT20

  • Page 1 TMG-ABT20 PRODUCT MANUAL v2023.08.26 20 GALLON PORTABLE SANDBLASTER Please read and understand the product manual completely before assembly Check against the parts list to make sure all parts are received Wear proper safety goggles or other protective gears while in assembly Do not return the product to dealer.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS ........................2 SAFETY INFORMATION........................... SPECIFICATION..............................COMPONENTS AND CONTROLS........................UNPACKING & ASSEMBLY..........................OPERATION..............................MAINTENANCE............................TROUBLESHOOTING..........................PARTS DIAGRAM............................

  • Page 3: Safety Information

    IMPORTANT SAFETY INFORMATION Before operating the PARTS WASHER read the following safety instructions. Failure to comply with these warnings may result in serious injury or death. SAFETY INSTRUCTIONS The alert symbol is used throughout this manual and this manual and on the product safety decals. This symbol indicates attention is required and identifies hazards concerning your personal safety and the safety of others.
  • Page 4 IMPORTANT SAFETY PRECAUTIONS WARNING! Read and understand all instructions before using this tool. The operator must follow basic precautions to reduce the risk of personal injury and / or damage to the equipment. Before allowing someone else to use this tool, make sure they are aware of all safety information.
  • Page 5 ABRASIVE BLASTING MEDIA PRECAUTIONS The blasting process emits abrasive media under pressure that breaks apart upon impact. The resulting dust is a combination of the media and the material being removed by the abrasive. Both the media and the material being removed may have toxic components such as lead in paint.
  • Page 6 TOOL USE AND CARE WARNING! Do not use the tool if the trigger or ON / OFF switch does not function properly. Any tool that cannot be controlled with the ON / OFF switch is dangerous and must be repaired. 1.

  • Page 7: Specification

    PRODUCTS SPECIFICATIONS Model TMG-ABR20 Tank volume 20 gal. Working pressure 60-125 psi Air consumption 6-25CFM Required air hose 3/8"x8’ Abrasive media capacity 16.5 gal. Nozzle size 5/64”, 3/32”, 1/8”, 9/64” COMPONENTS AND CONTROLS Air Pressure Water Gauge Trap Air Inlet...

  • Page 8: Unpacking & Assembly

    UNPACKING & ASSEMBLY UNPACKING 1. Carefully remove the tool from the package. a. Retain packing material until you have carefully inspected and satisfactorily installed or operated the tool. 2. Make sure that all items in the parts list are included. 3.
  • Page 9 5. Assemble the deadman valve and ceramic nozzle (See figure 5). Fig. 5 a. Screw the hose barb (49) into the intake connector (34) of the deadman valve. b. Unscrew the nozzle cap nut (39) and remove the rubber adaptor (38). c.

  • Page 10: Operation

    OPERATING Read the Entire Important Safety Information section at the beginning of this manual including all text under subheadings therein before set up or use of this product. inspect tool before use, looking for damaged, loose, and missing parts. if any problems are found, do not use tool until repaired. TOOL SET UP WARNING! To prevent Serious injury From accidental operation:...
  • Page 11 WORKPIECE AND WORK AREA SET UP 1. Designate a work area that is clean and well-lit. The work area must not allow access by children or pets to prevent distraction and injury. 2. If possible, place the Workpiece inside a sandblast cabinet. Otherwise, isolate the Workpiece to make sure no damage can occur to nearby walls, tools, personal property, etc.
  • Page 12 OPERATING TIPS 1. The effectiveness of the blaster is increased by holding the nozzle as close to the area being cleaned as possible. 2. Move the blaster in steady, even strokes over the area to keep the abrasive blasting surface even. 3.

  • Page 13: Maintenance

    MAINTENANCE NOTE: Disconnect the air source and discharge any residual air pressure in the air line before performing any maintenance. 1. The ceramic nozzle (37) will wear away over time, causing the internal diameter to widen and disperse the media over a larger area, reducing the tool’s efficiency.

  • Page 14: Troubleshooting

    LUBRICATION Do not use lubricants or air tool oil on the unit. The oil will contaminate the abrasive media, clogging the tool and reducing the effectiveness of the abrasive. STORAGE With a dry, clean cloth or brush, remove any contaminants from the unit and the deadman valve before placing the unit in storage. DISPOSING OF THE TOOL 1.

  • Page 15: Parts Diagram

    EXPLODED VIEW & PARTS LIST 1. Exploded diagram...
  • Page 16 2. Parts List PART NO. DESCRIPTION PART NO. DESCRIPTION Tank 20gallon Abrasive hose Ø12x2500 Wheel Ø1/2”x5” Funnel Cotter pin 4x36 Safety hood Front foot Safety hood lens Wheel axle Ø12x344 Upper body Hand bar Lower body Hand grip Ø22 Metal pipe Pan screw M6x35 Intake connector Hex nut M6...
