RIOTEC LS6000B Quick Manual

Laser barcode scanner
Hide thumbs Also See for LS6000B:
Table of Contents

Advertisement

Quick Links

LS6000B
Laser Barcode Scanner
Quick guide
www.BC-Discount.com
+33 (0) 1 82 83 62 06 - contact@bc-discount.com
AgileBio SARL, 16bis quai Jean Baptiste Clément, F-94140 ALFORTVILLE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LS6000B and is the answer not in the manual?

Questions and answers

Related Manuals for RIOTEC LS6000B

Summary of Contents for RIOTEC LS6000B

  • Page 1 LS6000B Laser Barcode Scanner Quick guide www.BC-Discount.com +33 (0) 1 82 83 62 06 - contact@bc-discount.com AgileBio SARL, 16bis quai Jean Baptiste Clément, F-94140 ALFORTVILLE...
  • Page 2 For power supply, the charging cradle of LS6000B also works as a battery charger for the scanner. Users can plug in 5V DC power adaptor for power charge of the scanner.

  • Page 3: Installation

    6 hours at first time before install driver. Install the software “PL-2303 Driver Installer.exe” to the host system for LS6000B series. Connect scanner cradle to the USB port on the host system. Once link the red led light on scanner will off.

  • Page 4: Hyper Terminal

    Hyper Terminal. Detail set up on the Hyper Terminal, please see at the Figure 1 to Figure 3. Figure 1 Step 1: key-in a file name Step 2: select the first icon Step 3: press OK Figure 2 No need to key-in No need to key-in Step 1: key-in the identify COM Step 1: key-in the identify COM...

  • Page 5: Reset Configuration To Defaults

    Row 1: key-in “9600” Row 2: key-in “8” Row 3: key-in “none” Row 4: key-in “1” Row 5: key-in “none” Press OK 7. Start to aim the scanner at a bar code, you may see data shown on the hyper terminal.

  • Page 6: Maintenance

    few times to find what range of angles works best. Maintenance Cleaning the scan window is the only maintenance required. A dirty window may affect scanning accuracy. Wipe the scanner window gently with a lens tissue or other material suitable for cleaning optical material.
  • Page 7 conditions, failure to follow the instructions and warnings, or misuse or alteration or repair of the products without written approval.

  • Page 8: Setup From Bar Code Label

    Setup from Bar Code Label...

  • Page 9: Multi-Interface Functions

    Multi-Interface Functions – 1 OUTPUT FIRMWARE VERSION RESET CONFIGURATION TO DEFAULTS OUTPUT OUTPUT MODE – KEYBOARD / USB OUTPUT MODE - SERIAL MODE 000600 000601 BUZZER / GOOD READ BEEP TONE – NONE GOOD READ BEEP TONE - RESET 014200 0B142 IMAGE DECODE OPTIONS REVERSE IMAGE –...

  • Page 10: Reading Mode

    Multi-Interface Functions – 2 READING SCAN MODE – SINGLE SCAN SCAN MODE – SINGLE SCAN NO MODE TRIGGER 013300 013301 SCAN MODE – MULTISCAN SCAN MODE – MULTISCAN NO TRIGGER 013302 013303 SCAN MODE - PULSE 013305 LASER/CCD TIMEOUT – 5 SECONDS LASER/CCD TIMEOUT –...

  • Page 11: Transmit Speed

    Interface – KBW Communication WEDGE MODE - AUTODETECT WEDGE MODE – SCAN SET 2 PASS THRU 000200 000204 TRANSMIT TRANSMIT SPEED - 0 TRANSMIT SPEED - 25 SPEED 0000000 0000025 LANGUAGE KEYBOARD COUNTRY - USA KEYBOARD COUNTRY - GERMAN 0005000 0005010 KEYBOARD COUNTRY –...

