Anchor Fiesta Assembly Instructions Manual

24’ through 30’ wide systems with expandable kits

Hide thumbs Also See for Fiesta:

Table of Contents

Assembly Instructions

Fiesta

24' through 30' Wide Systems

SALES OFFICES:

1100 BURCH DRIVE

PO BOX 3477

EVANSVILLE, IN 47733 USA

EC 3190

Frame Tent

With Expandable Kits

PHONE: 812-867-2421

FAX: 812-867-0547

1-800-544-4445

EMAIL: tents@anchorinc.com

www.anchorinc.com

PRODUCTION FACILITIES:

EVANSVILLE, IN

Fi2430 0706

R2 04-14

Table of Contents

Do you have a question about the Fiesta and is the answer not in the manual?

Page 1: Assembly Instructions
Assembly Instructions Fiesta Frame Tent ® 24’ through 30’ Wide Systems With Expandable Kits SALES OFFICES: PRODUCTION FACILITIES: PHONE: 812-867-2421 1100 BURCH DRIVE FAX: 812-867-0547 EVANSVILLE, IN PO BOX 3477 1-800-544-4445 EVANSVILLE, IN 47733 USA EMAIL: tents@anchorinc.com www.anchorinc.com Fi2430 0706...
Page 4 Warning: Do not drag fabric tent top across hard or rough surfaces as abrasion from tent hardware is possible.
Page 5 4’-0” (2) 10” nails in each base plate. Hammer down ﬂ ush with base plate to secure. 4’-0”...
Page 6 Connect 2-pc ridge and pin to PTTs using the PTRE pointed downward so that the ridge is elevated. Pin cross bars together and attach to frame as shown.
Page 7 PTRE Slide PTR on to 10’-0” ridge. Align with hole at center of ridge and pin. Repeat for each 10’-0” ridge. Pin 10’-0” ridges together and add existing ridges to each end. Lift and pin assembled ridges to PTT’s, using the PTRE pointed downward so that ridges are elevated.
Page 8 Regardless of the number of stakes we suggest, we make no representation or warranty as to whether this speci c number of stakes will meet the local tent code. Anchor does not, nor can it make any suggestions, representation, or warranties about the adequate staking required at each speci c installation site.
