SpeedyBee BEE25 Manual

Hide thumbs Also See for BEE25:
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
BEE25
INSTALLATION
AND
OPERATION
INSTRUCTIONS
* Note: For 3D rendering purposes; actual product may va爀礀.
*Due to the small screw size, please install them manually.
Avoid using an electric screwdriver to prevent excessive torque, which could cause screws to break.

Advertisement

loading
Need help?

Need help?

Do you have a question about the BEE25 and is the answer not in the manual?

Questions and answers

Related Manuals for SpeedyBee BEE25

Summary of Contents for SpeedyBee BEE25

  • Page 1 BEE25 INSTALLATION OPERATION INSTRUCTIONS * Note: For 3D rendering purposes; actual product may va爀礀. *Due to the small screw size, please install them manually. Avoid using an electric screwdriver to prevent excessive torque, which could cause screws to break.
  • Page 2 Antenna Replacement Steps 1. Remove the screws from the antenna cover and slide out the original antenna to the right. 2. Install the provided antenna into the corresponding inte爀昀ace and secure the antenna cover with an original M1.6*8 Phillips screw. 3.
  • Page 3 Injection-Molded Head Installation Steps 1. Pass the replaced antennas through the hexagonal openings on both sides of the head. 2. Install the O3 Air Unit with the Type-C po爀琀 facing up into the injection-molded head. Secure it to the bottom with four M1.6*8mm (hex socket cup head) screws from the accessories.
  • Page 4 Antenna Mount Installation Steps Antenna Mount Copper Tube Antenna Install the copper tube antenna in the designated position and secure it with two M1.6*4mm (昀氀athead Phillips) screws.
  • Page 5 Head Fixation Steps Inse爀琀 the rese爀瘀ed 6Pin cable into the O3 Air Unit. Attach the assembled head to the protective ring and secure it with four M2*8mm (hex socket button head) screws. Note: Pay attention to the antenna placement during the head installation to avoid pinching the antenna.
  • Page 6 The PNP version does not include a receiver and needs to be installed separately. 3. Connect the soldered receiver po爀琀 to the rese爀瘀ed socket of the Bee25. 4. Reattach the bottom plate to the protective ring and secure it with four...
  • Page 7 GPS protective cover. Secure it with two M2*6mm (hex socket button head) screws. 4. After installing the GPS, connect to the BEE25 using the APP. In the preset mode, select "Return to Home" mode to set the return parameters with one click.
  • Page 8 2. Remove the four original screws from the bottom of the LINK. Note: The LINK expansion pa爀琀 needs to be downloaded and printed from the SpeedyBee o昀케cial website. 3. Install the expansion module onto the LINK as shown in the diagram.
