- Page 1 SpeedyBee Meteor LED Strip User Manual Contents 1. LED Strip Wireless Configuration 2. FC Wireless Configuration 3. BOOT Mode 4. Bee35 Meteor LED Installation Instructions...
- Page 2 The Meteor LED features an integrated wireless configuration module, enabling easy setup and adjustments via the SpeedyBee APP for your drone. The Meteor LED is factory-prepared with pre-soldered LED strips for your convenience.Follow the detailed installation steps provided in the sections below.
- Page 3 LED Strip Wireless Configuration If the flight controller comes with a built-in Bluetooth configuration feature, there is no need to solder TX and RX. You only need to connect V and G to perform wireless configuration of the LED. ① The red wire should be soldered to the BAT pad of the flight controller or the positive pole of the power cable, with an input voltage range of 2-6S lithium battery.
- Page 4 Then click 'Save and Reboot' in the bottom right corner. ⑤ With all soldering and settings complete, power up the drone and open the SpeedyBee APP. Click the plus sign at the bottom, select 'SpeedyBee MeteorLED'. Once connected, click on 'FC Tuning' for wireless Configuration.
- Page 5 The Meteor LED can is used to enter DFU mode on the flight controller through the button on the BEC module. It only supports flight controllers with BOOT solder pads, such as the SpeedyBee F4mini flight controller. Operation: ① Press and hold the BEC button first.
- Page 6 Bee35 Meteor LED Installation Instructions M2.5*8 self-tapping screw M3*18...
