Translation of the original operating manual
sb
Rev. 1.0 of 14/06/2016
Epsilon 2-4 LSCplus; ;
Version 06/2016
Epsilon 2-4 LSCplus
part no. 113019
Freeze-dryer
Operating Manual
Please retain for later use!
