- Page 1 © 2009, Videolarm, Inc. All Rights Reserved S M 7 C S - 9 , S M 7 C 1 2 S - 9 SView™ Series Installation and Operation Instructions for the following models: Before attempting to connect or operate this product, please read these instructions completely.
-
Page 2: Limited Warranty
1. NOTIFICATION OF CLAIMS: WARRANTY SERVICE: If Purchaser believes that the Product is defective in material or workmanship, then written notice with an explanation of the claim shall be given promptly by Purchaser to Videolarm but all claims for warranty service must be made within the warranty period. -
Page 3: General Instructions
SM75C2N IP Ready Network Housing Outdoor vandal resistant surface mount ptz IP camera system that can be mount facing down or facing towards the sky. 23x zoom Day & night camera. MPEG-4 & MJPEG video compression format, Full D1. Clear dome, w/24Vac input, heater/blower ELECTRICAL SPECIFICATIONS (OUTDOOR ONLY): (SM7CS-9) - Page 4 WIRING INSTRUCTIONS (OUTSIDE OF HOUSING) Wiring Color Code Power and Control Inputs (SM7CS-9) POWER Camera Power (24 VAC) Camera Power (24 VAC) Heater and Blower Power (24 VAC) Yellow Heater and Blower Power (24 VAC) Green (heater and blower not included on indoor unit) Wiring Color Code Power and Control Inputs (SM7C12S-9) POWER...
- Page 5 INSTALLING THE HOUSING ASSEMBLY: Be sure the bracket is properly and securely mounted to a supporting structure capable of rigidly holding the weight of the entire unit. INSTALLING OPTIONAL WALL MOUNT 1. Choose the desired location for installation and mark the drill holes using the template.
- Page 6 SETTING PROTOCOL FOR THE UNIT There are no user settings for protocol selection. The MR7CS-9™ will respond to Pelco D, Pelco P, or Videolarm VL422 protocol automati- cally (1 start bit, 1 stop bit, 8 data bits, no parity). Factory Settings...
- Page 7 TEMP - This displays the temperature sensor data on the tilt board. Press "zoom in" to turn this on, "zoom out" to turn it off. NOTE: This reading will be higher than the actual ambient temperature in the dome. This is for diagnostic use only. PRESSURE - This displays the pressure sensor data for units equipped with a pressure sensor.
-
Page 8: Other Features
SYSTEM INFO - Displays the Pan Version, Tilt Version, Current Pan Position and Current Tilt Position. PRESETS - Allows the selection of the dwell times for each of the 64 presets. When this submenu is selected, the dwell time for each of the 64 presets is displayed. - Page 9 DIPSWITCH SETTINGS: Address Dip switch settings, refer to Table 1. Table 1: Pan/Tilt Address Dip Switch Settings ADDRESS ADDRESS - 9 -...
- Page 10 ADDRESS ADDRESS - 10 -...
- Page 11 ADDRESS ADDRESS - 11 -...
- Page 12 Exploded View for Replacement Parts - 12 -...
- Page 13 Exploded View for Replacement Parts (Surface Mount) Replacement Parts List Part Number RPSM7501 RPRH7502 RC7T RC7C RPRH7503 RPSM7511 RPSM7512 RPSM7513 RPSN7514 RPSM75040 RPPKH2090 RPPKH2100 RPPKH2130 Description DOME SEAL LOWER TRIM RING TINTED REPLACEMENT CAPSULE CLEAR REPLACEMENT CAPSULE DOME CLAMPING BRACKET HOUSING TOP MOUNTING HOLE CLOSURE CONDUIT HOLE CLOSURE...
- Page 14 Exploded View for Replacement Parts Replacement Parts List Part No. RPFD060 RPFD080 RPFD072 RPFD050 RP-TRAN03 RP40BRTRAN3 RP96VL2413 RP40BRB38504 RPVL2982R0 RP76POF0605E RP70P1401S Description Camera Bracket Blower (2) 24VAC Heater (2) Connection PCB 24vac to 12vdc Power Supply Power Supply with Bracket Pan Tilt Base Gasket Pan/Tilt Base (Network) IP Bracket...
- Page 15 Exploded View for Replacement Parts Replacement Parts List Part No. RP6039mm1.8 RPVL2314 RP40CASL385 RPVL2315 RP605007 RPVL2316 RPVL2318 RPVL2320 RP605011 RP73CAVKS454 RP92WSFN11 RP605009 RP605008 RP95FSSR06 RP95FSSR07 RP605010 RPVL2312R1 RP76V385T RP76V385P RPVL2317 RPVL2321 Description Motor (2) Hub Bracket Slip Ring Assembly (2) 20T 80 Pitch Pulley (2) Bearing 90T Pan Pulley...
-
Page 16: Product Registration/Warranty
Product Registration/Warranty Thank you for choosing Videolarm. We value your patronage and are solely committed to providing you with only the highest quality products available with unmatched customer service levels that are second-to-none in the security industry. Should a problem arise, rest assure that Videolarm stands behind its products...
