2.1 Outline

Item
Kit name
Kit product No.
Power supply
Operation temperature
Operation humidity
MOSFET
Sensor
Connector
Switch/Potentiometer
LED
Wave viewer tool
Note.1: The Evaluation Board has through holes for mounting the connector. When using this function, please mount the connector.
For details on this function, refer to- Chapter 4.
Note.2: The connector is mounted on the Evaluation Board.
R12UZ0130EJ0100 Rev.1.00
Nov 1, 2023

Chapter 2. Product Specifications

Table 2-1 Specification List for RAJ306102 RSSK
Renesas Solution Starter Kit
Motor Control Evaluation System
- Motor Control IC: RAJ306102 -
(RAJ306102 RSSK)
RTK0EML2J0S00020BJ
VM power supply range: DC 24[V]
Use a stable power supply such as a stabilized power supply equipment
or a battery.
The power supply to the VM provides 3.3[V] or 5.0[V] to the Control
Board from the built-in LDO of the smart gate driver.
Room temperature
No condensation
TPH12008NH (80[V], 24[A])
Hall sensor or sensorless
・ USB for E2 Lite (E2OB)
・ USB for Renesas Motor WorkBench (Now referred to as RMWB)
・ External MOSFET connector (CN_EXT_MOS)
・ Hall sensor signal input connector (CN_HALL)
・ Analog general-purpose input/output connector (CN_ANA)
・ Digital general-purpose input/output connector (CN_DIGI1)
・ I C communication connector (CN_I2C)
2
・ SPI communication connector (CN_SPI)
・ UART communication connector (CN_UART)
・ External volume connector (CN_VOL)
Toggle SW x2
Potentiometer x1
Tact switch for RESET x1
LED x7
Renesas Motor Workbench tool is supported
The latest tool is available from Renesas website
Chapter 2. Product Specifications
Specification
Note.1
Note.2
Note.1
Note.1
Note.1
Note.1
Note.1
Note.1
