System Smartphone Edition in a compact flip phone design to give you the convenience of Windows and the comfort of a familiar shape. Using ActiveSync , you can keep your PC and PN-820 synchronized at all ® times. The PN-820 offers the multiple features listed below which are designed to enhance your mobile experience.
CHAPTER 1. BEFORE USING YOUR PHONE ...9 ACTIVATING YOUR PHONE ... 10 SETTING UP YOUR VOICEMAIL ...11 SET UP VOICEMAIL ...11 CHECK VOICEMAIL ...11 Chapter 1 INSIDE THE PACKAGE ... 12 HANDSET DESCRIPTION ... 13 HOME SCREEN ... 14 HOME SCREEN CUSTOMIZATION ... 14 HOME SCREEN ICONS ...
Page 4
CHAPTER 3. MEMORY FUNCTION ...39 MAKE A CALL ... 40 MAKE A CALL FROM THE CALL HISTORY LIST ... 40 MAKE A CALL USING A RECENTLY DIALED PHONE NUMBER ... 40 ENTERING TEXT AND NUMBERS ... 41 ENTERING TEXT AND NUMBERS ... 41 CHANGE BETWEEN UPPERCASE, LOWERCASE, AND CAPS LOCK ...
Page 5
INSERT AN INTERNATIONAL COUNTRY CODE ... 67 SEND AN E-MAIL MESSAGE FROM CALL HISTORY ... 68 SETTINGS ... 69 ACCESSIBILITY SETTINGS ... 69 POWER MANAGEMENT ... 70 REGIONAL SETTINGS ... 71 SELECT DEFAULT BAND ... 72 DISPLAY YOUR PHONE NUMBER ... 72 DISPLAY YOUR ESN ...
Page 6
CONTENTS VIEW MMS MESSAGES ...116 SELECT MMS IN THE LIST OF MESSAGE TYPE ...116 MMS SETTINGS ...118 USE MMS CLIENT ...119 START MMS CLIENT ...119 MESSAGING SETTINGS ... 120 CHANGE MESSAGING ACCOUNT OPTIONS ... 120 CHANGE HOW THE MESSAGE LIST DISPLAYS ... 120 CREATE A MESSAGE FROM A CONTACT CARD ...
Page 7
CHAPTER 6. PICTURES & VIDEOS, CAMERA, FUN & GAMES ...149 PICTURES & VIDEOS ... 150 SELECT VIDEO QUALITY ... 150 COPY AN IMAGE TO YOUR PHONE ... 151 TAKE PICTURES USING A TIMER ... 152 ADJUST PICTURES AND VIDEO FOR LIGHTING CONDITIONS ... 153 SELECT WHERE PICTURES ARE SAVED ...
Page 8
Chapter 7 CHANGE THE SIZE OF TEXT ON WEB PAGES ... 183 SHOW OR HIDE PICTURES ON WEB PAGES ... 184 VIEW A PAGE IN FULL SCREEN MODE ... 184 SEND A LINK VIA E-MAIL ... 185 ADJUST THE SCROLLING SPEED ... 186 CHAPTER 8.
Page 9
Chapter 8 DELETE A VPN CONNECTION ... 234 EDIT A DIAL-UP CONNECTION ... 234 EDIT A PROXY CONNECTION ... 235 EDIT AN INTRANET URL ... 236 CHAPTER 9. VOICE COMMAND ...237 VOICE COMMAND ... 238 1 - ADJUST THE MICROPHONE ... 238 2 - SET THE VOICE COMMAND BUTTON ...
ACTIVATING YOUR PHONE If you purchased your phone at a Verizon Wireless Store, it is probably activated and ready to use. If you have upgraded your phone or received a new phone by mail, it probably needs to be activated before you can use it.
SETTING UP YOUR VOICEMAIL SET UP VOICEMAIL All unanswered calls to your Verizon Wireless PN-820 by UTStarcom are sent to voicemail, even if your phone is turned off. You’ll want to set up your voicemail and personal greeting as soon as you activate your PN-820.
INSIDE THE PACKAGE This package should include all items pictured below. If any are missing or different, you should immediately contact the retailer where you purchased the phone. Handset Standard Battery USB Data Cable AC Travel Charger Stereo Ear-mic Getting Started Disc User Guide CD...
HANDSET DESCRIPTION The PN-820 weighs 3.92oz. The dimensions are 2.05" x 3.85" x 0.78". 2.5mm Headset Jack Camera Sub LCD Home Key Navigation Key SEND Key Mini Camera SD Card Flash I/O Slot Volume Camera Key Quick List/ Recording Earpiece...
HANDSET DESCRIPTION HOME SCREEN The Home Screen plays an integral part in the navigational model of your Smartphone. It is the first screen displayed every time the phone is turned on. You can easily return to the Home screen by pressing the Home key.
HANDSET DESCRIPTION HOME SCREEN ICONS Status icons appear at the top of the screen and In the Home screen. The following table lists common status icons and their meanings. Indicator New e-mail or text message (SMS) Multimedia message (MMS) New voice mail New instant message Voice call Voice call in progress...
Page 18
HANDSET DESCRIPTION Indicator Keys S key E key < key > key C key * key 0 key # key H key V / v key Q [Q/REC] Meaning T9 text input mode, uppercase Numeric input mode 1XRTT connection available EV-DO connection available Functions Press to make or receive a call.
BATTERY USAGE The battery is not charged when the phone is first purchased – fully charge the battery before first use. Battery operating time gradually decreases over time. If the battery fails to perform normally, you may need to replace it. BATTERY INSTALLATION Be sure to use only the batteries that have been provided with the phone.
BATTERY REMOVAL Again, place the battery on a flat surface and use an even, steady pressure when removing the battery. 1 ❶ Pull the release latch upwards, lift up the battery. ❷ Remove the battery from the handset. If the battery is not correctly placed in the compartment, the handset will not turn on and/or the battery may detach during use.
BATTERY USAGE BATTERY CHARGING Make sure the battery is properly installed in the handset. Use all normal cautions when working with a standard wall outlet. POWER CONNECTION Plug the AC Charger into a standard outlet. Plug the other end of the AC Charger into the bottom of your phone.
Page 22
BATTERY USAGE TIMES The operating time is subject to your handset usage and configuration. Battery Capacity STD 950 mAh EXT 1600 mAh BATTERY STANDBY TIME The operating time is subject to your handset usage and configuration. Battery Capacity STD 950 mAh EXT 1600 mAh These times are for a new battery.
BATTERY USAGE BATTERY HANDLING INFORMATION The correct usage and handling of batteries can preserve the lifetime of your phone and ensure proper operation. Operating times are subject to the usage and configuration of your handset; please see the label on your battery for your battery’s capacity. Follow these suggestions carefully.
Chapter 2 BASIC OPERATION This chapter addresses and explains the basic features of your phone including: TURNING THE PHONE ON/OFF USING THE QUICK LIST BASIC FUNCTIONS MAKING AN EMERGENCY CALL...
TURNING THE PHONE ON/OFF TURNING THE PHONE ON Press and hold the END key E until your “Power On” logo appears. • If “Password” appears on the display enter your 4-digit password to unlock your phone. • If the battery does not have enough charge to turn on the phone, the keypad will not light up.
USING THE QUICK LIST The Quick List provides a list of commands that you can use to quickly perform common actions. 1 Press the lower button Q [Q/REC] on the right side of your phone. 2 Use the Navigation Key to select the Quick List command you want.
Your Verizon Wireless PN-820 phone has many options. This section will show you how to use basic functions such as making and receiving calls, locking and unlocking your phone, and managing the appearance and settings on your phone. MAKE A CALL BY ENTERING A CONTACT NAME Your phone allows you to call someone from your contact list or address book.
BASIC FUNCTIONS MAKE A CALL FROM AN OPEN CONTACT You can open contacts from the main screen and make a call from that contact. 1 In the Home screen, press the right soft key > [Contacts]. 2 Select the contact to call and press O [OK]. 3 Select the phone number to call and press O [OK].
MAKE A CALL FROM THE CONTACT LIST Your contact list is always readily available from the Home screen. 1 In the Home screen, press the right function key [Contacts]. 2 Select the contact you want to call, and press O [OK].
BASIC FUNCTIONS ANSWER OR IGNORE A CALL To answer the call, press SEND or press Answer. To reject the call, press E or press Ignore. Selecting Ignore will connect the caller to your voice mail if you subscribe to this service. ANSWER OR POSTPONE A SECOND CALL To put the first call on hold and answer the second call, press SEND or press Answer.
INSERT A THREE-SECOND PAUSE IN A DIALING SEQUENCE There may be occasions when you wish to pause dialing after you’ve selected a contact to call. You can insert a three second pause between selecting a contact to call and when the phone actually dials. 1 In the Home screen, press the right function key >...
BASIC FUNCTIONS LOCK THE KEYPAD Locking the keypad turns off keypad functionality. This is a helpful feature if, for example, the phone is turned on and in your pocket, and you want to prevent accidental key presses. 1 Display the Quick List by pressing the lower button Q [Q/REC] on the right side of your phone.
TURN VOICE PRIVACY ON OR OFF Through encryption and scrambling, the PN-820 provides privacy for your cell phone calls. 1 In the Home screen, press [Start], select Settings, then Call Options. 2 Select or clear voice privacy and press [Done].
