In-back/Out-back Cooling Kit for FK09c/FB09c and FK10c/FB10c
Installation Guide
Table 2: Items Supplied in In-back/Out-back Cooling Kits
Item
Top flange spacer
Top cover
Top cover gasket
Drive slot gasket
Bottom bracket
Base plate gasket
Base plate
Front spacer
Bottom cover gasket
Bottom cover
M5x12 screw
M5x16 countersunk screw
M5x18 screw
Back vent spacer
Back vent gasket