  • Page 12: Interface - Serial

    Interface – Serial - 1 BAUD RATE SERIAL BAUD RATE - 2400 SERIAL BAUD RATE - 4800 000703 000704 SERIAL BAUD RATE - 19200 SERIAL BAUD RATE - 9600 000705 000706 HAND SHAKE SERIAL HANDSHAKE – XON/XOFF SERIAL HANDSHAKE - NONE 001200 001201 SERIAL HANDSHAKE –...
  • Page 13 Interface – Serial - 2 PARAMETERS SERIAL DATA BITS - 8 SERIAL DATA BITS - 7 00081 00080 SERIAL STOP BITS - 2 SERIAL STOP BITS - 1 00090 00091 SERIAL PARITY - ODD SERIAL PARITY - NONE 001000 001001 SERIAL PARITY - EVEN SERIAL PARITY - MARK 001002...

  • Page 14: Symbologies On/Off

    Symbologies On/Off - 1 CODE 11 CODE 11 - ENABLE CODE 11 - DISABLE 01261 01260 CODE 39 CODE 39 ENABLE CODE 39 DISABLE 00221 00220 FULL ASCII ENABLE FULL ASCII DISABLE 00231 00230...
  • Page 15 Symbologies On/Off - 2 CODE 93 CODE 93 - ENABLE CODE 93 - DISABLE 00621 00620 CODE 128 CODE 128 - DISABLE CODE 128 - ENABLE 00691 00690 CODE 128 ISBT - DISABLE CODE 128 ISBT - ENABLE 00701 00700 CODABAR CODABAR - ENABLE CODABAR - DISABLE...
  • Page 16 01061 01060...

  • Page 17: Upc-A Enable

    Symbologies On/Off - 3 MSI - ENABLE MSI - DISABLE 01151 01150 UPC/EAN UPC-A DISABLE UPC-A ENABLE 00341 00340 UPC-E DISABLE UPC-E ENABLE 00351 00350 EAN-13 ENABLE EAN-13 DISABLE 00361 00360 EAN-8 ENABLE EAN-8 DISABLE 00371 00370...

  • Page 18: Symbologies Set Up

    Symbologies Set Up - 1 CODE 11 CODE 11 ID CHARACTER – “m” CODE 11 ID CHARACTER – “Z” 0131m 0131Z CODE 11 LASER/CCD REDUNDANCY - CODE 11 LASER/CCD REDUNDANCY - ENABLE DISABLE 01321 01320 CODE 39 CODE 39 SS CHAR ‛+’ CODE 39 SS CHAR - NONE 002700 002704...

  • Page 19: Code 128

    Symbologies Set Up – 2 CODE 93 CODE 93 ID CHARACTER – “h” CODE 93 ID CHARACTER – “Z” 0066h 0066Z CODE 93 LASER/CCD REDUNDANCY - CODE 93 LASER/CCD REDUNDANCY - ENABLE DISABLE 00681 00680 CODE 128 CODE128 ID CHARACTER - ‛Z’ CODE 128 ID CHARACTER –...
  • Page 20 Symbologies Set Up – 3 CODABAR CODABAR ID CHARACTER –‛k’ CODABAR ID CHARACTER –‛Z’ 0094k 0094Z CODABAR LASER/CCD REDUNDANCY CODABAR LASER/CCD - ENABLE REDUNDANCY - DISABLE 00951 00950 Interleaved 2 of 5 I2OF5 CHECK DIGIT - DISABLE I2OF5 CHECK DIGIT - ENABLE 00970 00981 I2OF5 ID CHARACTER –...
  • Page 21 Symbologies Set Up – 4 ID2OF5 LASER/CCD REDUNDANCY - ID2OF5 LASER/CCD REDUNDANCY - ENABLE DISABLE 01141 01140 MSI CHECK DIGIT – MOD 10 MSI CHECK DIGIT –RESET 01160 0B116 MSI ISBN ID CHARACTER –‛f’ MSI ISBN ID CHARACTER –‛Z’ 0053f 0053Z MSI LASER/CCD REDUNDANCY - MSI LASER/CCD REDUNDANCY -...
  • Page 22 Symbologies Set Up – 5 SEND UPC-A CHECK DIGIT ENABLE SEND UPC-A CHECK DIGIT DISABLE 00421 00420 SEND UPC-E CHECK DIGIT ENABLE SEND UPC-E CHECK DIGIT DISABLE 00431 00430 SEND EAN-13 CHECK DIGIT ENABLE SEND EAN-13 CHECK DIGIT DISABLE 00461 00460 SEND EAN-8 CHECK DIGIT ENABLE SEND EAN-8 CHECK DIGIT DISABLE...
  • Page 23 Symbologies Set Up – 6 EAN-8 ID CHARACTER ‛d’ EAN-8 ID CHARACTER ‛Z’ UPC/EAN 0052d 0052Z ISBN ID CHARACTER ‛f’ ISBN ID CHARACTER ‛Z’ 0053f 0053Z UPC/EAN SUPPLEMENTS - DISABLE UPC/EAN SUPPLEMENTS – 2 DIGIT ONLY 00550 00551 UPC/EAN SUPPLEMENTS – 5 DIGIT ONLY UPC/EAN SUPPLEMENTS –...

