RIOTEC iCR6307ABQ Programming Quick Manual

P r o g r a m m i n g Q u i ck Gu i d e
- i CR 6 3 0 7 ABQ / i CR 6 3 0 7 ABM
Connecting the Scanner
Be sure that PC is turned OFF, before Connect scanner cable to
the PC USB port on the PC as below described, Ensure that all
connections are ready, and turn on your PC.
1. Please switch ON and charge scanner for 4~ 5 hours at f irst time
before use. Scanner switch shown on Fig. 2.
2. After switch ON, the Orange LED will flash following with 3
beep-sounds. The RED LED will be OFF while it links to cradle
within 2.4GHz radio range.
3. I f RED LED is continual ON, please re-plug USB cable, then, scan
the 3 barcodes on the bottom of cradle sequentially.
Fig. 3 From 1 to 3).
4. Charging issue: Cradle works as charger when putting scanner on
it. Even if the scanner's battery is full, the cradle will continue to
supply power to the scanner. We suggest you to remove scanner
from cradle when scanner is charged fully
* Note: Please install PL-2303 driver for iCR6307ABM
LED I ndicator I nformation
Orange LED ON
Orange LED Flashing
Red LED ON
Green LED ON
Orange LED ON
Remark:
* When the battery power is too low, the Orange LED will flash and beep
once. Scanner should be charged immediately.
* I f scanner shuts down it is recommended to charge it fully before
turning it back on.
* Under power-saving mode, there will not be LED indication when charging.
Reset Configuration to Defaults
(scan from A1 to A7 for iCR6307ABQ or B1 to B7 for iCR6307ABM)
iCR6307ABQ
A1
A2
(Shown on
A3
A4
A5
A6
A7
* Note: Please install PL-2303 driver for
There are tw o operating modes on the scanner
Full charged
Charging / Low battery
Offline / out of service
Good read
Good read (Batch mode)
Data
read
LED
iCR6307ABM
B1
Data
read
B2
LED Green/ Orange LED flashes followed by 3 beeps.
B3
Under Data storage Mode
The data can be keep or delete by option after transmit
B4
B5
Transmit memory data
B6
Green/Orange LED Flashes followed by 3 beeps
B7 Clean memory data
Green/ Orange LED flashes followed by 3 beeps
iCR6307ABM
The barcode data which is stored in the memory will be deleted.
1
( Default)
1.Data Transmission mode
I t is a necessary to scan "clean memory data" w hen
sw itching betw een these tw o modes.
Within 2.4GHz radio range Beyond 2.4GHz radio range
Save data into scanner's memory,
Transmit data to PC/ terminal scanner will transmit data to PC/
directly terminal automatically when back to
2.4GHz radio range.
Enter Data Storage mode
Green/ Orange LED flashes
followed by 3 beeps.
( Batch Mode)
2.Data Storage mode
I t is a necessary to scan "clean memory data" w hen sw itching
betw een these tw o modes.
Save data directly to scanner's memory, I t will transmit the data to PC/
terminal after you scan the Transmit memory data
data please scan the Clean memory data code.
Enter Data Transmission mode
Always Clean memory data before switching to Data Transmission
Mode.
Otherwise Red/ Orange LED will flash with one long beep and will not
switch modes.
Keep the data
( Default)
code. To delete
Delete the data
