- Page 2 CNC head part installation M2.5 (20mm) aluminum standoff M2.5 (8mm) button head hex socket screw M2 (6mm) button head hex socket screw Antenna Installation Sequence insert the O-ring into the antenna to secure it on the TPU antenna base.
- Page 3 FC Mounting Hole | Motor Mounting Hole Motor installing hole distance: 12*12mm M2 (6mm) screws are recommended 20*20 flight controller mounting holes 25.5*25.5 AIO flight controller mounting holes 30.5*30.5 flight controller mounting holes...
- Page 4 Recommended cable length for 25.5 AIO: 52mm Recommended cable length for 20mm MINI: 62mm *(Note: Assembly diagram, motor not included in the frame) 1�1 Scale 100 110 120 130 140...
- Page 5 Multi-function Antenna Mount SMA antenna installation position. Adjustable GPS Mount (12*16mm) TYPE-C Module Self-tapping Screw M2.5 (6mm) M3 (15mm) aluminum standoff Tpye-C (*Note: pictures for assembly reference only. Select the corresponding Frame doesn’t include antenna) interface to connect to the FC Micro USB *(注：装配示意图，机架不包含天线）...
- Page 6 CNC cooling part installation Install the video transmitter antenna into the TPU antenna mount. First, install the aluminum alloy at the bottom position. Install the video transmitter into the aluminum bracket (pay attention to the orientation), and then secure it with the TPU video transmitter mount.
- Page 7 Suggesting place for main power cable It is recommended to keep the power cable of ESC to be about 100mm. Please refer to your own battery for actual length.
- Page 8 CNC cooling part installation M3 (14mm) button head hex socket screw M2 (6mm) button head hex socket screw O3 Air Unit or RunCam Link installation M2 (3mm) button head hex socket screw O3 Air Unit或RunCam Link...
- Page 9 Bottom screw installation M3 (14mm) button head hex socket screw...
-
Page 10: Installation Illustration
Installation Illustration M3 (8mm) button head hex socket screw M3 (9mm) flat hex socket screw M3 (10mm) button head hex socket screw M3 (7mm) flat hex socket screw M3 (14mm) button head hex socket screw... - Page 11 T-antenna installation M2(6mm) M2 (7mm) button head hex socket screw...
- Page 12 Detachable anti-vibration camera base mount M3 (8mm) button head hex socket screw M3 (10mm) button head hex socket screw M3 (20mm) button head hex socket screw M3 nut Note: This accessory needs to be purchased separately...