SET THE IDLE TIMER Your PN-820 will automatically return to the Home screen after a period of inactivity. You can adjust the amount of time before the PN-820 defaults to the Home screen. 1 In the Home screen, press [Start], select Settings...
CHANGE THE HOME SCREEN APPEARANCE The PN-820 allows you to choose from many color schemes and layouts and allows you to use a background image for the main screen. 1 In the Home screen, press [Start], select Settings with the Navigation Key, or select Settings from the menu bar on top of the Home screen and press O [OK].
BASIC FUNCTIONS ENTER OWNER INFORMATION Entering and displaying owner information allow someone to return the phone to you in case it is lost. 1 In the Home screen, press [Start] Settings Owner Information. 2 Complete the following: • In Name, enter your name. •...
3 Select one of the folders listed in the main window. 4 Press [Menu], and navigate through the folders listed there. 5 Select the item you want to open. QUICKLY LOCK YOUR PHONE You can use a shortcut to quickly lock your phone by using one simple button.
BASIC FUNCTIONS SET THE ALARM You have several options for managing the alarm feature. Be sure you have properly set the date, time, and time zone before using this feature. 1 In the Home screen, press [Start], select Settings with the Navigation Key, or select Settings from the menu bar on top of the Home screen and press O [OK].
You can make calls to emergency service numbers under any circumstances, even if you have locked the phone. LOCATION ON/E911ONLY The PN-820 allows you to share position information over the network. 1 In the Home screen, press [Start], select Settings with the Navigation Key, or select Settings from the menu bar on top of the Home screen and press O [OK].
Chapter 3 Chapter 3 MEMORY FUNCTION MEMORY FUNCTION This chapter addresses memory functions including: MAKE A CALL ENTERING TEXT AND NUMBERS CREATING A CONTACT CARD FOR A CALLER...
MAKE A CALL FROM THE CALL HISTORY LIST Call History displays calls you have made, received, and missed. 1 In the Home screen, press [Start] and select Call History using the Navigation Key. 2 Select the name or phone number to call. 3 Press S.
ENTERING TEXT AND NUMBERS ENTERING TEXT AND NUMBERS You can enter text, numbers and symbols by using the keypad. The phone supports four input modes for entering text, numbers and symbols: Multipress, T9, Numeric and symbols. Multipress and T9 modes are used for entering text, Numeric mode is used for entering numbers, and Symbols mode is used for entering symbols like “@”, “/”, “$”...
ENTERING TEXT AND NUMBERS DELETE CHARACTERS You can only delete characters when you are in input mode, either for numbers, names, or text. The Clear key operates similarly to a “backspace” key on a computer. 1 To backspace and delete a single character in any input mode, press Clear key C.
ENTERING TEXT AND NUMBERS ENTER NUMBERS IN TEXT BOXES To enter numbers, use Numeric mode. If you need to enter a number within a line of text, change to Numeric mode to enter the number, and then change back to Multipress or T9 mode to finish entering the text. 1 Change to Numeric mode by pressing and holding the * key.
ENTERING TEXT AND NUMBERS ENTER TEXT IN T9 MODE To form a word in T9 mode, press the number keys that contain the letters you want. As you enter letters, T9 analyzes your key presses and attempts to complete the word. For example, to enter the word shoe, press 7, 4, 6, 3.
ENTERING TEXT AND NUMBERS START A NEW LINE When you are entering information in a text box, if you want to add a line break, use the OK key. 1 In a multi-line text box such as the Notes area of a contact or a calendar appointment, do the following: 2 In any input mode, press O [OK].
ENTERING TEXT AND NUMBERS CHANGE THE INPUT MODE There are several input modes available on your phone depending on whether you are entering contact information, phone numbers, symbols or text. Be sure you are in the input mode you desire. 1 In text input mode, press and hold the * key.
CREATING A CONTACT CARD FOR A CALLER Creating a contact card for a caller makes their information easier to retrieve when the call is done. The card can be added to the Contact list during the call. 1 During a call, press the right soft key Menu. 2 Select Save to Contacts and press O [OK].
Chapter 4 MENU FUNCTION This chapter discusses accessing the menu and using its functions and features to customize your phone. CONTACTS CALL HISTORY SETTINGS ERROR REPORTING PROFILES SECURITY SOUNDS TOOLS...
Using the Contacts feature of your PN-820, you can manage all the phone information you need. There are many options for adding contacts, retrieving contacts, and managing the information for each contact. CREATE A NEW CONTACT To enter a new contact manually, without having the caller on the phone, you will use the Contacts selection from the home screen.
BEAM A CONTACT It is possible to use your phone to send a contact to another device such as Bluetooth radio. This is called “beaming” your contact. A list of devices will appear when you’ve selected Beam. 1 In the Home screen, press the left soft key < [Start].
CALL A CONTACT FROM CONTACT INFORMATION You can call a contact directly by selecting them from the Contacts page of the Home screen. 1 In the Home screen, press left soft key < [Start]. 2 Select Contacts and press O [OK]. 3 Select the contact to call and press O [OK].
CHANGE THE DEFAULT NUMBER FOR A CONTACT The default number for the contact will be the first number displayed. If you need to change the default number, you will use the Navigation key to set the default. 1 In the Home screen, press left soft key < [Start]. 2 Select Contacts and press O [OK].
FILTER THE CONTACT LIST Contacts that have categories assigned are displayed in a list when filtered by category. 1 In the Home screen, press the left soft key < [Start]. 2 Select Contacts and press O [OK]. 3 Press the right soft key > [Menu]. 4 Select Filter from the popup menu and press O [OK].
SEND AN E-MAIL TO A CONTACT If a contact’s email address is entered into their information, you can send an email from within the contact list after selecting the contact. 1 In the Home screen, press the left soft key < [Start].
VIEW AND EDIT CONTACT INFORMATION You may want to change or update contact information once it has already been entered. Do this from the Contacts menu of the Home screen. 1 In the Home screen, press the left soft key < [Start].
ADD A PICTURE TO A CONTACT You may wish to add a picture to a contact record. You can add an existing picture, or you can put the phone in Camera mode to take the picture and add it to the contact. 1 In the Home screen, press the left soft key <...
REMOVE A PICTURE FROM A CONTACT Once a picture is attached to a contact, it can easily be removed or changed from the Contacts menu by using the soft-key and editing the field. 1 In the Home screen, press the left soft key < [Start].
ASSIGN A CATEGORY TO A CONTACT It may be helpful to group your contacts in categories you define for easier reference. If you know the contact’s category you can easily retrieve the contact. 1 You can use categories to help you organize and group your contacts.
ASSIGN A RING TONE TO A CONTACT To easily identify who is calling you by the ring tone, you can assign a custom ring tone to each contact. 1 In the Home screen, press the left soft key < [Start]. 2 Select Contacts and press O [OK].
4 Select the phone number, e-mail address, or Web page address for which to create a speed dial. 5 Press [Menu] and select Add to Speed Dial, then press O [OK]. 6 In Keypad assignment, select the speed dial number to use. 7 Press [Done].
VIEW AND EDIT A SPEED DIAL You can view or edit all the contacts you’ve assigned to speed dial by entering the Speed Dial menu from the Start soft key. 1 In the Home screen, press the left soft key < [Start].
CALL HISTORY Call history provides details of all calls received, missed and dialed. 1 From the Home screen, press the left soft key < [Start]. 2 Select Call History and press O [OK]. To view only missed calls, incoming calls, or outgoing calls, Press [Menu] select Filter, and then press the type of calls to view.
RESET CALL TIMERS When call information is no longer required, the call timers can be set to zero. 1 From the Home screen, press the left soft key < [Start]. 2 Select Call History and press O [OK]. 3 Press [Menu] select View Timers from the popup menu and press O [OK].
CALL HISTORY CREATE A CONTACT FROM CALL HISTORY While you are in the Call History function, you can select any of the calls and automatically add that caller to your contact list. 1 From the Home screen, press the left soft key < [Start].
DELETE AN ITEM FROM CALL HISTORY Any of the calls that are shown in the Call History can be deleted by selecting the call and then accessing the menu. 1 From the Home screen, press the left soft key < [Start].
CALL HISTORY FIND A CONTACT FROM CALL HISTORY There is an option in the Call History for finding contacts from your contact list. The autofill feature will help. 1 From the Home screen, press the left soft key < [Start]. 2 Select Call History and press O [OK].
SEND AN E-MAIL MESSAGE FROM CALL HISTORY To use this function, the e-mail address of the person you are sending an e-mail to must be included in their contact information card. 1 From the Home screen, press the left soft key < [Start].
Choosing the Settings option from the Home screen allows you to view and in some cases change the status of your phone, the hardware and software version, the phone number and other important reference information about your phone. ACCESSIBILITY SETTINGS The accessibility settings will determine the size of the text and characters, time outs, call alerts, and volumes on the phone.
POWER MANAGEMENT You can use Power Management to check the battery and configure settings that prolong battery life. 1 From the Home screen, press the left soft key < [Start]. 2 Select Settings and press O [OK]. 3 Scroll to Power Management and press O [OK]. 4 Adjust the following: 5 Backlight time out on battery: select the amount of time for the phone to be idle before the...
