eta AQUILO PRO User Manual page 58

EN
7.3 MAIN BRUSH CLEANING
1. Press relevant locking elements, remove cover A8 and main brush A7.
2. Clean the main brush with the cleaning tool I (or other suitable). You can also use
scissors to remove tangled hair / hair. Wipe the main brush cover and main brush
compartment with a soft, dry cloth.
3. After maintenance, install the main brush back to the robot vacuum.
7.4 SIDE BRUSH CLEANING
1. Loosen locking screw using screwdriver and remove brush A6.
2. Clean the brush and remove hair sticking on it.
3. After maintenance, install the brush back in place and tighten the locking screw again.
7.5 WHEELS CLEANING
Clean the front, left and right wheels with the I device. For easier maintenance, you can
remove front wheel A5. After the maintenance, fit wheel A5 back to place.
EN - 58
