3. SETTING PULSE OR TONE DIALING
The CrystalTone Plus is preset to use tone
dialing because this is used by most telephone
lines. If your line uses pulse dialing, move the
switch located on the bottom of the
CrystalTone Plus to the "Pulse" setting.
4. SETTING UP THE CrystalTone Plus
For Desktop Use
1. Plug the
adapter cord into
the round power
jack on the bottom
of the CrystalTone
Plus. If the
desktop/wall
adapter is not removed, remove it now
(see illustration on page 4).
2. Plug the telephone line cord into the
telephone line jack on the bottom of the
CrystalTone Plus and the other end into
the wall phone jack.
3. Plug the AC adapter into an AC wall outlet.
4. Replace the desktop/wall adapter so that
the larger side is along the top edge of the
CrystalTone Plus.
5. Set the CrystalTone Plus on a sturdy
surface such as a desk, table or counter.
AC
1 2
Mounting on a Wall
1. Flip the handset
hook over so that
the hook points up
and will hold the
handset when you
hang it up.
2. Plug the AC adapter cord into the round
power jack on the bottom of the
CrystalTone Plus.
3. Plug the 6-inch telephone line cord into
the CrystalTone Plus.
4. Replace the desktop/wall adapter so the
larger side is down. This aligns the
CrystalTone Plus so that it is flat when
3 mounted on the wall.
5. Plug the telephone
cord into the wall
jack. Then, line up
the holes in the
wall-mount
bracket with the
mounting studs on
the wall plate. Hook the bracket on the
studs then pull down.
6. Plug the AC adapter into an AC wall outlet.
The power cord should not lie across any
walkway.
INSTALLATION
■
