Related Manuals for InMotion Explore V11Y
Summary of Contents for InMotion Explore V11Y
- Page 1 Electric Unicycle User Manual Electric Unicycle User Manual Before using your unicycle, please read the instructions, and keep this manual for ready reference. Original instructions...
-
Page 3: Getting Started
GETTING STARTED Thank you for choosing the INMOTION electric unicycle(hereinafter referred to as the unicycle)! This unicycle is an intelligent high-tech entertainment product. When you use the unicycle, there may be situations such as falling or collision that can cause injury and other risks. To reduce possible risks and ensure the personal and property safety of yourself and others, you have the responsibility and obligation to carefully read the user manual, fully understand all the warnings and precautions listed in this manual, and ensure that you can use it correctly. -
Page 4: Brief Introduction
BRIEF INTRODUCTION Check the Packing List Please carefully check all components inside the packaging. If any components are missing, please consult your point of purchase. Quick Start Guide User Manual Quick Start Guide User Manual Power Cord /Adapter Inflator Wrench *2 L-shaped wrench*2 Extended air nozzle Warning: Please keep the packaging box and packaging materials for at least 30... - Page 5 DIAGRAM Handlebar Handlebar switch Anti-tilt button Power pads Power on/off button Charging port Battery level display Bluetooth Fault indicator indicator Taillight Kickstand Rear mudguard Front headlight Front An ti -c oll isio n mudguard silicone Tire Footrest...
- Page 6 PRODUCT FEATURES INTRODUCTION Power On/Off: Long press the power button to turn on the device, and in the powered-on state, long press the power button to turn it off. Front Headlight: In the powered-on state, short press the power button to turn on the front headlight. Daytime running light (DRL): By default, the DRL is enabled when the device is powered on and can be disabled in the app or by simultaneously holding the anti-tilt button and the power button.
- Page 7 Handlebar switch Handlebar: Press the button under the handlebar to unlock and extend it. When not in use, hold the button under the handlebar to fold it back. Shock Absorption: Equipped with dual air spring shock absorption function. Note: Before use, be sure to inflate the air springs Parking Stand: Rotate the parking stand downward to following the inflation instructions.
- Page 8 PRODUCT FEATURES INTRODUCTION Specification Item Argument Range（km) Charging time（h) 6.6h with single charger；3.3h with dual chargers Rated Power（KW) Max.Power（KW) Basic Specs Max.torque（N.M) Max.speed（KM/H) Max.slope（°） 40° Suspension travel（mm） Length*Width*Height（mm） 555*180*744 Net weight（kg） 30.4 Frame Max. payload（kg） IP ratings IPX6 Rated capacity（Wh） 1423 IP ratings for battery IPX7...
- Page 9 Specification Item Argument Chrger Input AC 110-220V Charger Charger output DC 84V 2.5A Charger interface GX12-3PIN Configurationn Quantity of charger interface Working temperature（℃） -10-45 Requirments Storage temperature（℃） -20-45...
- Page 10 DIMENSION...
-
Page 11: Initial Use
INITIAL USE Preparation Before Use The unicycle is a high-tech entertainment product. Riding it without understanding the operational guidelines may lead to unforeseen injuries and property damage. The following instructions will provide users with detailed guidance on the correct usage of the unicycle and various precautions while using it. Please read them carefully and use the unicycle as instructed. Before using the unicycle, make sure that all its components are undamaged and properly installed. -
Page 12: Air Spring
The unicycle supports Bluetooth, with a BLE ID of: V11Y-XXXXXXXX, where XXXXXXXX represents the last 8 digits of the SN. Install the INMOTION App on your mobile device (iOS 12.1 and above or Android 7.0 and above supported) and follow the prompts to connect to your unicycle. - Page 13 Weight - Barometer Weight Air pressure Under 60kg 80-120psi 60-70kg 120-130psi 70-80kg 130-150psi 80-90kg 150-180psi 90-100kg 180-200psi Scan to check out the how-to video 100-130kg 200-220psi Pumping Port...
-
Page 14: Learning To Ride
LEARNING TO RIDE 1. Step on the pedal with one foot, then 2. Step on the pedal with one foot, keep 3. Step on the pedal with one foot, lift swing back and forth. your feet and body upright and the other foot off the ground for 1-2 gradually shift your weight up. - Page 16 INMOTION App Facebook group Website www.inmotionworld.com...
