INSTRUCTION MANUAL
SF30M series
ITEM NO.:
AUTOMATIC SCREW SUPPLIER
SF30M series-I-1912A-YM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SF30M Series and is the answer not in the manual?

Questions and answers

Related Manuals for Sumake SF30M Series

Summary of Contents for Sumake SF30M Series

  • Page 1 INSTRUCTION MANUAL SF30M series ITEM NO.: AUTOMATIC SCREW SUPPLIER SF30M series-I-1912A-YM...

  • Page 2: Table Of Contents

    SF30M Automatic Screw Feeder Instruction Manual Table of Contents Instruction ･･･････････････････････････････････ Item inspection････････････････････････････････ III. Safety precautions･･････････････････････････････ Specification 1.exterior ･････････････････････････････････････ 2.working environment ････････････････････････････ 3.weight ･･････････････････････････････････････ Parts Nomenclature t view ･･････････････････････････････････ 1.fron view･･･････････････････････････････････ 2.rear Installation ･･･････････････････････････････････ VII. Pre-job Checking･･･････････････････････････････ VIII. Test run･･････････････････････････････････････ Operating Steps･･･････････････････････････････...
  • Page 3 1.air volume adjustment ････････････････････････････ 2.adjustment of escapement speed ････････････････････ 3.regulating plate adjustment ･ ････････････････････ 4.torque adjustment and BIT replacement ･･････････････ Troubleshooting 1. Screw can’t reach tip of screwdriver ･･････････････････ 2. Screw can’t fed through escapement ･･････････････････ 3. Screw can’t fed through delivery hose ････････････････...
  • Page 4 I. Introduction The SF30M automatic Screw Feeder is suitable to automatic production to saves the trouble of manually picking screws as practiced conventionally. Furthermore, the machine can feed the screw to screwdriver also screwing to work-piece automatically. The working stability characteristic can enhance productivity, reduce human cost. II.

  • Page 5: Safety Precautions

    III. Safety precautions Follow instructions depicted in the manual and operate the machine correctly. ＜Be sure to follow the instructions＞ 1. Warning sign： 【Prohibition Sign】Fire, electric shock, or personnel injury or death may occur if not observed 【 Alarm Sign】Damage of properties, or electric shock or injury of personal may occur if not observed.
  • Page 6 2. Safet y rules NOT let contaminants such as water or oil enter into machine Please connect use correct voltage to work. Follow instructions depicted in the manual and operate the machine correctly. DO NOT dismantle or modify the machine. If machine smoke, dropped from high place, Influent, please remove the power cord and send the product for repair.

  • Page 7: Specification

    IV、Specification 1. exterior: Model L / W / H Weight Voltage Air Pressure SF30M 35 / 25 / 38 (cm) 22 kg AC 110V / 220V 5 ~ 6 kg / cm 2. Working environment: Model SF30M Voltage Screw feeder Electric screwdriver AC 110V / 220V AC 110V / 220V...

  • Page 8: Parts Nomenclature

    V、 Parts Nomenclature front view Torque reaching signal Feed signal connector Man./auto switch Screwdriver start Air hose connector timer power signal Air volume adjustment Rail sensor valve Feeder outlet right valve left valve...

  • Page 9: Installation

    2.reae view Air pressure switch Air unit Air pressure gauge Air source connector VI、Installation 1. install the delivery hose, screwdriver start / torque reaching/ feed signal connector, air hose to screw feeder. (make sure all lines is smoothly.) 2. connect air source.
  • Page 10 3. adjust air pressure ( 5 ~ 6 ㎏/ cm ） Pull the switch the turn by clockwise Push the switch after correct setting 4. check feed timer setting should be around 0.5 sec. Note: The timer setting is different for different delivery hose length. Check timer switch (1).

  • Page 11: Pre-Job Checking

    VII、 Pre-job Checking Install each item correctly. Confirm that all power connectors, signal joint and air joint are properly installed in place. Confirm the input power is correct. Confirm the cylinder are positioned. Confirm that all parts are securely locked Confirm the working air pressure (at 5.5(±0.5)kg/cm )。...
  • Page 12 ｢FIG.1｣ 5.the cylinder move forward after releasing lever (feeding) see Fig.2 ｢Fig.2 6.The cylinder will retract after few seconds, the screwdriver is ready to work. See Fig.1 7.there is no screw for first using. Do step 4.5. then the screw feeder to BIT. ｢Fig.3...
  • Page 13 4.check if working correct: check if screwdriver work correct after press lever, and no noise. ◼ ◼ Check if delivery hose, cable is smooth or not. 5.Check torque setting is correct. Use screwdriver to tighten first screw to make sure torque setting. ◼...

  • Page 14: Operating Steps

    IX、Operating steps The machine can work after test run. 2. Aim screw to screw hole vertical and press the lever. 3. Move the screwdriver upward after screwing to avoid jaw set impact to work-piece when during cylinder movement. 4. Do step 2.3 to continue working after feeding next screw.

  • Page 15: Adjustment And Replacement

    X、Adjustment and replacement 1. air volume adjustment ： If the screw can’t reach to screwdriver within feeding time, please adjust air volume by procedures as below. a. Use wrench to release nut of escapement. Then use wrench to adjust screw by procedures as below. ※...

  • Page 16: Regulating Plate Adjustment

    3. regulating plate adjustment ： If the regulate plate is too high or low, please adjust by 4 ㎜ hex-wrench and 8mm wrench to adjust. Adjust screw 4.torque adjustment and BIT replacement lease remove air source, turn off power of Torque adjust ring screw feeder and electric screwdriver if need to replace BIT or adjust torque setting.

  • Page 17: Screw Can't Fed Through Escapement

    *Please【refer to VI.】 (5) If screw can’t fed in normal condition. * Make sure there are screws in hopper.；If yes, please press lever for 1 second then release. Screw can’t fed through escapement ： Please turn off power and air. ◆...

  • Page 18: Electric Screwdriver Breakdown

    (2) The torque setting of the screwdriver is too large to damage the screw hole type. Please adjust the screwdriver torque setting ➢ (3) The BIT is bent and cannot be accurately aligned to the screw position. Check if the BIT is bent ➢...
  • Page 19 4. The cylinder is not fixed, ten the BIT will affect for feeding action. ➢ Remove air source and delivery hose, see Fig.4/5 ｢Fig.5｣ ｢Fig.4｣ Delivery hose Air inlet move head base forward and see if BIT block feeding. See Fig.6 ➢...

  • Page 20: Maintenance

    5. Didn’t feed screw (1) The electric screwdriver set for “reverse” Please change electric screwdriver to “forward”see ｢Fig.8｣。 ➢ (2) electric screwdriver set for “forward”: ➢ Turn the Mau./Auto. Switch to Auto. see｢Fig-9｣。 Electric screwdriver switch (R/F) ｢Fig-9｣ ｢Fig-8｣ ※ If the above trouble event happened, please contact dealer or our company.
  • Page 21 Caution please connect 5×8 ㎜ PU hose to air unit before drain. Please supply oil (w10) Connector for drain (3) Clean escapement and rail Use air gun to clean regularly ➢ ➢ Use cotton dip alcohol to clean track.
  • Page 22 EU Declaration of Conformity (DOC) SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： AUTOMATIC SCREW FEEDER Model/ Serial No.： SNF-A1, SNF-A2, SNF-A3, SNF-A4, SNF-A8, SNF-A9, SNF-A10, SNF-A11, SNF-A12, SNF-A13, SF40TH, SF30A,...
  • Page 24 NOTE www.SUMAKE.com www.AIRCOMPRESSOR.com.tw...
