InMotion V12Pro User Manual

Electric unicycle

Advertisement

Quick Links

V12Pro
Electric Unicycle User Manual
Electric Unicycle User Manual
Before using your unicycle, please read the instructions, and keep this manual for ready reference.
Original instructions

Advertisement

loading
Need help?

Need help?

Do you have a question about the V12Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for InMotion V12Pro

  • Page 1 V12Pro Electric Unicycle User Manual Electric Unicycle User Manual Before using your unicycle, please read the instructions, and keep this manual for ready reference. Original instructions...
  • Page 3: Getting Started

    The SN is a 16-character numeric code that can be found on the packaging box label, the body of the product, or in the device information section of the INMOTION App. Get closer to your seller so he can refer you to an appropriate training organization.
  • Page 4: Packing List

    PACKING LIST Please carefully check all components inside the packaging. If any components are missing, please consult your point of purchase. User Manual User Manual Power Cord /Adapter Warning: Please keep the packaging box and packaging materials for at least 30 days for future use when transporting the electric unicycle.
  • Page 5: Product Features

    PRODUCT FEATURES Power On/Off: Long press the button to power on/off. User is allowed to set the access code fo or Touch Screen via Inmotion App. Head-light: Under the status of power on, one more click the button to light on/off. The head- light could be light off on Touch Screen or INMOTION App.
  • Page 6 Charging The original charger is Dc100.8V/2.3A. The indicator of the charger is red/green,mean on-charging/charging completed. The USB port could be used for power output. Warning: • Do not charge if there is water at the charging port or Type-C power cord. •...
  • Page 7: Touch Screen

    4 set ofhigh-quality speaker were assembly in the front/rear body of V12Pro,and they could be connected with smart phone Decorative Light 6 set of decorative LED strip were assembly on the left/right body of V12Pro. Factory default lighting effect was provided, and user could DIY it as well.
  • Page 8 DIAGRAM Specification Item Argument Range(km) Charging time(h) Rated Power(Kw) Basic Specs Max.Power(Kw) Max.torque(N.m) Max.speed(Km/h) Max.slope(°) 45° Length*Width*Height(mm) 497*190*607 Net weight(kg) Frame Max. payload(kg) IP ratings IPX5 Rated capacity(Wh) 1750 IP ratings for battery IPX7 Rated voltage(V) 88.8 Battery Pack Smart BMS Overcharging protection, over-temperature protection, over-discharge protection, overcurrent protection, short circuit protection, overvoltage protection, and etc.
  • Page 9 Specification Item Argument Working temperature(℃) -10-45 Requirments Storage temperature(℃) -20-45 [1]: Typical range is obtained at full charge, with a load of 90kg, ambient temperature of 25°C, and riding at speeds of 20 to 40 km/h on a flat, paved road. The range of the wheel is influenced by factors such as temperature, tire pressure, road conditions, and riding habits (such as rapid acceleration and braking).
  • Page 10: Initial Use

    Tips: Electric Unicycle supports Bluetooth 5.0 BLE. The BLE ID is V12Pro-XXXXXXXX, where XXXXXXXX is the last 8 digits of SN. Install the INMOTION App on your mobile device (iOS 12.1 and above or Android 7.0 and above supported) and follow the prompts to connect your Electric Unicycle.
  • Page 11: Learning To Ride

    LEARNING TO RIDE 1. Step on the pedal with one foot, then 2. Step on the pedal with one foot, keep 3. Step on the pedal with one foot, lift swing back and forth. your feet and body upright and the other foot off the ground for 1-2 gradually shift your weight up.
  • Page 13 INMOTION App Facebook group Website www.inmotionworld.com...
  • Page 14 处数 变更者 版本 变更内容 日期 *制作以设计图纸内尺寸为标准 切割线 反折线 正折线 尺寸标注 出血位 李昌勃 电动独轮车法律声明(英文) 1 :1 单位 如图示 ±1mm 物料名称 内尺寸 公差 图纸比例 应用场景说明 设计师 材质: 外页157g双铜彩色印刷/内页80g书写纸/尺寸:160*140mm Q.LIB-000000948 注意事项: 料号 *材质印刷 电话 .输出图纸前,需确认图纸内容与尺寸正确,需发给组长与需求方审核确认 印刷颜色:按图印刷 .如实际制作图纸与定稿图纸内容有区别,需联系设计师调整更改 状态 *色号 签字(盖章确认) .最终制作出的成品与图纸有差别,需与设计师做沟通 审核 *技术要求 检验标准《乐行天下标签、贴纸测试标准》...
  • Page 15 Electric Electric unicycle unicycle Maintenance Maintenance and Legal Disclaimer and Legal Disclaimer Before using your unicycle, please read the instructions, and keep this manual for ready reference. Original instructions...
  • Page 17: Safety Notice

