Installation Instructions
57' Aurora Tent
Non-Certified Installation
Modified from Fully Certified Version
Please read all assembly / installation instructions before the installation or removal of this product.
7701 Highway 41 N
Evansville, IN 47725
Phone: 812-867-2421
Fax: 812-867-1429
1-800-544-4445
email: tents@anchorinc.com
www.anchorinc.com
EC 6067
AU57NC-124
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Anchor Aurora 57
Summary of Contents for Anchor Aurora 57
- Page 1 Installation Instructions 57’ Aurora Tent Non-Certified Installation Modified from Fully Certified Version Please read all assembly / installation instructions before the installation or removal of this product. 7701 Highway 41 N Evansville, IN 47725 Phone: 812-867-2421 Fax: 812-867-1429 1-800-544-4445 email: tents@anchorinc.com www.anchorinc.com EC 6067 AU57NC-124...
-
Page 2: Table Of Contents
Index Introduction ......................3 Safety Notes........................ 3 Parts Illustrations......................4 Part Numbers Chart.......................5 Stake and Pole Layout....................5 Tent Layout........................6 Stake Bars........................6 Lacing........................... 6 Lace Flap........................7 Attach Guys........................7 Raise Poles......................... 8 Winch Tensioning......................8 Final Adjustment......................9 Take Down........................9 Walls.......................... -
Page 3: Introduction
The requirements as specified must be followed. The installer/ owner must read the assembly instructions completely prior to any installation. Particular attention must be given to anchor- ing! See Caution Statement on back page of this manual Work from step to step. -
Page 4: Parts Illustrations
IMPORTANT: The installation of this Tent should be performed/supervised by knowledgeable tent installers with a clear understanding of safety issues as well as the methods of anchoring. The installer/owner must read the assembly instructions completely prior to any installation. Particular attention must be given to anchoring! See Caution Statement on back page of this manual. -
Page 5: Part Numbers Chart
Part Numbers Chart PART NUMBERS AND DESCRIPTIONS Install/Staking 33000 2’ Stake Bar 23000 2" Web guy and winch (22015 & 33200) 8048617 Aurora web guy assembly 3704242 Stake 1 1/8” x 42” - Double Head 8048613 Install Kit (Layout Cable, 4 Web Loops, 4 Web Guys) 8049355 57’... -
Page 6: Tent Layout
Tent Layout: Lay Ground Cloth over the area to be covered by the tent. Unfold the tent top fabric over the ground cloth, with right side up. Unfold and stretch fabric out so that side pole plates match placement marked on ground. -
Page 7: Lace Flap
Finishing Lace: At bottom of Lace, Tie off long loop to bottom loop as shown. Fasten snap to web loop. Fastening Lace Flap: Go back up to center pole hole and begin fastening flaps together. Walk on tent with stocking feet for protection of fabric. -
Page 8: Raise Poles
Raise Side Poles: Insert the sidepoles into the grom- mets and plates around the perim- eter. Stand up to nearly vertical and apply just enough tension on guys to keep poles in position. Raise Center Poles: From underneath the tent, insert the pin of the centerpole through the grommet at the peak and push the pole with the fabric up until the... -
Page 9: Final Adjustment
Final Adjustment: Due to changes in climactic conditions, periodic inspection and adjustment should be made. Protective covers are recommended for all stakes and stake bars. Important: Check guys periodically for tight- ness and maintenance of good condition. Proper installation suitable to site conditions is the responsibility of the installer. -
Page 10: Flag Pole Installation
Aurora Flag Pole Installation Instructions Knurled Knob screwed into top of pole to secure PVC Flag assembly on pole. PVC Flag Assembly fitted onto Flag Pole Tent is trapped between Flag pole. welded Flange and bottom Flange. Flange welded to Flag Pole. Top holes of tent fabric at lace. -
Page 11: More Staking Layouts
MORE STAKING LAYOUTS 56'-8 1/2" 96'-8 1/2" 28'-4 1/4" 28'-4 1/4" 28'-4 1/4" 20'-0" 20'-0" 28'-4 1/4" 10'-0" TYP. 116'-8 1/2" Stake guys out at 1’-0” less 28'-4 1/4" 20'-0" 20'-0" 20'-0" 28'-4 1/4" than Side Pole Height. Typ. 10'-0" for all layouts. -
Page 12: Queen/King Mids - Left Right Designation
156'-8 1/2" 28'-4 1/4" 20'-0" 20'-0" 20'-0" 20'-0" 20'-0" 28'-4 1/4" 10'-0" TYP. QUEEN/KING MIDS - LEFT RIGHT DESIGNATION LEFT RIGHT PLAN VIEW LEFT RIGHT SIDE VIEW... -
Page 13: Caution Statement
Regardless of the number of stakes we suggest, we make no representation or warranty as to whether this speci c number of stakes will meet the local tent code. Anchor does not, nor can it make any suggestions, representation, or warranties about the adequate staking required at each speci...
