Mounting the Hood
4. Lift liner into bottom opening of cabinet and secure to interior of cabinet using (12) #8 x 1/2"
stainless steel screws; (4) screws in the front and (4) screws in the sides and (4) screws in the back.
FIG. D.
5. Finalize installation of electrical and duct work. Seal duct work with certified aluminum duct tape.
Power on liner, check for leaks around duct tape and verify proper operation.
NOTE: If access to top of liner is not available after installation, electrical and duct work connection
may need to be made prior to installing the liner.
Monsoon Mini Use, Care, and Installation Guide
Installation Instructions
FIG. D
