- Page 1 Challenger Electric Unicycle User Manual Please wear an approved helmet, elbow pads, knee pads and other protective gear before riding. Please read the user manual and keep it for ready reference.
-
Page 3: About This Manual
1. About This Manual This manual applies to the electric unicycle Challenger V13 (hereinafter referred to as V13) produced by INMOTION Technologies Co.,Ltd. V13 is an intelligent, high-tech recreation product . When you use V13, there may be injuries caused by collision or falls and other risks. To reduce the possible risks and ensure the personal and property safety of you and others, please read this manual carefully and fully understand all warnings and precautions listed in it, then make sure you use it correctly. - Page 4 3. Diagram Trolley Lock Catch Dashboard Anti-Spin Button Power Button Charging Port Headlight Taillight Tail Bumper Front Bumper Rear Mudguard Tire Pedals 4. Functions Power on/off: Long press the power button to turn on the wheel. Long press the power button to turn off the wheel after powering on. Headlight: Press the power button to turn on/off the light after powering on;...
- Page 5 Charging Trolley The original charger is 126V 5A. Blue light indicates the Power Unfold: Pull up the lock catch, the trolley will bounce up automatically. is on, green light shows when the battery is fully charged, and Fold: Pull up the lock catch, then press down the trolley. red light indicates it's charging or completion of charge.
-
Page 6: Specifications
Specifications Specification Items Parameter Model V13Pro Basic specs Dimension 579x268x731mm Net weight Approx. 53.2kg Max. palyload 130kg Requirement to Rider Required height 120-200cm Recommended age 16-50 years Typical range [1] Approx. 95-150km Max. slope [2] Approx. 45° Max. speed [3] 90km/h Performance IP rating... -
Page 7: Initial Use
6. Dimension 790mm 268mm 490mm 731mm 579mm 579mm 579mm 7. Initial Use 7.1 Before Use V13 is a high-tech recreation product. When you ride without following the operation specifications, it may lead to unpredictable injuries and property losses. The following will explain how to use V13 and the precautions in details. Please read it carefully and use V13 as required. Before using, please make sure that all parts of V13 are not damaged and installed properly. - Page 8 V13 supports Bluetooth 5.0 BLE. The BLE ID is V13-XXXXXXXX, where XXXXXXXX is the last 8 digits of SN. Install the INMOTION App on your mobile device (iOS 8.0 and above or Android 4.4 and above supported) and follow the prompts to connect your V13.
-
Page 9: Damping Adjustment
7.4 Damping Adjustment For initial use, user can adjust the damper according to weight and preference as follows 1.Open the protective cover. 2. Take out the damping regulator from accessories, insert it into the damping 3. After adjustment, cover it tightly. adjusting port in the direction shown in the figure, turn the regulator, the damping decreases counterclockwise, and increases vice versa. - Page 10 7.6 Remove Air Suspensions and Dampers Scan to check out the how-to video How to Remove the Air Spring and Damper How to Install the Air Spring and Damper...
- Page 11 7.7 Learning to Ride 1. Step on the pedal with one foot, then 2. Step on the pedal with one foot, keep 3. Step on the pedal with one foot, lift the swing back and forth. your feet and body upright and gradually other foot off the ground for 1-2 seconds and shift your weight up.
- Page 12 INMOTION App Facebook Group Website Version: V1.0 Customer service center:service@imscv.com...