REGIONAL SETTINGS You can specify the language, locale, date and time style, as well as number and currency formatting options. 1 From the Home screen, press the left soft key < [Start]. 2 Select Settings and press O [OK]. 3 Scroll to Regional Settings and press O [OK]. 4 Adjust the following: 5 Language: select your preferred language.
SELECT DEFAULT BAND Your phone has three possible bands in which to operate. Choose one band as the default. 1 From the Home screen, press the left soft key < [Start]. 2 Select Settings and press O [OK]. 3 Scroll to Connections and press O [OK]. 4 Select Wireless Manager.
DISPLAY YOUR ESN Your phone has a unique identification number known as the Electronic Serial Number, or ESN. To see the ESN follow these instructions. 1 From the Home screen, press the left soft key < [Start]. 2 Select Settings and press O [OK]. 3 Scroll to Phone Information and press O [OK].
DISPLAY YOUR HARDWARE VERSION The phone itself also has a version number. Should you need tech support or for upgrades, you will need to check the hardware version. 1 From the Home screen, press the left soft key < [Start]. 2 Select Settings and press O [OK].
DISPLAY YOUR ERI VERSION ERI is the Enhanced Roaming Indicator and provides more information regarding the roaming status of your phone. 1 From the Home screen, press the left soft key < [Start]. 2 Select Settings and press O [OK]. 3 Scroll to Phone Information and press O [OK].
TURN ERI BANNER ON / OFF If you do not desire to see the ERI notification, you have the option of toggling the banner displaying the ERI messages on and off. 1 From the Home screen, press the left soft key < [Start].
SELECT NAM The NAM or Number Assignment Module, is a part of the phone that stores a wireless device’s phone number, lock code, timer reset code and other user information. The NAM is programmed by the service provider when a device is activated. The NAM also associates the Mobile Identification Number (MIN) with the Electronic Serial Number (ESN).
SELECT TTY MODE Your phone is able to operate with TTY (Teletypewriter) digital modes. This feature is system dependent and may not be available in all areas. 1 From the Home screen, press the left soft key < [Start]. 2 Select Settings and press O [OK]. 3 Scroll to Call Options and press O [OK].
ERROR REPORTING Error Reporting sends information needed by technical support groups to diagnose a program error for a device running Windows Mobile software. A text file is created whenever an error is detected, and can be delivered to support personnel if you choose to send it. If a program error occurs, Error Reporting [Start]s automatically.
VIEW THE LIST OF PROFILES You can store a set of parameters and options for your phone in what is known as a “profile”. By developing and selecting a profile you will be establishing the baseline features of operation for the phone. 1 From the Home screen, press the left soft key <...
CHANGE THE CURRENT PROFILE If you have more than one profile on your phone, there are two simple methods of changing to another profile. 1 In the Home screen, use the up and down Navigation Keys N to select Profile and press O [OK].
Your UTStarcom PN-820 has several easy-to-use security features. You can enable the device lock, or you can enable security certificates such as SSL. ENABLE THE DEVICE LOCK 1 From the Home screen, press the left soft key < [Start]. 2 Select Settings and press O [OK].
DISABLE THE DEVICE LOCK When you disable a device lock, remember to disable the automatic feature that locks the device if it is unused for a specified amount of time. 1 From the Home screen, press the left soft key < [Start].
VIEW A CERTIFICATE Your phone is able to use personal security certificates that you add to the phone and it also has root certificates that come pre-installed. 1 From the Home screen, press the left soft key < [Start]. 2 Select Settings and press O [OK]. 3 Scroll to Security and press O [OK].
DELETE A CERTIFICATE Be careful when deleting certificates: select only the certificate you intend to delete. Root certificates should only be deleted when you are certain you do not need that security on the phone. 1 From the Home screen, press the left soft key < [Start].
RESET DEFAULT When you first purchase your phone, all the settings are pre-configured and installed. At any time you can return your phone to the factory default settings. 1 From the Home screen, Press the left soft key < [Start]. 2 Select Settings and press O [OK].
The UTStarcom PN-820 comes with a large standard set of ringtones and sounds. You can also add your own as long as they are in the correct format. CHANGE OR TURN SOUNDS ON OR OFF Any sound can be toggled on or off at any time, or you can turn the phone’s sound off altogether.
DELETE A SOUND You can only delete sounds that you have added. You cannot delete sounds pre-installed in the phone. 1 From the Home screen, press the left soft key < [Start]. 2 Select Settings and press O [OK]. 3 Scroll to Sounds and press O [OK]. 4 Press [Menu], Delete Sounds and press O [OK].
COPY A SOUND FROM YOUR PC TO YOUR PHONE After a sound file is located on your phone, you can use it for a ring tone. Sound files in .wav, .mid, mp3 or .wma formats can be used. 1 Connect the phone to your PC using a USB connection.
CALENDAR SCHEDULE AN APPOINTMENT Your calendar allows you to schedule appointments and reminders by day, by time, or by event. From the Home screen, press the left soft key < [Start]. Select Calendar and press O [OK]. Press [Menu] and select New Appointment. Enter information about the appointment.
Page 93
DELETE AN APPOINTMENT To delete an existing appointment, you will have the option of deleting just one appointment or the entire series if it is a recurring appointment. From the Home screen, press the left soft key < [Start]. Select Calendar and press O [OK]. In Agenda view, select the appointment to delete.
Page 94
UPDATE AN APPOINTMENT When your schedule or appointment information changes, you can easily edit the appointment with new information. From the Home screen, press the left soft key < [Start]. Select Calendar and press O [OK]. Select the appointment and press soft key [Edit]. If the appointment is recurring, press Yes to edit only the current occurrence.
Page 95
VIEW APPOINTMENTS FOR THE WEEK Each week’s appointments are clearly displayed in the calendar, when you’ve selected Week View. From the Home screen, press the left soft key < [Start]. Select Calendar and press O [OK]. Press [Menu] and select Week View. See also Change the display of the work week.
Page 96
VIEW YOUR AGENDA FOR A SPECIFIC DATE You can also select a specific date to check that day’s schedule. From the Home screen, press the left soft key < [Start]. Select Calendar and press O [OK]. Press [Menu] select Go to Date and press O [OK].
Page 97
MAKE AN APPOINTMENT RECURRING If you’ve already entered a single appointment in your calendar and would like to change it to a recurring appointment, use the Occurs selection after selecting the appointment. From the Home screen, press the left soft key < [Start].
Page 98
ASSIGN A CATEGORY TO AN APPOINTMENT You can use categories to help you organize and group your appointments. From the Home screen, press the left soft key < [Start]. Select Calendar and press O [OK]. Select an appointment and press soft key [Edit]. Select Categories and check the category you want.
Page 99
Scroll to Month view and click O [OK]. Select Show week numbers. Press [Done]. In Week view, the week number appears at the top of the screen. In Month view, the week numbers appear along the left side of the screen. CHANGE THE WORK WEEK DISPLAY Depending on your schedule, you may want to change the default work week displayed.
Change the time. Press [Done]. TASKS CREATE A TASK The PN-820 allows you to create a new task with reminders for your task list from your phone or from your PC. From the Home screen, press the left soft key < [Start].
Page 101
CHANGE A COMPLETED TASK TO INCOMPLETE If you have marked a task as complete on your list and the status changes, you can easily go back to the task and change its status to incomplete by “activating” the task again. From the Home screen, press the left soft key <...
Page 102
DELETE A TASK To remove a task from your list you will delete it. Marking a task as complete will not delete the task from your list. From the Home screen, press the left soft key < [Start]. Select Tasks and press O [OK]. Select the task, and Press the right soft key >...
Page 103
LOCATE A TASK There are many options for finding a task on your list; you can view and sort the entire task list, or filter the list by category. From the Home screen, press the left soft key < [Start]. Select Tasks and press O [OK].
CALCULATOR USING THE CALCULATOR Perform standard mathematical operations such as addition, subtraction, multiplication, and division. In the Home screen, press the left soft key < [Start], then left soft key < [More] and select Accessories and press O [OK]. Select Calculator and press O [OK]. Enter a number using the keypad.
VOICE NOTES In addition to making and receiving calls, scheduling and keeping contacts, the PN-820 allows you to save your own reminders and messages in voice format. CREATE A VOICE NOTE When you wish to create a voice note, after making the selections described here, you will speak into the microphone just as you would speak on a call.
Page 106
LISTEN TO A VOICE NOTE You can retrieve any voice notes you wish. When the voice notes were saved they were recorded by time and category. In the Home screen, press the left soft key < [Start], then the left soft key < [More] and select Voice Notes and press O [OK].
Page 107
RENAME A VOICE NOTE You have the option of renaming a voice note, or assigning it to a different category. In the Home screen, press the left soft key < [Start] select Voice Notes and press O [OK]. Select the voice note to delete. Press [Menu] then select Rename and press O [OK].
Voice mail is available at all times. When you call your voice mail the messages will be played back in the order they were received. You will have options to save, delete, replay, or skip each message. CALL YOUR VOICE MAILBOX Retrieving your voice mail is simple and can be accessed directly from the Home screen.
CREATE A TEXT MESSAGE The PN-820 allows you to create text messages quickly. You create a text message by typing in a phone number or by selecting a contact first.
