- Page 1 Electric Unicycle User Manual Electric Unicycle User Manual Before using your unicycle, please read the instructions, and keep this manual for ready reference. Original instructions...
-
Page 4: Getting Started
The SN is a 16-character numeric code that can be found on the packaging box label, the body of the product, or in the device information section of the INMOTION App. Get closer to your seller so he can refer you to an appropriate training organization. -
Page 5: Packing List
PACKING LIST Please carefully check all components inside the packaging. If any components are missing, please consult your point of purchase. Quick Start Guide User Manual User Manual Quick Start Guide L-shaped Wrench*1 Power Cord /Adapter Washers*2 M3 Countersunk screws*4 Set of Powerpads Set of Battery Corner Set of Collision Blocks... -
Page 6: Product Features
DIAGRAM Push rod button Dashboard Charging port Tail light Power button Handle Headlight Suspension spring Kickstand Battery Front mudguard Rear mudguard Pedal Wheel PRODUCT FEATURES Power On/Off: Long press the power button to turn on the device. In the powered-on state, long press the power button to turn off the device. - Page 7 Power Assist: Enabling this mode helps you achieve a more comfortable acceleration and braking experience. (1) Acceleration Assist: Adjust the value to achieve a more comfortable and rapid acceleration experience. A higher value results in faster acceleration. (2) Braking Assist: Adjust the value to achieve a more comfortable and rapid braking experience. A higher value results in shorter braking distance.
- Page 8 Damper Size 200mm Pedal Angle Adjustment Increase pedal angle: Align the M3 countersunk screw and washer with the screw hole below the pedal, and tighten using an L-shaped wrench.
- Page 9 Push Rod Unfold the push rod: Press the push rod lock button, and the push rod will automatically spring up. Fold the push rod: Press the push rod lock button, and then press the push rod down. Push rod button Dashboard Speed Bluetooth...
- Page 10 Speed Unit: Switch the display unit in the app. Battery Level: The battery indicator and the numerical display directly show the current battery level of the vehicle. Gear: Switch between D/S modes in the app. (1) D: Normal mode (2) S: Sport mode (3) P: Parking mode.
- Page 11 Specification Item Argument Length*Width*Height（mm） 478*228*680 Net weight（kg） Frame Max. payload（kg） IP ratings IP56 Rated capacity（Wh） 2277 IP ratings for battery IP67 Rated voltage（V） 115.2 Battery Pack Smart BMS Overcharging protection, over-temperature protection, over-discharge protection, overcurrent protection, short circuit protection, overvoltage protection, and etc.
-
Page 12: Initial Use
DIMENSION INITIAL USE Before Use Electric Unicycle is a high-tech recreation product. When you ride without following the operation specifications, it may lead to unpredictable injuries and property losses. The following will explain how to use Electric Unicycle and the precautions in details. - Page 13 Tips: Electric Unicycle supports Bluetooth 5.0 BLE. The BLE ID is Adventure-XXXXXXXX, where XXXXXXXX is the last 8 digits of SN. Install the INMOTION App on your mobile device (iOS 12.1 and above or Android 7.0 and above supported) and follow the prompts to connect your Electric Unicycle.
-
Page 14: Learning To Ride
LEARNING TO RIDE 1. Step on the pedal with one foot, then 2. Step on the pedal with one foot, keep 3. Step on the pedal with one foot, lift swing back and forth. your feet and body upright and the other foot off the ground for 1-2 gradually shift your weight up. - Page 16 INMOTION App Facebook group Website www.inmotionworld.com...
