ViewSonic PJ1060 Quick Start Reference Sheet

NOTE: This document is intended only as a quick reference for installation – please read the SP
Controls Application Note for a complete description of this projector driver prior to installation.
I. Driver Features

1. Input Selection Mapping

Selection 1: VIDEO
Selection 2: VIDEO
Selection 3: RGB 1
Selection 4: RGB 2

2. Hidden Function Mapping (Default Configuration)

Using the ON button as a shift key, press the following buttons to access the specified projector features.
Selection 1: BLANK
Selection 2: MUTE
Selection 3: ADJ LEFT
Selection 4: ADJ RIGHT
Off: MENU
Volume Up: ADJ UP
Volume Down: ADJ DOWN

3. Other Driver Features

Power Status Feedback Method
Control Wiring
II. Wiring Specifications
NOTE: For a wiring diagram, please see the SP Controls Application Note.

1. RS-232:

Wire the Panel RS-232 port to a female HD15 as follows:
TX to 13
RX to 14
GND to 10
Connect this female HD15 to the projector port labeled CONTROL.

2. Infrared Emitter:

Wire the Panel IR/Serial port to a female 1/8" Mini as follows:
IR/SER to tip
GND to ring
Connect to the included IR Emitter and attach the emitter bud to any projector IR window.
III. Additional Projector Information
The MP8670 must be configured in the following way for use with the Panel:
•
Baud Rate 9600: Set the projector to 9600bps in the onscreen OPT. (OPTIONS) Menu: COM.
SPEED setting.
•
Data Word 8N1: Set the projector to use data word 8N1 in the onscreen OPT. (OPTIONS) Menu:
COM. BITS setting.
DR-VWS03 - 12/18/03
SP Controls reserves the right to modify specifications without notice at any time.
RS-232 Power Polling
RS-232 and Infrared Emitter
Quick Start Reference Sheet
Viewsonic PJ1060
Revision A