DELETE ALL TEXT MESSAGES To clear all text messages in a folder, you will need to show all the folders and select the folder you want. 1 In the Home screen, press the left soft key < [Start] select Messaging and press O [OK]. 2 Select Text Messages and press O [OK].
TEXT MESSAGING BE NOTIFIED WHEN A TEXT MESSAGE IS DELIVERED By selecting Request message delivery notification you can receive a notification on your phone when your message is delivered. 1 Before sending a text message, Press [Menu] Message Options. 2 Press [Menu], then select “Folders.” 3 Press [Menu] then select “Show all Folders.”...
Multipoint Microwave Service (MMS) allows you to send messages directly to other devices without an intervening wireless network. This can be an advantage in certain situations. MMS messages are composed just as other text messages would be. CREATE AN MMS Creating an MMS is simple and you can add images or attachments to the message.
Page 115
MMS MESSAGING 8 The alert message “Confirm? Do you want to send this message” is shown up to confirm the sending of the message. 9 Select “Confirm”. 10 Select O [OK] to send the message. If MMS was sent successfully, a ‘Message sent successfully’ dialog will appear.
MMS MENU OPTIONS The Menu supports advanced MMS composer option. Menu option Add Recipient Add Item Cancel Composer Create Item Edit Item MMS MESSAGING Description Press [Menu] Add Recipient to select the recipient address from Contact list or the PIX Place. You can add content such as image, sound, text, video, vCard and vCalendar.
Page 117
MMS MESSAGING Menu option You can edit page properties such as page duration and background color. Press [Menu] Edit Page, Insert Page: insert a new page. Press [Menu] Edit Page, Move Page: select a page number and move. Edit page Press [Menu] Edit Page, Delete Page: delete a current page.
VIEW MMS MESSAGES To view MMS messages, simply select MMS from the Messaging menu and you will see a list of Inbox messages. 1 In the Home screen, press the left soft key < [Start], select Messaging and press O [OK]. 2 Select MMS, press O [OK] for list of Inbox messages.
Page 119
MMS MESSAGING 5 Press [Menu] ‘Reply to all’ to send a reply MMS message to all senders. 6 Open MMS editor and display “To” field with “RE”: all sender addresses including “CC”, “BCC” sender. 7 Press [Menu] Forward to forward MMS message Open MMS editor and display “To”...
MMS SETTINGS To make it easier and quicker to use the MMS feature of the phone, edit the MMS settings in advance of using the program. There are several automatic options available. 1 In the Home screen, press the left soft key < [Start], select Settings and press O [OK].
MMS MESSAGING USE MMS CLIENT To use MMS client, you need to set up a connection on your phone, such as a modem or wireless connection, which enables you to connect to the Internet. MMS client can send / receive MMS messages via the Internet connection.
MESSAGING SETTINGS There are many settings in the Messaging function of your phone. Use the Messaging selection from the home screen to customize how your messages are ordered and displayed. CHANGE MESSAGING ACCOUNT OPTIONS MMS, E-mail and text messages can be displayed differently and you can select from many options for each.
MESSAGING SETTINGS CREATE A MESSAGE FROM A CONTACT CARD Just as you can make phone calls from a contact card, you can select a contact and send a message from the contact card. 1 In the Home screen, Press [Start], select Contacts and press O [OK].
The UTStarcom PN-820 allows you to send emails with several options. You can copy, blind copy, set priority, and store emails just as you would from a computer. The PN-820 uses Outlook as the default mail program. CREATE AN E-MAIL MESSAGE You can create an email message from a contact card, or by typing in the address.
OVERVIEW OF E-MAIL SECURITY You can help prevent impersonation, tampering, and eavesdropping when sending e-mail messages from your Outlook e-mail account by using Secure Multipurpose Internet Mail Extensions (S/MIME) digital signatures and encryption. A signature helps prevent impersonation and tampering. Impersonation occurs when a hacker sends e-mail messages and pretends to be someone else.
DIGITALLY SIGN A MESSAGE Digitally signing a message applies your certificate with the public key to the message. This proves to the recipient that the message is from you and not from an imposter, and that the message has not been altered.
DOWNLOAD AN ATTACHMENT In an open message with an attachment to download, press the attachment. The attachment is downloaded the next time you synchronize or connect to your e-mail server and send and receive e-mail. If there are multiple attachments in the message, all attachments are downloaded.
MARK A FOLDER FOR SYNCHRONIZATION When you synchronize your Outlook e-mail account with your PC, the same Inbox folders that are in Outlook on your PC are created on your phone. 1 In the Home screen, press the left soft key < [Start], select Messaging and press O [OK].
VERIFY THE DIGITAL SIGNATURE ON A SIGNED MESSAGE YOU RECEIVE For additional security, you can check digital signatures on messages before opening them. In some cases the signatures may not be available. 1 Open the message that has been digitally signed.
SEND AND RECEIVE INTERNET E-MAIL MESSAGES Using the PN-820 you can connect to the Internet to send and receive emails. 1 In the Home screen, press [Start] Messaging. 2 Select the Internet e-mail account for which you want to send and receive messages.
SET UP AN INTERNET E-MAIL ACCOUNT AUTOMATICALLY You can program your phone with an internet email address so your address is the default email address. 1 In the Home screen, press left soft key < [Start], select Messaging and press O [OK]. 2 Select an account.
SET UP AN INTERNET E-MAIL ACCOUNT MANUALLY Before you set up your Internet e-mail account, ensure that you have the necessary information. Setting User name Password Domain Server type Account name Network Incoming mail server Require SSL connection E-MAIL Description Usually the first part of your e-mail address, which appears before the ‘at’...
Page 133
Setting Outgoing mail The name of your outgoing e-mail server server (SMTP). Outgoing server Your outgoing e-mail server (SMTP) may requires require authentication. NOTE: Your user authentication name and password from above will be used. Your outgoing e-mail server may require Outgoing server different authentication settings than your settings...
Page 134
Now you’re ready to set up your account. 1 In the Home screen, press the left soft key < [Start], select Messaging and press O [OK]. 2 Select an account. 3 Press [Menu] [Option] New Account. 4 In Your name, enter your display name for e-mail messages.
CREATE AND ADD A SIGNATURE TO MESSAGES For each account in Messaging, you can specify a signature to be automatically inserted into messages that you send. 1 In the Home screen, press the left soft key < [Start], select Messaging and press O [OK]. 2 Select an e-mail account.
DELETE A MESSAGE Messages from any account can be deleted. Select the Messaging function from the Home screen. 1 In the Home screen, press the left soft key < [Start], select Messaging and press O [OK]. 2 Select an account. 3 Select the message to delete.
4 Select the account to delete. 5 Press [Menu] Delete. You cannot delete your Text Messages or Outlook e-mail accounts. EDIT PREDEFINED TEXT You can edit the predefined text included with the phone to create words or phrases that you frequently use in messages. 1 In the Home screen, press the left soft key <...
EMPTY THE DELETED ITEMS FOLDER If you don’t have a need to store deleted items, you can delete the Deleted Items folder itself. 1 In the Home screen, press left soft key < [Start], select Messaging and press O [OK]. 2 Select an account.
INSERT PREDEFINED TEXT INTO A MESSAGE To save time when entering text, you can insert predefined text into messages. 1 In the Home screen, press the left soft key < [Start], select Messaging and press O [OK]. 2 Select an account and press New. 3 Press [Menu] My Text.
4 Press [Menu]. 5 Press Mark as Read or Mark as Unread. The message display is changed to reflect its new status: normal text for read messages and bold text for unread messages. When you synchronize or send and receive e-mail, the message is displayed as read or unread in all locations.
OPEN A MESSAGE To review or use a message you open it from its account in the Messaging function. 1 In the Home screen, press the left soft key < [Start], select Messaging and press O [OK]. 2 Select an account. 3 Select the message to open and press O [OK].
SEND A MESSAGE DRAFT If you wish to have a message draft reviewed, you can retrieve a stored draft or an open draft and send it to someone else. 1 In the Home screen, press the left soft key < [Start], select Messaging and press O [OK].
RESPOND TO A MEETING REQUEST You can receive and respond to Outlook meeting requests on your phone in a similar manner as you do in Outlook on your PC. 1 In the Home screen, press [Start] Messaging, and select an account. 2 Press the meeting request and respond to it as follows: 3 To accept the meeting request and insert the...
[Menu] Save to Drafts. A draft of the message is stored in the Drafts folder of the account you are SPECIFY THE LANGUAGE FOR READING A MESSAGE The PN-820 has many languages and character sets from which to choose. Each message can be composed in whatever language you require.
STOP ADDING A SIGNATURE TO MESSAGES If you have previously added a signature to an account and wish to stop using it, you can turn the signature off for that account. 1 In the Home screen, press the left soft key < [Start], select Messaging and press O [OK].
VIEW MESSAGE FOLDER CONTENTS You can store messages in folders and create the types of folders you need. 1 In the Home screen, press the left soft key < [Start], select Messaging and press O [OK]. 2 Select an account. 3 Press [Menu] Folders.
VIEW THE LIST OF ACCOUNTS If you have added accounts to your phone, you can see a list of all the accounts at one time. 1 In the Home screen, press the left soft key < [Start], select Messaging and press O [OK]. 2 The list of accounts displays with the number of unread messages in the Inbox of each account shown in parentheses.
