USE AND CARE GUIDE
PATTERSON ELECTRIC FIREPLACE MANTEL
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this fireplace mantel. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement
needs. Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY 18WM30495-PC44
Summary of Contents for HAMPTON BAY 18WM30495-PC44
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this fireplace mantel. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement...
-
Page 2: Table Of Contents
Table of Contents Safety Information ............. 3 Operation ..............7 Warranty ..............5 FCC/IC Information ............8 Pre-Assembly ............. 6 Care & Cleaning ............8 Hardware Included ........... 6 Troubleshooting ............9 Product Specifications ............6 Replacement Parts ..........10 Maximum Load Warning MAXIMUM LOAD 15 lb. -
Page 3: Safety Information
Safety Information Please read and understand this entire manual before attempting to assemble, operate or install the product. If you have any question regarding the product, please call customer service at at 1-855-HD-HAMPTON or visit WARNING: Under no circumstances should this fireplace www.HAMPTONBAY.com. - Page 4 Safety Information (continued) NOTE: Use care in assembling your new fireplace. Take your time and use the hardware provided and a quality Phillips head screwdriver. Never overtighten bolts. • Do not sit on any part of the mantel. NOTE: To avoid injury from unexpected starting or electrical shock, do not plug the power cord into a source of power during unpacking and assembly.
-
Page 5: Warranty
Warranty Warranty 1 Year Limited Warranty: The manufacturer warrants that your new Electric Fireplace is free from manufacturing and material defects for a period of one year from date of puchase, subject to the following conditions and limitations. Install and operate this appliance in accordance with the installation and operating instructions furnished with the product at all times. -
Page 6: Pre-Assembly
Pre-Assembly HARDWARE INCLUDED Part Description Part Number Quantity Insert Mounting Bracket (pre-attached) PH-BKTZNC001 Floor Glide (pre-attached) PH-GLDBRW001 NOTE: Hardware not shown to actual size. PRODUCT SPECIFICATIONS VOLTAGE 120VAC, 60 Hz AMPS 11.7 Amps WATTS 1400 Watts PLANNING ASSEMBLY Before beginning assembly of product, make sure all parts are present. Compare parts with Hardware Included and Package Contents lists. If any part is missing or damaged, do not attempt to assemble, install or operate the product. -
Page 7: Operation
Operation Operation NOTE: The control panel can be accessed at the upper-right corner of the insert. Powering the fireplace Heater The power switch supplies power to all of the The fireplace consists of a fan-forced functions of the fireplace wire-element-type heater. The heater switch turns the heater ON and OFF. -
Page 8: Fcc/Ic Information
FCC/IC Information WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 9: Troubleshooting
Troubleshooting PROBLEM ROOT CAUSE CORRECTIVE ACTION Defective Switch, broken, no Switches do not work. Contact customer service to replace the switch(s). longer toggles, loose. Blower is very noisy when flames are off. Blows cold air. Heater Blower Motor. Contact customer service to replace the heater/blower assembly. Blower runs but does not produce heat. -
Page 10: Replacement Parts
Replacement Parts For replacement parts, call our customer service department at at 1-855-HD-HAMPTON or visit www.HAMPTONBAY.com. Part Description Qty. Front Flame Circuit Board Back Flame Circuit Board Blue LED Circuit Board Power Circuit Board Main Power Switch Heater/Blower Assembly Front Panel with Frame... - Page 11 HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 12 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
