SpeedyBee BEE25 Installation Instructions Manual

Frame
Hide thumbs Also See for BEE25:

Advertisement

Quick Links

Download this manual
FRAME
INSTALLATION
INSTRUCTIONS
BEE25
*Note: 3D effect requirements, the actual object shall prevail.
*Due to the small screw size, manual installation is recommended. Avoid using an electric screwdriver to
prevent excessive torque that could break the screws.

Advertisement

loading
Need help?

Need help?

Do you have a question about the BEE25 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SpeedyBee BEE25

Summary of Contents for SpeedyBee BEE25

  • Page 1 FRAME INSTALLATION INSTRUCTIONS BEE25 *Note: 3D effect requirements, the actual object shall prevail. *Due to the small screw size, manual installation is recommended. Avoid using an electric screwdriver to prevent excessive torque that could break the screws.
  • Page 2 25.5*25.5 AIO FC mounting holes Motor mounting hole distance: 9*9mm Use four countersunk M2*12mm hex screws to secure the FC. M2 Anti-Slip Nuts Countersunk screw M2 (12mm)

  • Page 3: Incorrect Example

    Slide the EXT LITE/PRO board into the frame from the rear carbon plate. Do not install from top to bottom. Incorrect Example...
  • Page 4 Connect the positive and negative terminals of EXT LITE to the flight controller using the included 18AWG red and black power cables. Insert the 4PIN cable into EXT LITE and plug the Type-C/Micro USB into the flight controller's tuning port. Hold the side button on EXT LITE and power the flight controller to enter mode.
  • Page 5 1. Connect the positive and negative terminals of EXT PRO to the flight controller using the included 18AWG red and black power cables. Solder the capacitor to the PRO XT30 head (ensure correct capacitor polarity).）； 2. Insert the 6PIN cable into EXT PRO and plug the Type-C/Micro USB into the flight controller's tuning port.；...
  • Page 6 Thread the elastic strap into the CNC, place the CNC on the carbon plate, and tighten it from bottom to top using M2*6 screws. Button head socket screw M2 (6mm)
  • Page 7 Secure the motors using 16 M2*4 screws. Button head socket screw M2 (4mm)
  • Page 8 1. Insert the LED strip from the right side of the rear of the protective ring. 2. Connect the 3-pin plug to the reserved socket of the EXT PRO. 3. Embed the LED strip into the protective ring's inner layer, and secure it along the inner wall.
  • Page 9 Use four M2*6 screws to secure the upper carbon plate onto the protective ring. Button head socket screw M2 (6mm)
  • Page 10 1. Install the corresponding ELRS receiver as shown in the diagram. 2.After soldering and installing the receiver, mount the base plate onto the protective ring and secure it using four M2*6mm (button head socket) screws.
  • Page 11 Use two M2*6 screws to install the GPS cover; frame installation is complete. Button head socket screw M2 (6mm)
  • Page 12 Secure the propellers using 8 M2*7 screws. Button head socket screw M2 (7mm)
  • Page 13 1. Remove the screws on the antenna cover and slide the original antenna out to the right. M1.6 cross screws (6mm) 2. Install the antenna from the accessory kit into the corresponding port and secure the antenna cover with an original M1.6*6mm cross screw.
  • Page 14 1. Thread the replaced antennas on both sides out of the hexagonal shape on the side of the head. 2. Install the O3 Air Unit with the Type-C port facing up into the injection-molded head and secure it to the bottom positions using 4 M1.6*8mm (cup head hex) screws from the accessory kit.
  • Page 15 Antenna Mounting Copper Tube Antenna Install the copper tube antenna into the designated location and secure it with 2 M1.6*4mm (flat head cross) screws. Button head socket screw M2 (6mm)
  • Page 16 1. Insert the 6-pin cable into flight controller and O3 Air Unit. 2. Attach the assembled had to the protection ring and secure it with 4 M2*8mm (button head socket) screws. Button head socket screw M2*8mm Note: When installing the nose, ensure the antenna is positioned correctly to avoid pinching or damaging it.
  • Page 17 2. Remove the 4 original screws at the bottom of the LINK. 3. Install the extension part onto the LINK as shown in the diagram. Note: The LINK extension part can be downloaded and printed from the SpeedyBee official website.