ACTIVATE THE USB MODEM The PN-820 comes with a USB modem pre-installed. You can use the modem for rapid data transfer, but first you must activate it. 1 In the Home screen, press [Start], select Settings and press O [OK].
DEACTIVATE THE USB MODEM When not in use, it is possible to deactivate the USB modem. This will allow you to use the ActiveSync program. 1 In the Home screen, press [Start], select Settings and press O [OK]. 2 Scroll to Connections and press O [OK]. 3 Select Modem Link and press O [OK].
Chapter 6 PICTURES & VIDEOS, CAMERA, FUN & GAMES This chapter addresses picture and video functions including: PICTURES & VIDEOS CAMERA CONTROLS GAMES...
PICTURES & VIDEOS Use the Pictures & Videos program to take, view, and edit pictures as well as record and launch video clips stored on your device or on a storage card. You can also send pictures and video clips to others, or set a picture as the background In the Home screen.
PICTURES & VIDEOS COPY AN IMAGE TO YOUR PHONE You can upload standard image files from a PC to your phone. You should customize the size and resolution of your images for display on the phone screen. 1 Connect the phone to your PC. 2 On your PC, copy the image file you want.
PICTURES & VIDEOS TAKE PICTURES USING A TIMER Using the timer, you can be in the picture you take. Just place the phone on a stable support and press the camera button, then get into position. 1 In the Home screen, press [Start], select Pictures &...
PICTURES & VIDEOS ADJUST PICTURES AND VIDEO FOR LIGHTING CONDITIONS White balance settings optimize pictures and video clips for the type of ambient light. If you are not sure what to select, try the Automatic setting. 1 In the Home screen, press [Start], select Pictures &...
2 Press [Menu] select [Edit] and press O [OK]. 3 Press New Folder. EDIT A PICTURE You can actually edit pictures and videos on the PN-820 using the Menu key. 1 In the Home screen, press [Start], select Pictures & Videos and press O [OK].
PICTURES & VIDEOS 3 Press [Menu] [Edit] and press O [OK]. Do one of the following: • To rotate a picture 90 degrees counterclockwise, press [Menu] Rotate. • To crop a picture, press [Menu] Crop. Then, position the selection cursor to mark the upper left corner of the picture, press Next, and then position the cursor to mark the lower right corner of the picture.
PICTURES & VIDEOS SET A PICTURE AS THE HOME SCREEN Any picture you have uploaded can be saved as the background for the Home screen. 1 In the Home screen, press [Start], select Pictures & Videos and press O [OK]. 2 Select the picture to set as the background and press [View].
PICTURES & VIDEOS SEND A PICTURE You can attach pictures to messages and send them to someone else when your phone synchronizes with your PC. 1 In the Home screen, press [Start], select Pictures & Videos and press O [OK]. 2 Select the picture to send.
PICTURES & VIDEOS SAVE A COPY OF A PICTURE Store pictures in your phone by saving it to a pre-created folder. 1 In the Home screen, press [Start], select Pictures & Videos and press O [OK]. 2 Select the picture to save and press [Menu] [Edit].
PICTURES & VIDEOS CAMERA • Supports JPEG File Format (jpg) VIDEO • Supports QCIF(176x144) size of video • Supports 3gpp2 File Format (3g2) RECORD A VIDEO By using the camera function, you can take pictures or you can record video by selecting the Camcorder option. 1 In the Home screen, press [Start], select Camera and press O [OK].
PICTURES & VIDEOS PLAY RECORDED FILE After you’ve recorded and stored a video file, you can retrieve it at any time and play it back on the phone. 1 Press “1” on the keypad. The first left icon in upper Menu bar changes to Camcorder icon 2 Press left soft key <...
PICTURES & VIDEOS SNAPSHOT To take a quick picture, you will use the snapshot feature of the phone. After taking a picture, you can store it, delete it, or forward it. 1 In the Home screen, press [Start], select Camera and press O [OK].
CAMERA CONTROLS Just as with an ordinary camera, your phone can be adjusted to control the brightness, color, resolution etc. From the General Options menu you have access to all the image parameters you will want to adjust. GENERAL OPTION The general option menu is reached after selecting Camera from the Home screen and gives you access to these parameters: storage, balance, white balance, and color effect.
Page 165
CAMERA CONTROLS Item Choose storage in list Default value is ‘Device’. [Device] Capture files keep in the Device of Storage file box. [SD Card] Capture files keep in the “SD Memory Card” Choose brightness in list Default value is ‘0’. [-2] Preview or capture file’s brightness is very dark.
CAMERA CONTROLS CAMERA OPTIONS Camera Options allows you to control the resolution, self timer, flash, shutter sounds, quality, and multishot parameters. 1 Press “1” on the keypad. The first left icon in upper Menu bar changes to picture icon 2 Press right soft key > [Options] . 3 Select [Camera] and press O [OK].
Page 167
CAMERA CONTROLS Item Choose Resolution in list Default value is ‘640x480’. [160x120] Camera resolution is 160x120 Resolution [320x240] Camera resolution is 320x240 [640x480] Camera resolution is 640x480 [1280x960] Camera resolution is 1280x960 [1280x1024] Camera resolution is 1280x1024 Choose Self Timer in list Default value is ‘Off’.
CAMERA CONTROLS CAMCORDER OPTIONS The Camcorder Options allows you to control video features such as resolution and quality, and allows you to select the mode and turn the audio on and off. 1 In the Home screen, press [Start], select Camera and press O [OK].
Page 169
CAMERA CONTROLS Item Choose camcorder resolution in list Default value is ‘176x144’. Resolution Camcorder resolution is only supports 176x144. Choose Quality in list Default value is Medium [Low] Low quality setting the capture movie. [Medium] Medium quality setting the capture Quality movie.
CAMERA CONTROLS OVERVIEW OF THE DEFAULT HARDWARE BUTTON ASSIGNMENTS By default, these hardware buttons are assigned to Camera functions. Hardware Button NAVIGATION left NAVIGATION right NAVIGATION up NAVIGATION down Camera/Camcorder Function [Start] Record Video/Stop Record Video, Take a picture Brightness down Brightness up Zoom in Zoom out...
There are two games included with your PN-820: Solitaire and Bubble Breaker. SOLITAIRE START A GAME OF SOLITAIRE In the Home screen, press [Start] Games Solitaire. Start new game When you have finished playing a game, begin a new one by pressing [Menu] New Game.
PLAY SOLITAIRE Move any aces on the seven stacks to the four card spaces at the top of the screen, and then make any other available plays. When you have made all available plays, press Draw to turn over cards. The top card that is face up on the deck is always available for play.
Page 173
START BUBBLE BREAKER In the Home screen, press [Start], select Games, then Bubble Breaker. Set Bubble Breaker options Bubble Breaker allows you to vary your playing experience. In Bubble Breaker, Press [Menu] [Options], and select the following: • Play Sounds: Turns game sounds on or off. •...
Page 174
View Bubble Breaker statistics Bubble Breaker records your statistics for each playing style. Press [Menu] Statistics. • Games: the total number of games played. • Average: the average score across all games played in that style. • High: the high score for the particular style. •...
Chapter 7 MOBILE INTERNET EXPLORER This chapter addresses Internet services and web browsing. For more detailed information contact your service provider. USING INTERNET EXPLORER BROWSER MENU...
MOBILE INTERNET EXPLORER ADD A WEB PAGE TO THE FAVORITES LIST Internet Explorer functions on your phone much the same as it does on your PC. You can maintain a list of web sites in your favorites list. Add each site to the list through the Internet Explorer menus. 1 From the Home screen, press [Start] and select Internet Explorer.
MOBILE INTERNET EXPLORER CHANGE CONNECTION OPTIONS Depending on your location and your access settings, you can connect to different networks through Internet Explorer. 1 From the Home screen, press [Start] and select Internet Explorer. 2 Press [Menu] [Options]. 3 Press Connections. 4 Do one of the following: 5 To allow Internet Explorer to select network settings, select Automatically detect settings.
MOBILE INTERNET EXPLORER CHANGE WEB PAGE DISPLAY OPTIONS There are Web page display options to choose from: one column, default, and desktop. 1 From the Home screen, press [Start] and select Internet Explorer. 2 Select one of web site. 3 Press [Menu] [View]. Select one of the following: •...
MOBILE INTERNET EXPLORER CLEAR HISTORY, COOKIES, OR TEMPORARY FILES Internet explorer typically stores a list of the sites you’ve visited, cookies (files simplifying return to a site), or temporary files. Clearing these files is simple. 1 From the Home screen, press [Start] and select Internet Explorer.
MOBILE INTERNET EXPLORER DELETE A FAVORITE Any favorite can be deleted from your favorites list at any time. 1 From the Home screen, press [Start] and select Internet Explorer. 2 Press Favorites. 3 Select the favorite to delete. 4 Press [Menu] Delete. 5 Press Yes to confirm the deletion.
MOBILE INTERNET EXPLORER EDIT A FAVORITE You can change the name, URL, or description of a web site in your favorites list. 1 From the Home screen, press [Start] and select Internet Explorer. 2 Press Favorites. 3 Select the favorite to edit. 4 Press [Menu] [Edit].
