- Page 1 ViewSonic ® PJ106D SVGA LED Projector - User Guide - Guide de l’utilisateur - Bedienungsanleitung - Guía del usuario - Guida dell’utente - Guia do usuário - Användarhandbok - Käyttöopas - Pyководство польэователя - 使用手冊 - 使用手册 Model No. : VS11244...
-
Page 2: Compliance Information
To assure continued FCC compliance, the user must use grounded power supply cord and the cables which are included with the equipment or specified. Also, any unauthorized changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this device. ViewSonic PJ106D... - Page 3 EEC as amended by 92/31/EEC and 93/68/EEC Art.5 with regard to “Electromagnetic compaty”, and 73/23/EEC as amended by 93/68/EEC Art.13 with regard to “Safety.” User Information for all Countries Notice: Use the cables which are included with the unit or specified. ViewSonic PJ106D...
-
Page 4: Copyright Information
PS/2, VGA and XGA are registered trademarks of International Business Machines Corporation. Disclaimer:ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. -
Page 5: Product Registration
To meet your future needs, and to receive any additional product information as it becomes available, please register your product on the Internet at: www.viewsonic.com. The ViewSonic Wizard CD-ROM also provides an opportunity for you to print the registration form, which you may mail or fax to ViewSonic. -
Page 6: Table Of Contents
Contents Important safeguards ...2 Overview...7 Power...8 Remote control (optional accessory)...10 Installation ...13 Basic connections...15 Preparation ...17 Basic operation...19 Menu operation...22 Using an SD Card...25 Troubleshooting ...28 Maintenance ...32 Indicators ...33 Specifications ...35 ViewSonic PJ106D... -
Page 7: Important Safeguards
Instructions All operating instructions must be followed. Cleaning Unplug this projector both from the wall outlet and battery before cleaning it. Do not use liquid aerosol cleaners. Use a damp soft cloth for cleaning. Attachments and equipment Never add any attachments and/or equipment without the approval of the manufacturer as such additions may result in the risk of fire, electric shock or other personal injury. - Page 8 Slots and openings in the cabinet are provided for ventilation, ensuring reliable operation of the projector and to protect it from overheating. Do not block these openings or allow them to be blocked by placing the projector on a bed, sofa, rug, or bookcase.
- Page 9 (a) If the power-supply cord or plug is damaged. (b) If the adaptor or the battery is damaged. (c) If liquid has been spilled, or objects have fallen into the projector, adaptor or battery. (d) If the projector does not operate normally after you follow the operating instructions.
- Page 10 Unplug the power cord or remove the battery immediately if there is something wrong with your projector. Do not operate if smoke, strange noise or odor comes out of your projector, adaptor or battery. It may cause fire or electric shock. In this case, unplug immediately and contact your dealer.
- Page 11 Do not look into the lens when the projector is operating. It may hurt your eyes. Never let children look into the lens when the projector is on. Do not unplug the power cord or remove the battery during operation.
-
Page 12: Overview
Terminal board Air outlet grille Lens Kensington lock Remote control sensor (Rear side only) Speaker Air inlet grille ViewSonic PJ106D Control panel 1 LAMP indicator 2 POWER indicator 3 CHARGE indicator 4 POWER button 5 Four directional 6 OK button... -
Page 13: Power
Using the provided AC adapter or an optional Lithium-ion rechargeable battery. Warning: The projector must be used with the provided AC adapter. Damage caused by the use of an incorrect adapter is not covered under the warranty. Using the AC adapter 1. - Page 14 We recommended that you full charge the battery all the time. When the projector is off, the charger works as a fast charging mode. It takes approximately 5 hours to complete charging. When the projector is on, the charger works as a slow charging mode.It takes approximately 7 hours to complete charging.
-
Page 15: Remote Control (Optional Accessory)
Blank button 4:3/16:9 button Auto button For the first time use: Remove the transparent insulation tape by pulling it before use. For battery change: 1. Push the catch to the right and remove the battery holder. ViewSonic PJ106D Catch Battery holder... -
Page 16: Operating Range
The infrared signal operates by line-of-sight up to a distance of approximately 9.8 (3 m) and within a 30-degree angle of the remote sensor. The projector will not function if there are objects between the remote control and the remote sensor on the projector or if strong light falls on the remote sensor. - Page 17 Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to your local regulations. Do not recharge, disassemble or dispose of the battery in fire. ViewSonic PJ106D...
