Nexcom NSA 7160 Quick Reference Manual page 13

NSA 7160 Quick Reference Guide
JP17 JP18
2
1
2 1
H10
CON2
8 16
CN10
A37
CN5 1 9
B37
A1 A25
H13
H11
B1 B25
H1
CON1
MP2 DP1 MP5 MP12
A2
8 16
A1
H8
MP13
MP3 DP2
A2
C
1 9
A1
H2
U70
CN1
3 6
4
1
4 8
1 5
CN2
JP23
H9
3
2
1
1
2
3
RTC
CN7 CN8
1 1 2 60 2 60
H15
7 7
H3
1 59 1 59
CN4
J2
H17
2 JP15
1
4
H12
1 2
JP7
JP9
3 1
1 8 7
2
4 3
J3
1
2 1 2
H7
JP8
1 16
H4
1
2
JP16
1 2
11 12
H16
3 1
3 1
H6
4 2
4 2
JP10 2
1
1
JP11
6
CN3
JP12
2
10 1
JP5
1 9 3
2 2
4 1
3 JP6
2 1 2
8 7 1
1
2 1
JP4
H14
H5
OB14
CN6 CN9
CN11 J10 JP20 J11
1 3
H26
2
9 1 9 1
1 4
CN13 CN16 CN18
A1 A37 A1 B1 B37 B1 B37
H30
B1 B37 B1 A1 A37 A1 A37
H21
H33
U110
H29 H34
CN15
2 4 2 4 2 60
1 59
1 3 1 3
H23
CN12
OB1 OA1
OB14 OA14
B1 A1
B28 A28
B29 A29
B42 A42
B43 A43 1 12
U103
B70 A70
H22 H31
OB14
OB14 OB14
CN14 CN17
DIMM1: Run BMC Connector
JP22 CN19 J12
1 3
2 1 4 9 1
H48
CON4
3
1
2
4
H46
H38
H49
1
2
H47
CON3
3 1
H45
4 2
CTP31
H41
H52
U115
OB1 OA1
OB14 OA14
B1 A1
B28 A28
B29 A29
B42 A42
B43 A43
B70 A70
H50
H40
OB14
CN20
Pin Description Pin
1 P12V_AUX 2
3 P3V3_BMC 4
5 P3V3_BMC 6
7 P3V3_BMC 8
9 GND 10
11 GND 12
13 SGPIO_BMC_LD_R_N 14
15 SGPIO_BMC_DIN 16
17 SGPIO_BMC_DOUT 18
19 SGPIO_BMC_CLK_R 20
21 BMC_RXD5 22
23 BMC_TXD5 24
25 FP_ID_LED_R_N 26
27 BMC_FAN3_PWM 28
29 BMC_FAN5_PWM 30
31 IRQ_BMC_CPU_NMI_R 32
33 RNBMC_R1_PRSNT# 34
35 IRQ_BMC_PCH_SMI_LPC_N_BMC 36
37 FM_P1V2_BMC_AUX_EN_R 38
39 GND 40
41 BMC_CPLD_UART1_R_RXD 42
43 BMC_CPLD_UART1_R_TXD 44
45 GND 46
47 SMB_CPLD_STBY_LVC3_MM8_R3_CLK 48
49 SMB_CPLD_STBY_LVC3_MM8_R3_DATA 50
51 GND 52
53 SMB_SENSOR_STBY_LVC3_R1_CLK 54
55 SMB_SENSOR_STBY_LVC3_R1_DATA 56
57 GND 58
59 FM_CPU_ERR0_LVT3_BMC_N 60
61 FM_CPU_ERR1_LVT3_BMC_N 62 SMB_BMC_STBY_LVC3_MM5_R_DATA
63 SPI_BMC_BOOT_CS0_R_N 64
65 SPI_BMC_BOOT_R_MOSI 66
67 SPI_BMC_BOOT_R_MISO 68
69 SPI_BMC_BOOT_R_IO2 70
71 SPI_BMC_BOOT_R_IO3 72
73 SPI_BMC_BOOT_R_CLK 74
75 SPI_BMC_BOOT_CS1_R_N 76
77 PWRGD_BMC_PS_PWROK_R 78
79 FM_BMC_CRASHLOG_TRIG_N_BMC 80
81 FM_CPU1_SKTOCC_LVT3_R1_N 82
83 BMC_GPIO49 84
85 FM_CPU_CATERR_R2_N 86
87 RST_PFR_EXTRST_N 88
89 FM_BMC_PCH_SCI_LPC_R2_N 90
Description
NC
P3V3_BMC
P3V3_BMC
GND
V_BMC_GFX_REAR_GRN
V_BMC_GFX_REAR_BLU
V_BMC_GFX_REAR_RED
V_BMC_GFX_REAR_HSYN
V_BMC_GFX_REAR_VSYN
SMB_BMC_DDC_SCL_R
SMB_BMC_DDC_SDA_R
GND
BMC_FAN1_PWM
BMC_FAN2_PWM
BMC_FAN4_PWM
BMC_FAN6_PWM
CPLD_BMC_SMI_R#
BMC_GPIO19
BMC_CPLD_UART1_R_CTS#
BMC_CPLD_UART1_R_NDCD
ID_LED_BMC_OUT
BMC_GPIO24
BMC_CPLD_UART1_R_NDSR
SMB_CPU_PIROM_BMC_SCL
SMB_CPU_PIROM_BMC_SDA
GND
SMB_SMLINK0_STBY_LVC3_R2_SCL
SMB_SMLINK0_STBY_LVC3_R2_SDA
GND
SMB_BMC_STBY_LVC3_MM5_R_CLK
GND
BMC_CPLD_UART1_R_RI
BMC_CPLD_UART1_R_DTR
BMC_CPLD_UART1_R_RTS#
FP_LED_STATUS_GREEN_R_N
FM_BIOS_POST_CMPLT_BMC_N
IRQ_BMC_PCH_NMI_R
BMC_FAN1_TACH
BMC_FAN2_TACH
BMC_FAN3_TACH
BMC_FAN4_TACH
BMC_FAN5_TACH
BMC_FAN6_TACH
FM_SLPS3_R_N