MOBILE INTERNET EXPLORER GO TO A WEB PAGE The Internet Explorer on your phone accesses web pages by letting you enter the address in the address bar after pressing the menu key. 1 From the Home screen, press [Start] and select Internet Explorer.
MOBILE INTERNET EXPLORER OPEN INTERNET EXPLORER Internet Explorer is one of the easily accessible options from the Home Screen. 1 From the Home screen, press [Start] and select Internet Explorer. REFRESH A WEB PAGE To refresh a web page use the Menu soft key and select Refresh. 1 From the Home screen, press [Start] and select Internet Explorer.
MOBILE INTERNET EXPLORER VIEW A FAVORITE To view a favorite site at any time, just go into the Favorites list and select the site you wish to visit. 1 From the Home screen, press [Start] and select Internet Explorer. 2 Press Favorites. 3 Select a favorite and press Go.
MOBILE INTERNET EXPLORER MOVE A FAVORITE TO A FOLDER After you’ve created folders in your Favorites list, you can move any of the sites already on the list into one of the folders. 1 From the Home screen, press [Start] and select Internet Explorer.
MOBILE INTERNET EXPLORER SHOW OR HIDE PICTURES ON WEB PAGES The screen on your phone can be optimized by hiding or unhiding pictures displayed on web pages. 1 From the Home screen, press [Start] and select Internet Explorer. 2 Press [Menu] [View] Show Pictures. 3 A check mark next to Show Pictures indicates that pictures will be displayed on Web pages.
MOBILE INTERNET EXPLORER SEND A LINK VIA E-MAIL One of the options your phone provides is sending a link through e- mail. You will use the Tools menu on the Internet Explorer menu bar. 1 From the Home screen, press [Start] and select Internet Explorer.
MOBILE INTERNET EXPLORER ADJUST THE SCROLLING SPEED You will use the scrolling feature of the phone to view web pages – it can be adjusted to scroll as slowly or as quickly as you need. 1 From the Home screen, press [Start] and select Internet Explorer.
Chapter 8 PC CONNECTIVITY, BLUETOOTH AND ACTIVESYNC This chapter addresses Bluetooth and ActiveSync functions. ACTIVESYNC ACTIVESYNC TROUBLESHOOTING BLUETOOTH CONNECTING TO YOUR PC...
Microsoft ActiveSync synchronizes data between your phone and PC. ActiveSync is already installed on you phone, but you need to install it on your PC before you can synchronize data. INSTALL AND SET UP ACTIVESYNC Install ActiveSync on your PC as described on the Windows Mobile Getting Started Disc.
ACTIVESYNC SET UP AN EXCHANGE SERVER CONNECTION To complete this configuration, you will need to get the name of the server and the server domain name from your service provider or system administrator. You must also know your Exchange user name and password.
6 Select the check boxes for the types of information items that you want to synchronize with Exchange Server. 7 To change available synchronization settings, select the type of information, and press [Menu] select Settings and press O [OK]. 8 To change the rules for resolving synchronization conflicts, press [Menu] select Advanced and press O [OK].
ACTIVESYNC SCHEDULE SYNCHRONIZATION AS ITEMS ARRIVE You can schedule automatic synchronization between your phone and Exchange Server every time an item arrives or is changed in Exchange Server if your company is running Exchange Server with Exchange ActiveSync, and after your first full synchronization with Exchange Server.
CHANGE THE SYNCHRONIZATION SCHEDULE Before changing synchronization settings, disconnect the phone from your PC. 1 On the phone Home screen, press [Start], select ActiveSync and press O [OK]. 2 Press right soft key > [Menu] select Schedule and press O [OK]. 3 Do one or more of the following: To sync When you are working, or...
ACTIVESYNC START AND STOP SYNCHRONIZATION The ActiveSync program allows you to access a PC to keep information on both the PC and the phone current. There are several types of information you will want to keep updated on both. 1 On the phone Home screen, press [Start], select ActiveSync and press O [OK].
CHANGE SETTINGS FOR AN INFORMATION TYPE Before changing synchronization settings on the phone, disconnect it from your PC. 1 In the Home screen, press [Start], select ActiveSync, press O [OK]. 2 Press Menu, select [Options] and press O [OK]. 3 Select one of the information types. 4 Do one of the following: 5 To view or change settings for an information type (when available), press Settings.
Install and set up ActiveSync Change ActiveSync settings CONNECT TO A PC USING CHARGEABLE USB CABLE The UTStarcom PN-820 provides a USB connector for transferring data to and from your computer via USB cable. 1 Plug the USB Data Cable into a standard USB connector of your computer.
CONNECT TO A PC USING BLUETOOTH Follow the instructions in ActiveSync Help on the PC for configuring Bluetooth on your PC to support ActiveSync. 1 In the phone Home screen, press [Start], select ActiveSync and press O [OK]. 2 Press [Menu] Connect via Bluetooth. Ensure that the phone and PC are within close range.
ACTIVESYNC CHANGE E-MAIL SECURITY OPTIONS ActiveSync lets you set up S/MIME e-mail encryption and signing. You will have to obtain a valid certificate for signing or encrypting e-mail before you will be able to sign or encrypt e-mail successfully. 1 In the phone Home screen, press [Start], select ActiveSync and press O [OK].
8 Press [Menu] and select Choose Certificate to select a certificate for signing or encrypting outgoing e-mail. You can select certificates to sign or encrypt e-mails individually even if you do not want to sign or encrypt all outgoing e-mail. Synchronizing e-mail using S/MIME encryption or signing is available only with Exchange Server 2003 Service Pack 2, or later.
ACTIVESYNC TROUBLESHOOTING ACTIVESYNC SUPPORT CODE TROUBLESHOOTER ActiveSync supplies support codes to supplement error and other status messages on the Status page. This topic maps these support codes to information that may help you respond to ActiveSync problems. Windows Windows Mobile Version Mobile 2003 5.0 Support Support Code...
Page 202
ACTIVESYNC TROUBLESHOOTING Windows Mobile Version 5.0 Support Support Code Code 0x85002009 0x8500200A 0x80042009 0x8500200B 0x800421D9 0x8500200D 0x8004200C 0x8500200F 0x85010000 0x85010002 0x800421D2 Windows Mobile 2003 Error Message (if different) Not available. Your account information could not be detected. Choose Configure Server on the ActiveSync menu to check your Exchange Server...
Page 203
ACTIVESYNC TROUBLESHOOTING Windows Windows Mobile Version Mobile 2003 5.0 Support Support Code Code (if different) 0x85010008 0x800421D8 0x85010009 0x800421D9 0x85010014 0x80042235 0x85010015 0x80042236 0x85010016 0x80042237 0x85010017 0x80042238 0x85010018 0x80042239 Troubleshooting Error Message The proxy server If you sync on a schedule, you have specified sync has been changed is incompatible...
Page 204
ACTIVESYNC TROUBLESHOOTING Windows Mobile Version 5.0 Support Support Code Code 0x85010019 0x8004223A 0x85020002 0x800422BD 0x85020003 0x8004225E 0x85020004 0x8004225F 0x85020006 0x80040024 0x85020007 0x8004227E 0x85020008 0x80042263 0x85020009 0x80042262 Windows Mobile 2003 Error Message (if different) ActiveSync encountered network problems or an internal server error while synchronizing.
Page 205
ACTIVESYNC TROUBLESHOOTING Windows Windows Mobile Version Mobile 2003 5.0 Support Support Code Code (if different) 0x8502000A 0x8004227D 0x8502000B 0x8502000C 0x8004225D 0x8502000D 0x800422BE 0x85030000 0x80140010 0x85030019 0x80140022 0x85030027 Troubleshooting Error Message The server could This condition is generally not be reached. This temporary.
Page 206
ACTIVESYNC TROUBLESHOOTING Windows Mobile Version 5.0 Support Support Code Code 0x85030028 0x80072ee1 0x80072ee2 0x80072ee4 0x80072ee5 0x80072ee6 0x80072ee7 0x80072ee8 Windows Mobile 2003 Error Message (if different) Cannot obtain a valid certificate. To try again, please disconnect and reconnect your device to a PC on the corporate network.
Page 207
ACTIVESYNC TROUBLESHOOTING Windows Windows Mobile Version Mobile 2003 5.0 Support Support Code Code (if different) 0x80072ee9 0x80072eea 0x80072eeb 0x80072eec 0x80072eed 0x80072eee 0x80072ef0 0x80072ef1 0x80072ef2 Troubleshooting Error Message ActiveSync This condition is generally encountered a temporary. Try to sync problem on your again later.
Page 208
ACTIVESYNC TROUBLESHOOTING Windows Mobile Version 5.0 Support Support Code Code 0x80072ef3 0x80072ef4 0x80072ef5 0x80072ef6 0x80072ef7 0x80072ef8 0x80072ef9 0x80072efa 0x80072efb Windows Mobile 2003 Error Message (if different) The server could not be reached. This can be caused by temporary network conditions. The server could not be reached.
Page 209
ACTIVESYNC TROUBLESHOOTING Windows Windows Mobile Version Mobile 2003 5.0 Support Support Code Code (if different) 0x80072efc 0x80072efd 0x80072efe 0x80072eff 0x80072f00 0x80072f01 0x80072f04 Troubleshooting Error Message Synchronization This can be caused by could not be Exchange Server load completed. Verify conditions. The condition that you have is generally temporary.
