Windows Licensing
To run Windows® 10 Enterprise 2019 LTSC on the RUGGEDCOM APE, the Windows®
operating system must be activated after the RUGGEDCOM APE module has been
installed.
For more information, refer to the product key sticker (included in the product
packaging) and
help/12440].
Microsoft products are not designed or intended for use in any system or application
where failure or fault of any kind could lead to death or serious bodily injury of any
person, or severe physical or environmental damage, otherwise considered high risk
use. High risk use is strictly prohibited.
1.2

Requirements and Restrictions

Note the following requirements and restrictions for using the RUGGEDCOM APE:
•
•
•
RUGGEDCOM APE (Application Processing Engine)
Configuration Manual, 08/2023, C79000-G8976-1415-06
Windows® Support [https://support.microsoft.com/en-us/
NOTICE
Chassis Operating System
The RUGGEDCOM RX1500-series chassis must have RUGGEDCOM ROX v2.12.4 or
higher installed.
Operating Temperature Range
Each module is rated for operation within the temperature range of -40 to 75 °C
(-40 to 167 °F).
Power Consumption
When using the RUGGEDCOM APE module in combination with other line
modules – including other RUGGEDCOM APE modules – make sure the total
power consumption of all installed line modules does not exceed the power
budget of the RUGGEDCOM RX1500 host device.
NOTICE
Electrical hazard - risk of power failure
Installing more modules than allowed on a RUGGEDCOM RX1500 device can
lead to power fluctuations and irregular shut downs.
Module Power Consumption
Module Type
RUGGEDCOM APE1808
RUGGEDCOM APE1402
RUGGEDCOM APE1404
2-Port Fiber Optic (FG50 + SFPs)
6-Port Fiber Optic (6FX50)
WAN Cell (3G, LTE)
1.2 Requirements and Restrictions
Power Consumption
12 W
10 W
10 W
7 W
7 W
7 W
