Controls and Lights
Navigation Buttons •
5-way Navigation Control
•
Five program buttons : CAMERA, COMM MANAGER, MESSAGING, INTERNET EXPLORER MOBILE,
VOICE COMMAND
•
Two phone functions : TALK and END
•
START MENU button
•
Two OK buttons
•
Two soft keys
•
Jog Wheel
•
POWER button
•
RESET button
•
WLAN switch
Hardware Keyboard
QWERTY keyboard with two additional soft keys, and an ambient sensor that detects low light and
automatically illuminates the keyboard.
LEDs
The left LED shows the following:
• A blinking Blue light for Bluetooth system notification of powered-up and ready to transmit radio
frequency signal.
• A blinking Green light for Wi-Fi status.
• When both Bluetooth and Wi-Fi are enabled, their lights blink alternately.
The right LED shows Green and Amber lights for CDMA standby and network status, notification,
and battery charging status.
Audio
Microphone/
Built-in/Dual, Hands-free
Speaker
Headphone
MP3/WAV/WMA/AAC/AAC+ codec
Expansion Slots
Memory Card Slot
microSD
TM