-
Page 18: Installation
Installation Layout of the projector Image size varies depending on the distance between the screen and the projector. Front projection L : Between the screen and the front edge of the projector A : Height of the projected image under the horizontal line... - Page 19 Do not place the projector on a carpet or any flammable materials. It may cause damage or fire. Place the projector at least 10 cm (or 4 inches) away from the wall to prevent the air inlet grille and the air outlet grilles that emit hot air from being blocked.
-
Page 20: Basic Connections
Plug in the AC adapter of the projector and the connected devices firmly. When unplugging, hold and pull the plug. Do not pull the cord. When the projector and the connected devices are located too close to each other, the projected image may be affected by their interference. -
Page 21: For Macintosh
Some computers require additional connectors or analog RGB output adapters to be connected with this projector. Contact your dealer for further information. For Macintosh If your Macintosh has no video port, a monitor output adapter is required. Contact your dealer for further information. -
Page 22: Preparation
Do not place any objects on the AC adapter and power cord or do not place the projector near heat sources to prevent damage to the power cord. If either the AC adapter or power cord should be damaged, contact your dealer for replacement because it may cause fire or electric shock. - Page 23 In such cases, set the keystone adjustment values in the range where the image is displayed without noise. When the keystone adjustment is carried out, the image may not be displayed correctly because of the type of input signal. ViewSonic PJ106D Press the Keystone ...
-
Page 24: Basic Operation
The LAMP indicator lights up and the POWER indicator goes off. The message “Searching for source” appears on the screen. The lamp occasionally fails to light up. Turn off the projector, wait for one minute and then turn on it again. - Page 25 The air outlet fan rotates faster as the temperature around the projector rises. Power-off Use the following procedure to turn off the projector. Do not turn off the projector by unplugging the power cord while the lamp is on. Unplugging while the lamp is on degrades the lamp’s performance and causes failure in the projector.
-
Page 26: On The Remote Control
Volume / button Press the Volume to increase the volume, press the Volume to reduce the volume. Source button If multiple sources are connected withto the projector simultaneously, press the Source but- tonThe projector will detect your source. Important: The image may not be projected or auto adjustmentsetting may not be performed correctly for input signals other than those supported by the projector. -
Page 27: Menu Operation
Active when connecting with VGA source only. Only available for SD card mode. SD Slideshow Delay will be active when SD Slideshow sets to Auto. Range -15 - +15 for 4:3 aspect ratio; -10 - +10 for 16:9 aspect ratio. ViewSonic PJ106D Color Brightness Contrast Gamma... - Page 28 H. Position...Use to adjust the horizontal position of the image. V. Position ...Use to adjust the vertical position of the image. Frequency...Use to change the display data frequency to match the frequency of your computer’s graphic card. Tracking ...Use to eliminate image noise such as wide stripes. ViewSonic PJ106D...
- Page 29 SD Picture Information ... Use to display picture information. 5. Language... Use to select the language used in the menu. [English, Deutsch, ViewSonic PJ106D and then choose “Yes” to turn the display parameters to the factory default settings. • Manual: for playback once.
-
Page 30: Using An Sd Card
Supported audio sampling rate: 8k,11.025k,12k,16k,22k,24k,32k,48kHz (Note: 44.1KHz is not supported) QuickTime Supported (MJPG brand name only) Epson Nikon Olympus PanasonicLecia Lumix DMC-LC5 ViewSonic PJ106D Supported model name DC-4381 DC-5381 Supported model name PowerShot S45 PowerShot S50 PowerShot A40 Exilim EXS2 QVR4 FinePixA303 FinePixF601 Digital Revio KD-400Z... - Page 31 1. NTFS format is not supported when formatting the SD Card. 2. Do not remove the SD Card while accessing or playing back the files because it may damage the data. ViewSonic PJ106D Supported model name PowerShot G1 PowerShot A40...
