Danfoss 176F4190 Installation Manual page 12

In-back/Out-back Cooling Kit for FK09c/FB09c and FK10c/FB10c
Installation Guide
2.9 Pedestal-mounting the Frequency Converter
To mount the FK09c or FK10c frequency converter on a pedestal, use the following steps. See
TIPPING PRECAUTION
If not properly secured, the frequency converter can tip and cause serious injury.
-
After attaching the frequency converter and pedestal to the floor, secure the top of the frequency converter to the wall or
mounting panel.
Procedure
1. Using the dimensions in
33.1
(1.3)
Illustration 11: Dimensions for Mounting FK10c Frequency Converter
12 | Danfoss A/S © 2023.09
W A R N I N G
Illustration 8 for FK09c or Illustration 11
Ø11
(0.43)
Illustration 11
for FK10c, prepare the mounting surface.
280
(11.0)
320
(12.6)
436
(17.2)
AN371942578354en-000101 / 136R0290
Installation
to Illustration 16.