    For the first ride, do not select areas where children, pedestrians, pets, vehicles, bicycles, or other obstacles and potential dangers may appear. INMOTION Technologies Co., Ltd. will not be responsible for any damage caused by insufficient riding experience or failure to follow the instructions in this manual.
  • Page 18: Riding Instructions

    RIDING INSTRUCTIONS 1. When riding this product, please comply with local laws and regulations and policy requirements. It is prohibited to use it in areas where entry is prohibited by local laws and regulations or related management units. 2. When riding, please respect the right of way of pedestrians. Pass on the left side of pedestrians as much as possible. When facing pedestrians, keep to the right and slow down.
  • Page 19 13. Push a bicycle through a pedestrian crossing. 14. Do not touch moving or rotating wheels. 15. In order to ride safely, you must be able to see what is in front of you, and you must be visible to others. 16.
  • Page 20 Therefore, be sure to turn off the power before parking. Other 1. Only use original or Approved parts and accessories from INMOTION. Do not modify your unicycle. Modifying your unicycle may affect its operation, leading to serious damage and invalidating the warranty.
  • Page 21: Maintenance

    MAINTENANCE Cleaning Use a soft damp cloth to wipe the unicycle frame clean. If there are stubborn stains, Apply toothpaste and brush repeatedly with a toothbrush, then clean with a soft damp cloth. Warning: • Before cleaning, make sure the vehicle is turned off and the charger is unplugged, and the charging port cover is securely fastened, otherwise, electronic components could be damaged.
  • Page 22: Battery Maintenance

    Battery Maintenance Warning: • Use the original charger and battery pack. Do not use other models or brands of chargers and battery packs, as this may pose a safety risk. • Do not exceed the specified temperature limit (see "Technical Specifications") when storing or charging the battery. •...
  • Page 23 Warning: • Do not use this product near water. • Please stop using the product if it is damaged. • Keep plastic covers away from children to prevent choking. • Fire and electrical hazards - No user-serviceable parts. • Using the product in damp weather will increase braking distance. •...
  • Page 24 Certifications European Union Compliance Statement Information on Disposal for Users of Waste Electrical & Electronic Equipment This symbol on the product or on its packaging indicates that used electrical and electronic products should not be mixed with unsorted municipal waste. For proper treatment, it is your responsibility to dispose of your waste equipment by arranging to return it to designated collection points.
  • Page 25 Restriction of the use of certain hazardous substances (RoHS) Directive Declare the whole product including parts(cables. cords,and so on) meets the requirements of RoHS Directive 2011/65/ EU and amendment Commission Delegated Directive (EU) 2015/863 on the restriction of the use of certain hazardous substances in electrical and electronic equipment("RoHS recast"...
  • Page 26 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant  to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfe rence in a residential installation. This equipment generates uses and can radiate radio frequency energy and,  if not installed and used in accordance with the instructions, may cause harmful interference to radio commun ications. However, there is no guarantee that interference will not occur in a particular installation. If this equip ment does cause harmful interference to radio or television reception, which can be determined by turning the  equipment off and on, the user is encouraged to try to correct the interference by one or more of the following  measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 5mm between the radiator & your body.
  • Page 27: Trademark And Legal Statement

    4. If you provide any personal information, it is deemed that you fully agree that INMOTION can use and disclose it to affiliated companies.
  • Page 28: Trademark Statement

    2. This legal statement is applicable to the laws of the People's Republic of China. 3. INMOTION shall not be liable for any claims, liabilities, or losses caused or potentially caused by consumers or any third party's violation of this legal statement.
  • Page 29 INMOTION App: Me → Online Service. Notice: • When contacting INMOTION, please provide the serial number of your corresponding vehicle. You can find your vehicle's serial number on the vehicle nameplate or in the "Vehicle Management" → "About Vehicle" section of the App."...
  • Page 30 INMOTION App Facebook group Website www.inmotionworld.com...
