3.1.4 Input terminal block (X3)
Opto-isolated inputs for clean contact signals or with PNP 24VDC transistor output.
First
Function
name
IN0
START
IN1
CCT
IN2
RESET
RED BASKETBALL
IN3
ENABLE
JOB SELECTOR
IN4
EMERGENCY OK
JOB SELECTOR
IN5
GREEN BASKETBALL
JOB SELECTOR
IN6
JOB SELECTOR
IN7
JOB SELECTOR
IN8
JOB SELECTOR
IN9
JOB SELECTOR
0VP
Input and output power
supply
+24P
Input and output power
supply
Maximum current of each single input
clamp
Description
X3.1
X3.2
X3.3
X3.4
For selection, see chapter 3.7
X3.5
For selection, see chapter 3.7
X3.6
For selection, see chapter 3.7
X3.7
For selection, see chapter 3.7
X3.8
For selection, see chapter 3.7
X3.9
For selection, see chapter 3.7
X3.10
For selection, see chapter 3.7
X3.11
Ground of the power supply of the "inputs and outputs" section
X3.12
Positive of the power supply of the "inputs and outputs" section
10mA
9
