The V-2924 Control Unit provides access to 24 stations. A V-2925 Expansion Unit is available for the V-2924.
Each V-2925 Expansion Unit will increase the capacity of the V-2924 by twenty-four (24) additional stations. Up
to three (3) Expansion Units can be added to a system for a total of 48, 72, or 96 zones of paging.
A V-2926 Plug-in Option Board is also available to provide enhanced Caller ID, flexible architectural numbering,
user defined page groups, a secondary serial port for easier programming and real-time clock. A Windows-based
programming tool is used with the option board to simplify system programming. The tool can be used with PC
compatible computers using the Microsoft Windows operating system.
"WARNING: To reduce the risk of fire or electric shock, do not expose this appliance to rain or
moisture."
"WARNING: Shock hazard – Do Not Open."
"AVIS: Risque de choc Electrique ne pas Ouvrir."
"PELIGRO: Corriente Electrica – No Abres."
FEATURES
24 zones of handsfree or one-way
communication (expandable up to 96 zones)
Built-in handsfree amplifier
Background music input
Built-in all call with "meet me" and "follow me"
capability
"Ring in" from speaker locations
Calls placed in queue
Dial tone programmable (On/Off)
Alert tone
Ringback tone
Repeated alert/privacy tone programmable
(On/Off)
Auxiliary contact closures for zones 21, 22, 23,
24
Programmable ring pattern
Ring contact closure follows ring cycle
Inhibit input
Caller identification
RS-232 serial printer port
Control unit is internally powered (battery
backup compatible; (1) VPB-260 per unit)
Override port
Emergency tone input
Time tone input
UNA contact closure input
All call/priority page through up to six V-2924
systems of any size
Group call
Programmable class of service
CAPACITY
The V-2924 is a single talkpath unit.
The maximum number of speakers per zone:
one 45 ohm speaker and/or forty (40) one-way
amplified speakers.
NOMINAL SPECIFICATIONS
These units are not intended for direct or indirect
connection to the public telephone network. When
used with a customer premise telephone system such
as a key system or PABX system, these units are
interfaced to the system via a fully protective paging
port or a system central port, which are fully
protected interface devices. Additionally, the host
system must be configured to disallow a central
exchange trunk conferencing in order to prevent
indirect connection to the network.
Attendant Port
Loop Start Access (E-Key C. O. Line Position,
Single Line Phone, Trunk Port of PABX)
DTMF Access
Caller ID Compatible
Tip and Ring Input Impedance:
Tip and Ring Input Level:
Ring Supply
90 VAC, 30 Hz - Ring Patterns:
2 sec ON, 4 sec OFF
1 sec ON, 4 sec OFF
Double Ring
Override Page Port
Loop Start Access (E-Key C. O. Line Position,
Single Line Phone, Trunk Port of PABX)
Telephone System Page Port Access
Tip and Ring Input Impedance:600
Tip and Ring Input Level:
2
600
-10 dBm nominal
American
Dutch
British
-10 dBM nominal
947211