Page 210
ACTIVESYNC TROUBLESHOOTING Windows Mobile Version 5.0 Support Support Code Code 0x80072f05 0x80072f05 0x80072f06 0x80072f07 0x80072f08 0x80072f09 0x80072f0a Windows Mobile 2003 Error Message (if different) The security certificate on the server has expired. Check that the date and time on your device are correct.
Page 211
ACTIVESYNC TROUBLESHOOTING Windows Windows Mobile Version Mobile 2003 5.0 Support Support Code Code (if different) 0x80072f0b 0x80072f0d 80072f0d 0x80072F7A 0x80072F7C 0x86000106 0x8600050D Troubleshooting Error Message Synchronization This in an Internet could not be error that is generally completed. Try again temporary.
Page 212
ACTIVESYNC TROUBLESHOOTING Windows Mobile Version 5.0 Support Support Code Code 0x80004005 Windows Mobile 2003 Error Message (if different) Synchronization could not be completed. If this condition persists, try deleting and then re- creating the device’s sync relationships. Troubleshooting information Problem could be caused by a specific folder or item on the device.
BLUETOOTH One remote networking option that is available to you with the PN-820 is Bluetooth wireless. By activating Bluetooth you can exchange information easily with other devices. ACCEPT A BLUETOOTH PARTNERSHIP A Bluetooth partnership is a direct link to other devices. Both devices that wish to connect must establish or accept a “partnership”...
CREATE A BLUETOOTH PARTNERSHIP Ensure that the two devices are within close range and that both Bluetooth-enabled devices are discoverable. 1 In the Home screen, press [Start], select Settings, press O [OK]. 2 Scroll to Connections and press O [OK]. 3 Select Bluetooth, press right soft key >...
BLUETOOTH END A BLUETOOTH PARTNERSHIP Through the connections menu, all Bluetooth partnerships that have been enabled are displayed. You can end a partnership at any time. 1 In the Home screen, press [Start], select Settings, press O [OK]. 2 Scroll to Connections and press O [OK]. 3 Select Bluetooth, press right soft key >...
MAKE YOUR DEVICE DISCOVERABLE To receive beamed information, beaming devices or computers must be able to detect your device. 1 In the Home screen, press [Start], select Settings, press O [OK]. 2 Scroll to Connections and press O [OK]. 3 Select Bluetooth, press right soft key > [Menu] select Devices and press O [OK].
BLUETOOTH RENAME A BLUETOOTH PARTNERSHIP You can give a more meaningful name to a Bluetooth partnership to help you recognize it when selecting from a list of partnerships. 1 In the Home screen, press [Start], select Settings, press O [OK]. 2 Scroll to Connections and press O [OK].
TURN BLUETOOTH ON AND OFF By default Bluetooth is turned off. If you turn it on, and then turn off your device, Bluetooth also turns off. When you turn on your device again, Bluetooth turns on automatically. 1 In the Home screen, press [Start], select Settings, press O [OK].
BLUETOOTH RECEIVE BEAMED INFORMATION Your phone can automatically receive beamed information, but you must enable the phone to do so through the Connections menu. 1 In the Home screen, press [Start], select Settings, press O [OK]. 2 Scroll to Connections and press O [OK]. 3 Select Beam and press O [OK].
RECEIVE INCOMING BEAMS Your phone receives all incoming beams from other devices until you clear this option. 1 In the Home screen, press [Start], select Settings, press O [OK]. 2 Scroll to Connections and press O [OK]. 3 Select Beam and press O [OK]. 4 Select Receive incoming beams.
BLUETOOTH BEAM AN ITEM In the Calendar, Contacts, Notes, Tasks, and Pictures programs, you can beam files and information to other devices using Bluetooth. 1 From the program, select the item you want to beam, such as an appointment in Calendar, a task in Tasks, a contact card in Contacts, or a picture in Pictures.
SET UP A BLUETOOTH-ENABLED HEADSET You can use a Bluetooth-enabled headset (or other Bluetooth-enabled hands-free device) with your device when you create a Bluetooth partnership between your device and the Bluetooth headset. 1 Make sure that the two devices are turned on and within close range, and that the Bluetooth- enabled headset is discoverable.
BLUETOOTH SET UP A STEREO HEADSET Windows Mobile-based devices support A2DP (Advanced Audio Distribution Profile), which is used by Bluetooth-enabled stereo headsets. Make sure that your stereo headset also supports A2DP. 1 Make sure that your device and the stereo headset are turned on, discoverable, and within close range.
TURN WIRELESS POWER ON OR OFF You can turn the power off to your wireless connections in a single location. This is a quick way to preserve battery power or to prepare your device for an airplane flight. 1 Press Q/REC button on the right side of the phone briefly to display the Quick List.
BLUETOOTH CONNECT TO INTRANET URLS Some companies use periods in their intranet URLs (for example, intranet.companyname.com). A Work URL exception tells Internet Explorer Mobile to look on the Work network to find the URL instead of searching the Internet. 1 In the Home screen, press [Start], select Settings, press O [OK].
USE A SPECIFIC CONNECTION TO CONNECT TO THE INTERNET When you create the connection, be sure to set the Connects to setting to The Internet. 1 In the Home screen, press [Start], select Settings, press O [OK]. 2 Scroll to Connections and press O [OK]. 3 Press [Menu] then Advanced.
BLUETOOTH EDIT A VPN CONNECTION If you have access to a Virtual Private Network (VPN) you can use your phone on the VPN. You will want to establish and edit the VPN connection first. 1 In the Home screen, press [Start], select Settings, press O [OK].
CONNECTING TO YOUR PC OVERVIEW OF BLUETOOTH VIRTUAL COM PORTS Some programs can connect only though a serial (COM) port. This can be true even if the device itself is Bluetooth-enabled. To make it possible for such programs to use a Bluetooth connection, you must set up a virtual COM port.
CONNECTING TO YOUR PC SET UP AN INCOMING BLUETOOTH COM PORT Make sure that your device is currently connected to the other device via Bluetooth. 1 In the Home screen, press [Start], select Settings, press O [OK]. 2 Scroll to Connections and press O [OK]. 3 Select Bluetooth and press O [OK].
CONNECTING TO YOUR PC SET UP AN OUTGOING BLUETOOTH COM PORT The New Outgoing Port menu command is available only if one or more Bluetooth-connected devices support serial (COM) connections. Make sure that your device is currently connected to the other device via Bluetooth.
CONNECTING TO YOUR PC CREATE A DIAL-UP CONNECTION Every network connection is different. You should gather all of the relevant information or network settings you need before starting this process. 1 In the Home screen, press [Start], select Settings, press O [OK]. 2 Scroll to Connections and press O [OK].
CONNECTING TO YOUR PC CREATE A PROXY CONNECTION Every network connection is different. You should gather all of the relevant information or network settings you need before starting this process. 1 In the Home screen, press [Start], select Settings, press O [OK]. 2 Scroll to Connections and press O [OK].
CONNECTING TO YOUR PC CREATE A VPN CONNECTION Every network connection is different. You should gather all of the relevant information or network settings you need before starting this process. 1 In the Home screen, press [Start], select Settings, press O [OK]. 2 Scroll to Connections and press O [OK].
CONNECTING TO YOUR PC DELETE A DIAL-UP CONNECTION If a dial-up connection is no longer need, delete it from the Connections menu. As with all options, you can control all the different connections possible through the phone. 1 In the Home screen, press [Start], select Settings, press O [OK].
CONNECTING TO YOUR PC DELETE AN INTRANET URL You may have stored URLs in your Work URL Exceptions list. When a URL is no longer needed there, delete it through the Advanced Connections menu. 1 In the Home screen, press [Start], select Settings, press O [OK].
CONNECTING TO YOUR PC DELETE A VPN CONNECTION When you are sure a VPN connection will no longer be needed – delete it from the Connections menu. 1 In the Home screen, press [Start], select Settings, press O [OK]. 2 Scroll to Connections and press O [OK]. 3 Select VPN and press O [OK].
CONNECTING TO YOUR PC EDIT A PROXY CONNECTION To edit a proxy connection, go to the Connections menu and select the connection to delete. 1 In the Home screen, press [Start], select Settings, press O [OK]. 2 Scroll to Connections and press O [OK]. 3 Select Proxy and press O [OK].
CONNECTING TO YOUR PC EDIT AN INTRANET URL To edit an Intranet URL, go to the Connections menu and the Advance menu, and select the connection to delete. 1 In the Home screen, press [Start], select Settings, press O [OK]. 2 Scroll to Connections and press O [OK].
Chapter 9 VOICE COMMAND The UTStarcom PN-820 has the most advance voice command technology available in cell phones. You can manage and use your phone without pressing buttons by setting up the Voice Command systems. VOICE COMMAND...
Follow these three easy steps: 1 - Adjust the Microphone 2 - Set the Voice Command Button 3 - Try out Voice Command 1 - ADJUST THE MICROPHONE To get better speech recognition: 1 If there is a microphone setting available, turn off Automatic Gain Control and set the microphone gain level to a medium level.
VOICE COMMAND A short melody will play and a microphone icon will appear at the top of your screen. 3 In a clear voice say, “Help”. 4 After Voice Command finishes speaking, answer “General”. You may also press the Voice Command Button anytime during a question to interrupt.
