OPERATION MANUAL
SH-110A5
DR-110A5
PD-110A5
Prior to operating this pump, be sure to read this operation manual for safety. After reading the manual,
please keep it at hand any time for your quick reference.
OIL PUMP
SH-110A5
（ 851753 ）
DR-110A5
（ 851754 ）
WARNING
ITEM No.851753
ITEM No.851754
ITEM No.851755
PD-110A5
（ 851755 ）
Doc. No.
APP 004U-06
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for YAMADA SH-110A5
Summary of Contents for YAMADA SH-110A5
- Page 1 Doc. No. APP 004U-06 OPERATION MANUAL OIL PUMP SH-110A5 ITEM No.851753 DR-110A5 ITEM No.851754 PD-110A5 ITEM No.851755 SH-110A5 （ 851753 ） PD-110A5 （ 851755 ） DR-110A5 （ 851754 ） WARNING Prior to operating this pump, be sure to read this operation manual for safety. After reading the manual,...
-
Page 4: Warnings And Cautions
- Preface Thank you very much for purchasing Yamada Pump. The 110 type oil pump is dedicated to the oil that is liquid at the normal temperature and has a flash point of 200 °C or more. This is an air-driven pump that is used to feed the oil in a drum can by pressure, draw out and divide oil into vessels, or inject a fixed quantity of oil. -
Page 5: Precautions On Use
- Precautions on Use The following warnings and cautions are very important. Be sure to observe them. WARNING - Keep your face away from the exhaust and discharge ports. Material may suddenly come out. There is a possibility of losing eyesight if it strikes eyes. - Gasoline is a high volatile fuel. - Page 6 CAUTION - Keep hands and fingers away from the pump during operation to avoid injury from moving parts. - Use pump for the material suitable for the specification. Parts may be corroded and material leak from the damaged parts can lead to environmental pollution. Also, follow handling notes (SDS) of the manufacturer about the handling of the material used.
-
Page 7: Table Of Contents
4. How to Operate the Pump ·············································································· 5 5. Maintenance and Inspection ························································ 6 5.1 Troubleshooting and Corrective Measures ········································································· 7 5.2 Maintenance and Inspection ····················································································· 7 5.3 Consumable Parts 6. Pump Specifications ······················································································ 8 7. Accessory(851753 SH-110A5 type) ··································································· 9 8. Limited Warranty ························································································· 10... -
Page 8: Names And Materials Of Parts
1. Names and Materials of Parts 1.1 Names and Materials of Parts 1.2 Contents of Package This pump is packed in a corrugated fiberboard case. Please make sure no damage during shipment and no missing accessories after unpacking as soon as possible. -
Page 9: Principles Of Operation
2. Principles of Operation The Yamada Air-powered Pump is a reciprocating type that is driven by compressed air. The pump consists of an air motor to drive the pump and a lower pump to draw up the material as shown in the figure at right. -
Page 10: Installing The Siphon Pump
3.2 Installing the Siphon Pump Steel pipe Fig. 2 High–pressure valve When installing the pump at the panel unit (separately available) or the mounting bracket, Material hose Air hose observe the following procedure. (When purchasing the panel unit separately) Loosen the bolt of the pump fixing band mounted on the mounting bracket and Vent regulator... -
Page 11: Air Connection
Install the hose union and material hose (separately available) to Air hose Air regulator the material discharge port (Rc3/4) of the pump. Tighten the hose Pump union with a spanner so as not to make the material hose loose. In Piping this case, wind the seal tape that is available on the market around the male screw of the hose and then screw it. -
Page 12: How To Operate The Pump
The distance for pressure feed differs depending on the viscosity, temperature, and required flow rate of oil. Regarding details, please ask Yamada Corporation or the dealer for further information. Turn the knob of the air regulator clockwise to supply air into the pump. When the supply air pressure reaches 0.15 - 0.20 MPa, the pump starts to operate. -
Page 13: Maintenance And Inspection
5. Maintenance and Inspection 5.1 Troubleshooting and Corrective Measures If the pump operation becomes unstable or trouble is caused to its oil discharge during operation, make a check according to the following procedure. Symptom Cause Contents of inspection and corrective measures The pump cannot Check if the air Check if the valve in... -
Page 14: Maintenance And Inspection
5.2 Maintenance and Inspection For lubrication of the pump, perform oiling once every 10 days with lubricating oil. Supply the lubricating oil as following. Remove the air regulator. Inject a few drops of lubricating oil (approx. 0.5 mL) into the air supply port as shown in the figure at right. -
Page 15: Pump Specifications
6. Pump Specifications ■ Engineering Data TYPE DR-110A5 PD-110A5 SH-110A5 ITEM No. 851754 851755 851753 PUMP RATIO (NOMINAL) 5 x 1 SUCTION PORT R 1-1/2 FLUID CONNECTION Rc 3/4 DISCHARGE PORT G 1/4(F) (Union Adapter) AIR CONNECTION SUPPLY PORT OPERATING AIR PRESSURE 0.2 - 0.7 MPa... -
Page 16: Accessory(851753 Sh-110A5 Type)
7. Accessory(851753 SH-110A5 type) ■Panel Unit Parts No. Descriptions Q’ty 801102 Delivery hose assembly 805062 Panel option 802558 Air regulator assembly 800400 Mounting bracket assembly ■850126 Suction Hose Assembly... -
Page 17: Limited Warranty
8. Limited Warranty If an abnormality occurs during normal operation in accordance with the operating instructions and other operating cautions within the warranty period (12 months after date of purchase) that can be attributed to a manufacturing defect, the defective parts of this product will be serviced or the product will be replaced free of charge. - Page 18 MEMO.
- Page 20 YAMADA EUROPE B.V . Aquamarijnstraat 50,7554 NS Hengelo (O),The Netherlands PHONE : +31-(0)74-242-2032 : +31-(0)74-242-1055 E-mail : sales@yamada.nl : www.yamada-europe.com Manufactured by YAMADA CORPORATION INTERNATIONAL DEPARTMENT 1-1-3, Minami-Magome,Ota ku, Tokyo, 143-8504, Japan PHONE : +81-(0)3-3777-0241 : +81-(0)3-3777-0584 E-mail : intl@yamadacorp.co.jp : www.yamadacorp.co.jp...