  • Page 24: Edit Setup Bar Codes

    EDIT SETUP BAR CODES EDIT #1 – STRIP 1 LEADING CHARACTER EDIT #1 - OFF ON ALL BAR CODES THAT START WITH ‛12345’ 02000101000000100000000112345 0B20001 EDIT #2 – STRIP 1 TRAILING CHARACTER EDIT #2 – OFF 020002020000001 0B20002 EDIT #1 – FILTER LEADING SPACES EDIT #1 - OFF 020001030000032 0B20001...

  • Page 25: Macro/Special Keys Setup Bar Codes

    MACRO/SPECIAL KEYS SETUP BAR CODES MACRO #1 – FIND ‛1’ AND REPLACE WITH MACRO #1 - DISABLED ‛ONE’ 02010101011ONE 0B20101 MACRO #2 - DISABLED MACRO #2 – FIND ‛2’ AND REPLACE WITH ‛TWO’ FOR CODE 39 ONLY 0201023012TWO 0B20102 MACRO – FIND ‛0’ AND REPLACE WITH ‛A’ MACRO –...

  • Page 26: Termination String Setup Bar Codes

    TERMINATION STRING SETUP BAR CODES STRING #1 – TERMINATION CHAR - CR STRING #1 – TERMINATION - LF 0202011000$0D 0202011000$0A STRING #1 - DISABLE STRING #1 – TERMINATION CR+LF 0202011000$0D$0A 0B20201 STRING #2– CODE 128 TERMINATION CHAR - STRING #2 – CODE 128 TERMINIATION CHAR - 0202021080$0D 0202021090$0A STRING #2–...

  • Page 27: Factory Default Setting

    Factory Default Setting...
  • Page 28 Scanner Timing Default RS-232 communication Default Baud rate 9600 Parity None Data Bits Stop Bit RTS/CTS Terminator <CR> Keyboard Wedge Communication Default Terminal Type PC/AT Keyboard US keyboard Terminator Enter (Alpha numeric) USB Communication Default Terminator type Enter Code mode Scan Code Keyboard US keyboard...
  • Page 29 Appendix-A Troubleshooting & Error Beeps...

  • Page 30: Possible Cause

    a. Problem: Nothing happens when I follow the operating instructions. Possible Cause Possible Solution Interface cables are loose Check for loose cable connections b. Problem: When I connected RS232 interface reader to PC, I could not get power up signal. Possible Cause Possible Solution There is no power from PC series...
  • Page 31 d. My computer gets a keyboard error while booting up. Possible Cause Possible Solution The scanner is damaged or is no Disconnect the scanner from your longer functioning. computer and use your keyboard only. Reboot your computer. If your computer still gets a keyboard error, then the problem may not be the scanner.
  • Page 32 Problem: The scanner beeps, but no data is displayed on my computer. Possible Cause Possible Solution Scanner is not programmed for the Please make sure the scanner is correct host type. configured to the appropriate host type by scanning the corresponding programming barcode on the User’s Manual.
  • Page 33 Possible Cause Possible Solution The scanner’s transmit speed is too For RS232, you can set up the fast. scanner’s transmit speed. My Caps Lock LED on my keyboard flickers when I read a bar code. Possible Cause Possible Solution The Keyboard Country that you are This is normal operation.