USING THE VOICE COMMAND BUTTON The Voice Command Button is used to activate or cancel voice recognition: • Press and release to talk or interrupt. • Press and hold to cancel. (*Not available on all devices) There are two ways to cancel voice recognition: •...
VOICE COMMAND MAKING PHONE CALLS You can call contacts and dial numbers with voice commands. • “Call <contact>” to call a contact whose phone number is stored on your device. • “Call <contact> at/on <location>” to call a contact at a specific phone number.
Page 244
WHEN CONFIRMING, SAY • “Yes” or “Correct” to call. • “No” or “Incorrect” to try again. WHEN ASKED WHICH LOCATION, SAY • an offered “<location>” to call. • “No” to try again or continue on to next contact in a list. EXAMPLES •...
VOICE COMMAND SHOWING CONTACTS You can show a contact card using voice commands. • “Show <contact>” • “Lookup <contact>” to display a contact. <CONTACT> SUPPORTS THE FOLLOWING FORMATS: • Nickname • First Last • First Last Suffix • First Middle Last •...
READING APPOINTMENTS You can request information from your calendar using voice commands. There are several variations of each calendar command. Use the one you find the most natural. Calendar reminders are read aloud as they occur. This can be turned on and off.
VOICE COMMAND WHILE LISTENING TO APPOINTMENTS, YOU CAN PUSH THE VOICE COMMAND BUTTON TO INTERRUPT AND SAY • “Next” for the next appointment • “Previous” for the previous appointment • “Repeat” to hear the current appointment again • “Cancel” to stop reading appointments NOTES •...
WHILE LISTENING TO OPTIONS, YOU CAN PUSH THE VOICE COMMAND BUTTON TO INTERRUPT AND SAY • “That One” to choose the current option • “<choice>” to choose an option EXAMPLES • “Play Artist” • “Play Scott Bishop Band” • “Play Album by Scott Bishop Band” •...
VOICE COMMAND GETTING PHONE STATUS You can set the ring volume and configure flight mode plus learn the battery level, signal strength, date and time using voice commands. • “What time is it?” to hear the current time. • “What date is it?” to hear the current date. •...
PERSONALIZATION Press Start ➞ (More ...) ➞ Voice Command Setup to begin personalizing. GENERAL OPTIONS There are many choices in the Voice Command feature of your phone. You can enable, disable, password protect, and control availability. • Voice Enabled – When yes, Voice Command is running and waiting for you to press and release the Voice Button.
VOICE COMMAND PHONE OPTIONS When using the Voice Command feature to place and receive calls, you will have the option of having your commands confirmed before being carried out. • Call Confirmations – When yes, Voice Command asks you to confirm that the correct name was recognized before placing the call.
GENERAL TIPS Voice command has many features to manage. This section describes some of the simple ways to manage Voice command. How do I get Help? – Say “Help”, it is context sensitive and will assist you with currently available commands. Do I have to wait until a question finishes to answer? –...
VOICE COMMAND PHONE AND CONTACT TIPS You will want to use some of the information in this section to make using your phone and contacts list with Voice command easier. • How do I call voicemail? – Make a contact named ‘voicemail’ and add each of your voicemail numbers.
READING APPOINTMENTS TIPS Voice command will act as you have instructed when you want it on or off in different situations. • Quiet Voice Command during a meeting or a movie – Voice Command will not make any noise if the device volume is off or set to vibrate.
VOICE COMMAND • Sometimes the artist isn’t what I expect – Voice Command uses the AlbumArtist property to organize tracks by artist. This is different than the Artist property displayed by Windows Explorer and by default in Windows Media Player. •...
GENERAL TROUBLESHOOTER This section contains answers to some of the most common questions you will have when using Voice command with your PN-820. The Voice Command Button doesn’t work when the password screen is displayed – The password screen blocks the Voice Command Button to avoid other people from placing phone calls while your device is locked.
Page 257
VOICE COMMAND The microphone icon doesn’t display – Try the following: • Make sure the button you’re pressing is assigned to Voice Command. • Make sure you are not holding the button long enough to engage the press and hold to cancel feature. I can’t use the Voice Command Button reliably –...
Page 258
PHONE AND CONTACT TROUBLESHOOTER These are common questions users have about using Voice command with their phones. I can’t use Voice Command during a call – Voice Command is temporarily disabled during phone calls. I say a contact name but it is not recognized – •...
Page 259
VOICE COMMAND Voice Command can’t find some tracks – If your media files lack track information, Voice Command may not find them. Add track information with Windows Media Player on your desktop. Voice Command supports only WMA and MP3 files in its index. STARTING PROGRAMS TROUBLESHOOTER Why am I getting a program when I ask to show a contact? –...
Chapter 10 SAFETY AND WARRANTY This chapter addresses the safety guidelines and precautions to follow when operating your phone. Before operating your phone, please be aware of all the safety details. This chapter contains the terms and conditions of services and the warranty for your phone.
SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES Read this information before using your Handheld Portable Cellular Telephone. EXPOSURE TO RADIO FREQUENCY SIGNALS Your wireless handheld portable telephone is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals.
SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES DRIVING SAFETY Talking on the phone while driving is extremely dangerous and is illegal in some states. Remember, safety comes first. Check the laws and regulations on the use of phones in the areas where you drive. Always obey them.
SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES ELECTRONIC DEVICES Most modern electronic equipment is shielded from RF energy. However, certain electronic equipment may not be shielded against the RF signals from your wireless phone. PACEMAKERS The Health Industry Manufacturers Association recommends that a minimum separation of six (6») inches be maintained between a handheld wireless phone and a pacemaker to avoid potential interference with the pacemaker.
SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES AIRCRAFT FCC and Transport Canada Regulations prohibit using your phone while in the air. Turn your phone OFF before boarding an aircraft. BLASTING AREAS To avoid interfering with blasting operations, turn your phone OFF when in a “blasting area”...
DO NOT use unauthorized accessories. DO NOT disassemble the phone or its accessories. If service or repair is required, return unit to an authorized UTStarcom cellular service center. If unit is disassembled, the risk of electric shock or fire may result.
SAFETY INFORMATION FOR FCC RF EXPOSURE WARNING! Read this Information before using CAUTIONS In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters.
THIS MODEL PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radiofrequency (RF) energy set by the Federal Communications Commission of the U.S.
Page 269
SAR INFORMATION The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after searching on PP4TX-215.
1851.25 — 1908.75 MHz (PCS CDMA) Maximum Conducted 0.342W CDMA (25.3dBm) Power (HAC): 0.342W PCS CDMA (25.3dBm) Trade Name/Model(s): UTStarcom / PC-8200N FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) FCC Rule Part(s): §20.19 HAC Standard: ANSI PC63.19-2005 D3.6 On July 10, 2003, the U.S.
Page 271
FCC HEARING-AID COMPATIBILITY (HAC) REGULATIONS FOR WIRELESS DEVICES Hearing devices may also be rated. Your hearing device manufacturer or hearing health professional may help you find this rating. Higher ratings mean that the hearing device is relatively immune to interference noise. The hearing aid and wireless phone rating values are then added together.
FDA CONSUMER UPDATE 1. Do wireless phones pose a health hazard? The available scientific evidence does not show that any health problems are associated with using wireless phones. There is no proof, however, that wireless phones are absolutely safe. Wireless phones emit low levels of radiofrequency energy (RF) in the microwave range while being used.
Page 273
FDA CONSUMER UPDATE 3. What kinds of phones are the subject of this update? The term “wireless phone” refers here to hand-held wireless phones with built-in antennas, often called “cell,” “mobile,” or “PCS” phones. These types of wireless phones can expose the user to measurable radiofrequency energy (RF) because of the short distance between the phone and the user’s head.
Page 274
FDA CONSUMER UPDATE The Project has also helped develop a series of public information documents on EMF issues. FDA and the Cellular Telecommunications & Internet Association (CTIA) have a formal Cooperative Research and Development Agreement (CRADA) to do research on wireless phone safety. FDA provides the scientific oversight, obtaining input from experts in government, industry, and academic organizations.
Page 275
FDA CONSUMER UPDATE 10. What about children using wireless phones? The scientific evidence does not show a danger to users of wireless phones, including children and teenagers. If you want to take steps to lower exposure to radiofrequency energy (RF), the measures described above would apply to children and teenagers using wireless phones.
Many companies are making look alike accessories and in some cases, promoting that their product is equal to or better than the UTStarcom product. Be careful. Some of these products may not be compatible to use with your UTStarcom product and may damage the unit or cause it to malfunction.
12 MONTH LIMITED WARRANTY UTStarcom Personal Communications (the Company) warrants to the original retail purchaser of this UTStarcom handheld portable cellular telephone, that should this product or any part thereof during normal consumer usage and conditions, be proven defective in material or...
Page 278
UTStarcom Personal Communications for repair or service. To obtain repairs or replacement within the terms of this Warranty, the product should be delivered with proof of Warranty coverage (e.g.
Page 279
This Warranty gives you specific legal rights, and you may also have other rights, which vary from state to state or province to province. IN USA: UTStarcom Personal Communication IN CANADA: UTStarcom Canada Company 5535 Eglinton Avenue West 555 Wireless Blvd.