- Page 32 Enter button or control panel’s OK button to playback. Pressing remote control’s Enter button or control panel’s OK button again will stop, pause or exit from playback. 5. Press remote control’s Source button again to exit SD Card mode. ViewSonic PJ106D Lock...
-
Page 33: Troubleshooting
The air inlet or outlet grille may be blocked. Remove the objects blocking the air inlet or outlet grille and carry out the Images suddenly disappear. Check that the battery or power cord connected with the projector correctly. ViewSonic PJ106D POWER(Red) following. -
Page 34: Images Aren't Projected Correctly
Check that the cable connected to the external device isn’t defective. source” is displayed. Check that the projector is connected to the external device using the correct terminals. Check that the connected device is correctly selected as the input source. - Page 35 Cause and solution White dots are seen This symptom is normal for a DLP projector and is not a malfunction. (A on projected images. very small number of pixels may stay lit or out, but such sympton is not a Black dots are seen malfunction.
- Page 36 Others Problem Cause and solution Hot air is emitted This air comes out as a result of cooling the inside of the projector. This isn’t from the air outlet a product malfunction. grilles. The microcomputers inside the projector may be wrongly operating because of noise.
-
Page 37: Maintenance
Cleaning of the projector and the ventilation slots Use a soft cloth to clean the projector and the ventilation grilles. When the grilles become dirty, wipe them with a soft cloth dampened with diluted mild detergent, and then wipe them with a dry cloth. -
Page 38: Indicators
Indicators This projector has three indicators, each of which shows the operation condition of the projector. The following offer solutions to possible problems. If these problem persist, turn the projector off and consult your appliance dealer. Normal condition (AC Adaptor only) -
Page 39: Abnormal Condition
Normal condition (Battery only) LAMP (Green) Abnormal condition LAMP (Green) Flashing x 1 Flashing x 2 Flashing x 3 ViewSonic PJ106D POWER (Red) CHARGE (Red) Flashing x 10 POWER (Red) CHARGE (Red) Off x 1 (Flashing) Off x 3 (Flashing) -
Page 40: Specifications
I/O Connectors Outside dimensions Weight AC adapter input Length of power cord Temperature, humidity (performance guaranteed) The specifications and outside appearance of the projector are subject to change without prior notice. ViewSonic PJ106D LED projector 15V, 2.0A Single 0.55” DLP panel 800 x 600 pixels 16.7 million... - Page 41 Dimensional drawings (unit : mm) ViewSonic PJ106D...
-
Page 42: Optional Accessories
1 Composite Video Cable 1 AC Adaptor 1 Power Cord (US/EU/UK/AU/CN/TW)* 1 Remote Control * It depends on different countries or areas, only 1 cord is included. Optional accessories 1 Lithium-ion Rechargeable Battery * Output: Normal DC 11.1V 4300 mAh ViewSonic PJ106D... - Page 43 Specification of RGB signals in each computermode of the projector Signal mode Resolution (H x V) Horizontal frequency (kHz) Vertical frequency (Hz) VGA 60 640 x 350 VGA 85 640 x 350 VGA mode3 640 x 480 640 x 480...
- Page 44 1920 x 1080 Important: Some computers aren’t compatible with the projector. The projector’s maximum resolution is 800 x 600 pixels. It may not display images of higher resolutions than 800 x 600 correctly. Images with SYNC on G (Green) signal may jitter.
-
Page 45: Customer Support
South Africa/Other www.viewsonic.com countries www.hk.viewsonic. Hong Kong com/support/ www.hk.viewsonic. Macau com/support/ Korea www.viewsonic.com ViewSonic PJ106D T=Telephone E-mail F=Fax T= (800) 688 6688 service.us@viewsonic. F= (909) 468 1202 service.ca@viewsonic. T=(866) 463 4775 service. T= 0207 949 0307 eu@viewsoniceurope. service. Contact your reseller eu@viewsoniceurope. -
Page 46: Limited Warranty
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will at its sole option repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components. - Page 47 fitness for a particular purpose. Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: Damage to other property caused by any defects in the product, damaged based upon inconvenience, loss of use of the product, loss of time, loss of profits, loss of business opportunity,...
