Technical Support and E-Warranty Certificate www.vevor.com/support
TRUCK BED EXTENDER
MODEL:TZJ-01-01/TZJ-01-02
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for VEVOR TZJ-01-01
Summary of Contents for VEVOR TZJ-01-01
- Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support TRUCK BED EXTENDER MODEL:TZJ-01-01/TZJ-01-02 We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and doses not necessarily mean to cover all categories of tools offered by us.
- Page 2 CustomerService@vevor.com This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if...
- Page 3 Warning-To reduce the risk of injury, users must read the instructions manual carefully. WARNING: Read and understand this entire manual before assembling, installing, operating, or servicing this product. Failure to follow these warnings and instructions can cause death, personal injury or damage to valuable property.
-
Page 4: Assembly Preparation
PRODUCT PAREMETERS Model TZJ-01-01 TZJ-01-02 Range 51.6~64 in 55.5~68in Material Aluminum, Plastic Color Black Ford SuperDuty,F150, Ridgeline,Tacoma,Gladia Dodge Ram 1500/2500/3500, Fitment tor,Colorado/Canyon, Toyota Tundra,Nissan Titan, Frontier,ranger Chevrolet Silverado ASSEMBLY PREPARATION When unpacking this product, check to make sure the parts listed below are included and carefully inspect for any damage that may have occurred during transit. - Page 5 PART PART PICTURE PICTURE NUMBER NUMBER Bumper Upright Hex key Assembly Strap Buckle Bumper Assembly Pivot Upright Hex Nut M6 Assembly Quick Mount Lock nut M5 Bracket set Straight Drill Bit φ4.1 Tube Strap Latch Bent Tube Insert φ15 Phillips Strap Latch Head Screw Insert...
- Page 6 PRODUCT ASSEMBLY EXPLODED TOOLS REQUIRED Phillips Screwdriver Torx T-25 Driver Power Drill φ4.1 Drill Bit Center Punch Supplied templates Soapy Water 1. Assembly Procedures Disassemble Part B with supplied Hex Key “ ” Assemble Part C and F with supplied Hex Key “...
- Page 7 Put on Part 2 Strap Buckle Assembly B on the middle tube. NOTE: Make sure the Strap Latch Insert is towards the inside after assembly as picture shown Apply straight tubes E to Part 2 of the assembly from Procedure-3. 2.
- Page 8 Use the center punch to mark screw holes for preparation of drilling. Use a power drill and φ4.1 drill bit to drill through the sheet metal. If equipped with a bed liner, drill through the bed liner as well. Fasten Bracket D with Screw H by using a Phillips screw...
- Page 9 Tips: black U-shaped frame is an optional accessory. If width carriage is not on the same horizontal line as the tailgate, it needs to be installed (as shown in the figure). If the width of the carriage is on the same horizontal line as the tailgate, it does not need to be installed.
- Page 10 Insert “ ”into the Quick Mount Bracket, and put” ”back on the brackets Adjust Strap Buckles to lock into the tailgate when Bed Extender is deployed. Your assembly is now complete. Tips:Strap Latch Insert is supplied in 2 diameter sizes, you can choose to properly fit your tailgate latch.
- Page 11 When the Bed Extender is at the furthest rear position. Push down on the the buckle to insert it into tailgate latch. Tighten straps. To release, pull the tailgate handle. NOTE: Ensure that buckles are properly inserted into latches by pulling on the straps after both buckles have been inserted.
- Page 12 Technical Support and E-Warranty Certificate www.vevor.com/support Made in China...
